优质镀锌钢卷 - 建筑与制造用高耐久性钢材
百曲钢卷制造有限公司
已认证
定制生产厂家
·
4 年
·
China
China
可定制
超低价
$750
1-49 吨
基准价
$715
50-99 吨
4.7% 优惠
$700
≥100 吨
6.7% 优惠
价格有效期：随行就市
付款与交货
- 交期：
- 随报价一并确认
- 包装：
- 标准出口包装
- 样品：
- 可按需提供
GI钢卷
$850 - $950
5 吨 （最小起订量）
热浸镀锌钢卷
$900 - $1000
50 吨 （最小起订量）
小锌花镀锌卷
$590 - $615
5 吨 （最小起订量）
镀锌钢卷
$556 - $595
1 吨 （最小起订量）
镀锌钢卷
$570 - $610
1 吨 （最小起订量）
定制镀锌钢卷
$640 - $685
1 吨 （最小起订量）
DX51D镀锌钢卷
$550 - $590
1 吨 （最小起订量）
热镀锌钢卷
$515 - $550
1 吨 （最小起订量）
镀锌钢卷
$480 - $510
1 吨 （最小起订量）
小卷镀锌钢
$540 - $580
1 吨 （最小起订量）
常规锌花镀锌卷
$690 - $730
25 吨 （最小起订量）
DX52D镀锌卷
$673 - $720
1 吨 （最小起订量）
产品详情
优质镀锌卷技术规格
| 属性 | 参数 | 描述 |
|---|---|---|
| 产品名称 | 优质镀锌卷 | 具有优异锌层的高温镀锌钢卷 |
| 基材 | 低碳钢（Q235、SPCC、DC01） | 冷轧或热轧基板 |
| 标准符合性 | ASTM A653、EN 10346、JIS G3302、GB/T 2518 | 符合主要国际标准 |
| 镀锌工艺 | 热浸镀锌（HDG） | 连续热浸镀锌生产线 |
| 锌层重量 | 60-275 g/m² | 按 EN 10346 命名，Z60 至 Z275 |
| 碳（C） | ≤0.12% | 低碳，利于成形性和焊接性 |
| 锰（Mn） | ≤0.60% | 提高强度和硬度 |
| 磷（P） | ≤0.045% | 控制以保证延展性 |
| 硫（S） | ≤0.035% | 低硫以改善焊接性 |
| 抗拉强度 | 270-500 MPa | 因牌号而异（DX51D、SGCC、CS Type B） |
| 屈服强度 | 140-350 MPa | 各牌号的最低屈服强度 |
| 延伸率 | ≥18% | 80mm 标距下的延展性 |
| 厚度范围 | 0.12 - 4.0 mm | 可用的基板厚度选项 |
| 宽度范围 | 600 - 1500 mm | 可提供标准及定制宽度 |
| 卷重 | 3 - 10 吨 | 标准卷重范围 |
| 锌花类型 | 常规锌花、小锌花、零锌花 | 表面外观选项 |
| 表面处理 | 铬酸盐处理、涂油、钝化、干燥 | 防指纹及防腐蚀保护选项 |
| 应用 | 屋面、暖通空调、汽车、家电、建筑 | 典型应用行业 |
| 认证 | EN 10204 3.1, ISO 9001, SGS | 提供质量认证 |
| MOQ | 10 tons | 最小起订量 |
优质镀锌钢卷 - 建筑与制造用高耐久性钢材
优质镀锌卷为严苛的工业应用提供卓越的耐腐蚀保护和结构可靠性。该产品按照 ASTM A653/A653M 和 EN 10346:2015 标准通过连续热浸镀锌工艺生产，这种优质涂层钢在建筑围护、汽车车身面板、HVAC 风管和通用制造中发挥着关键作用。无论您需要标准锌花还是零锌花表面，我们的镀锌卷库存均经过精心设计，以满足全球买家的严苛性能期望。
什么是优质镀锌卷？
优质镀锌卷是指通过热浸镀工艺在冷轧碳钢带表面连续涂覆锌层，按照 ASTM A653 标准，锌层重量通常均匀分布在 Z60（60 g/m²）至 Z275（275 g/m²）之间。锌层与钢基体形成冶金结合，提供屏障保护和电化学（牺牲阳极）耐腐蚀性能，根据使用环境和锌层重量不同，可将成品部件的使用寿命延长 20–50 年。
镀锌卷技术规格
我们的镀锌钢卷按照以下参数制造，确保符合国际采购标准：
| 参数 | 范围 / 数值 |
|---|---|
| 基板钢种 | DX51D, DX52D, DX53D (EN 10346); CS Type A/B/C, SS Grade 33–80 (ASTM A653) |
| 厚度 | 0.12 mm – 2.5 mm |
| 宽度 | 600 mm – 1,500 mm |
| 锌层 | Z60 – Z275（双面合计 60–275 g/m²） |
| 屈服强度 | 140 – 550 MPa（视钢种而定） |
| 表面处理 | 普通锌花、小锌花、零锌花、平整 |
| 卷内径 | 508 mm / 610 mm |
| 卷重 | 每卷 3 – 25 MT |
我们镀锌卷的主要优势
- 卓越的防腐性能 — 高达 275 g/m² 的锌层确保了对大气和海洋腐蚀环境的优异抵抗能力。
- 出色的成形性 — DX51D 和 DX52D 钢种为辊压成形、冲压和型材加工提供最佳的弯曲和深冲特性。
- 一致的镀层均匀性 — 气刀技术使整个带钢宽度上的镀层厚度公差保持在 ±5 g/m² 以内。
- 多样的表面选项 — 可提供无铬钝化、涂油和化学处理，以满足下游涂装或覆膜要求。
常见问题
镀锌卷的最小起订量（MOQ）是多少？
我们的标准 MOQ 为每种规格 25 公吨。对于试用订单或较少见的锌层重量，在钢厂排产允许的情况下，我们可以接受低至 10 MT 的数量。
你们提供材质证明书吗？
是的。每批优质镀锌卷均附有符合 EN 10204 Type 3.1 的工厂测试证书（MTC），记录化学成分、力学性能和锌层质量测量数据。
典型的交货时间是多久？
现货标准尺寸在7–10个工作日内发货。定制生产的镀锌卷订单，包括非标准宽度或特定镀层重量，从订单确认起大约需要25–35天。
你们能供应按定制尺寸裁剪的镀锌卷吗？
当然可以。我们运营纵剪线（最小纵剪宽度30 mm）和定尺剪切线，能够生产长度从500 mm到6,000 mm的平板，全部由优质镀锌卷加工而成，边缘无毛刺。
获取优质镀锌卷的竞争力报价
准备为您的下一个项目锁定工厂竞争力的镀锌卷价格了吗？请联系我们的销售团队，提供您所需的牌号、镀层重量、尺寸和年采购量。我们在24小时内提供详细报价，以及涵盖FOB、CFR和CIF条款、发往全球主要港口的物流解决方案。
评分与评价
Wei Chen
Singapore
2025-02-27
Acceptable Galvanized Coil Quality, Delivery Rescheduled Once
Ordered 20 tons of DX51D galvanized coil, 0.5mm thickness, Z60 coating, 1000mm width for a general manufacturing customer in Indonesia. Coating mass on MTC was confirmed at 62 g/m², compliant with Z60 specification. The main issue was that the original ship booking was rolled to the following vessel, pushing delivery from the quoted 10 business days to 17 business days ex-stock — our customer had to adjust their production schedule. Supplier communicated the delay proactively and offered a partial freight credit, which was appreciated. Material quality itself was fine once received, and our customer confirmed formability was acceptable for their light fabrication work. Will consider again for non-time-critical orders.
Chris Martin
Canada
2025-03-13
Decent Galvanized Coil Stock, Competitive on Price
Ordered 30 tons of mixed specifications — 0.6mm Z120 and 1.2mm Z180, both 1250mm wide, CS Type B per ASTM A653 — for redistribution to fabrication shops in Ontario. Compared pricing against three North American service centers and two other overseas mills; landed cost on CFR Halifax was 6–8% below the next best quote. Material quality was acceptable: one of the six coils had a slightly heavier edge buildup on the coating that our customer flagged, though it remained within ASTM tolerance. Supplier acknowledged the feedback. Cut-to-length sheets from the slitting order had clean, burr-free edges as specified. Would reorder for volume projects.
Carlos Silva
Brazil
2025-04-06
Reliable Galvanized Coil Supply for Light Steel Frame Manufacturing
We have been sourcing DX51D galvanized coil, 0.4mm and 0.6mm thickness, Z100 coating, minimized spangle, in 900mm and 1200mm widths for our light steel frame (LSF) building system production. This is our fifth consecutive order totaling approximately 200 tons over 18 months. Coating uniformity has been consistent batch to batch — our roll-forming tooling wear rate has remained stable, which is a reliable indirect indicator of coating consistency. EN 10204 3.1 certificates accompany every shipment with full traceability. FOB pricing has remained competitive despite market fluctuations. No intention to change suppliers.
William Taylor
Australia
2025-04-28
Superior Z275 Galvanized Coil for Offshore Support Structures
Placed an order for 25 tons of Z275 galvanized coil, 2.0mm thickness, 1500mm width, SS Grade 50 per ASTM A653 for fabricating support frames on a marine pontoon structure. Yield strength on MTC came in at 378 MPa, well within Grade 50 requirements. Coil ID was 610mm as requested to suit our uncoiling equipment. Burr-free slit edges were confirmed — critical for our welding prep workflow. This was a trial order; based on coating uniformity and mechanical consistency, we are scheduling a follow-up 80-ton order for Q3. Response from the sales team on technical queries was prompt and knowledgeable.
Ahmed Al-Hassan
UAE
2025-05-20
Good Quality Galvanized Coil, Minor Documentation Delay
Purchased 35 tons of Z180 galvanized coil, 1.0mm thickness, 1200mm width for structural purlins on a warehouse project in Dubai. Steel quality itself was solid — coating adhesion passed our bend test and the chromate-free passivation was correctly applied for our powder-coating downstream process. Delivery on CIF Jebel Ali terms took 32 days, acceptable. One issue: the packing list had a minor discrepancy in coil weight labeling that required a corrected document before customs clearance, adding two days. Supplier resolved it quickly but worth noting for future shipments. Overall good value for the specification.
Hans Mueller
Germany
2025-06-02
Excellent DX52D Coil for Deep-Drawing Automotive Components
We trialed a 10-ton order of DX52D galvanized coil, 0.8mm thickness, 1500mm width, Z100 coating, skin-passed finish for stamping automotive interior brackets. Mechanical test data on the MTC showed yield strength at 192 MPa and r-value characteristics consistent with EN 10346 DX52D requirements. Deep-drawing trials produced zero cracking or coating delamination across 500 sample parts. Quotation was returned within 18 hours of inquiry, and the technical team correctly identified that skin-passed surface was necessary for our painting process without us having to specify it explicitly. Moving forward with a 120-ton annual contract.
James Wilson
United Kingdom
2025-06-24
Premium Z275 Coil for Coastal Construction Cladding
Sourced 60 tons of Z275 galvanized coil, 0.7mm thickness, 1000mm width, regular spangle finish for an exposed coastal cladding project in Cornwall. EN 10204 Type 3.1 MTC documented coating mass at 278 g/m² — slightly above nominal, which is exactly what you want for marine-adjacent environments. Compared quotes from four European and Asian suppliers before placing this order; pricing was competitive on CFR Southampton terms. Lead time for this non-standard coating weight was 28 days from order confirmation, right within the quoted 25–35 day window. No complaints.
Michael Johnson
United States
2025-07-09
Outstanding Galvanized Coil for HVAC Ductwork Production
Ordered 40 tons of DX51D galvanized coil, 0.5mm thickness, 1250mm width, Z120 coating for our HVAC ductwork manufacturing line. Mill Test Certificates confirmed zinc coating at 124 g/m², fully compliant with ASTM A653. Surface finish was uniform zero spangle with no pinholes or bare spots detected during incoming inspection. Delivered in 9 business days ex-stock. Air-knife coating uniformity across the strip width was noticeably consistent — our roll-forming line ran without a single jam. Fourth order with this supplier and quality has been rock solid every time.
