ss 304 stainless steel coil
China
Supplier's customization ability
- Drawing-based customization
- Sample-based customization
- Full customization
Minimum order quantity: 1 ton
Shipping total: To be negotiated
- Lead time:
- confirmed with the quotation
- Packaging:
- standard export packing
- Samples:
- available on request
Product details
SS 304 Stainless Steel Coil Introduction
Applications of SS 304 Stainless Steel Coil
SS 304 stainless steel coil is a widely used austenitic stainless steel known for its excellent corrosion resistance and versatility. It is commonly employed in food processing equipment, kitchen appliances, architectural structures, and chemical containers. Its resistance to oxidation and ability to maintain strength at elevated temperatures make it suitable for manufacturing tanks, heat exchangers, and pipelines in diverse industries. The long tail keyword "SS 304 stainless steel coil for food processing" underscores its critical role in hygiene-sensitive environments where durability and corrosion resistance are essential.
Specifications and Mechanical Properties
Typical specifications of SS 304 stainless steel coil include thickness ranges from 0.02mm to 10mm, with widths up to 1500mm or more according to customer requirements. The chemical composition features 18-20% chromium and 8-11% nickel, ensuring robust corrosion resistance. Mechanical properties typically include a tensile strength of approximately 515 MPa, yield strength of 205 MPa, and elongation of about 40%, signifying excellent ductility and formability. Surface finishes available include 2B, BA, NO.1, and mirror finishes, providing both functional and aesthetic options. The long tail keyword "SS 304 stainless steel coil specifications and grades" highlights the importance of these details for accurate sourcing and quality assurance.
Advantages and Industry Suitability
SS 304 stainless steel coil offers outstanding advantages such as high corrosion resistance, excellent weldability, and good mechanical strength across a wide temperature range. Its resistance to pitting, crevice corrosion, and oxidation makes it suitable for marine, chemical, and architectural applications. The long tail keyword "benefits of SS 304 stainless steel coil in construction" illustrates its growing use in structural and decorative applications, offering both durability and aesthetic appeal. For procurement professionals, selecting SS 304 coil means securing a reliable, cost-effective material that supports long-lasting performance in demanding environments while meeting global quality standards.
SS 304 Stainless Steel Coil Attributes
| Attribute | Parameter | Description |
|---|---|---|
| Product Name | SS 304 Stainless Steel Coil | Standard austenitic stainless steel coil with excellent corrosion resistance and mechanical properties. |
| Grade | 304 / 304L (UNS S30400 / S30403) | 304 is standard, 304L is low carbon for improved weldability and reduced carbide precipitation. |
| Thickness Range | 0.02 mm – 6.0 mm | Flexible thickness options for various industrial and fabrication needs. |
| Width Range | 1.0 mm – 1500 mm | Standard widths compatible with diverse processing machinery. |
| Surface Finish | 2B, BA, No.1, No.4, 8K, Mirror, HL, Brushed | Multiple finish options for aesthetic and functional requirements. |
| Tensile Strength | ≥ 515 MPa | Ensures mechanical durability under stress. |
| Yield Strength | ≥ 205 MPa | Provides resistance against deformation. |
| Elongation | ≥ 40% | High ductility allowing deep drawing and forming. |
| Hardness | HRB max 92; HB max 201 | Balanced hardness for both strength and formability. |
| Density | Approximately 8.0 g/cm³ | Typical for austenitic stainless steels. |
| Melting Point | About 1450°C | Suitable for high temperature applications. |
| Thermal Expansion | 17.2 × 10⁻⁶ /K (20–100°C) | Thermal expansion coefficient important for dimensional stability. |
| Thermal Conductivity | 17.8 W/m·K | Moderate conductivity for thermal management. |
| Electrical Resistivity | 0.72 × 10⁻⁶ Ω·m | Suitable for electrical and electromagnetic applications. |
| Magnetic Properties | Essentially non-magnetic; slight magnetic when cold worked | Austenitic grade typically non-magnetic but can become slightly magnetic after cold work. |
| Corrosion Resistance | Excellent resistance to corrosion in many media including fresh water, seawater, chemicals | Suitable for food processing, chemical industries, and marine environments. |
| Standards Compliance | ASTM A240, JIS G4305, GB/T 4237, EN 10088 | Meets international quality and safety standards. |
| Applications | Food processing, chemical processing, architectural surfaces, medical and pharmaceutical devices | Versatile applications requiring corrosion resistance, durability, and formability. |
| Packaging | Standard coil packaging with protective wrapping | Ensures surface quality and coil integrity during transportation and storage. |
