| Property | Parameter | Description |
|---|---|---|
| Product Name | Cold-Drawn Carbon Steel Bars | Precision carbon steel bars manufactured through cold drawing process |
| Material Grade | AISI 1045 / S45C / C45 / EN 1.0503 | International grade equivalents for medium carbon steel |
| Standard Compliance | ASTM A108, EN 10277-2, JIS G4051 | Meets major international standards for cold-finished bars |
| Manufacturing Process | Cold Drawing | Enhanced dimensional accuracy and surface finish |
| Carbon Content (C) | 0.42-0.50% | Medium carbon content for balanced strength and machinability |
| Manganese (Mn) | 0.60-0.90% | Improves hardenability and tensile strength |
| Phosphorus (P) | ≤0.040% | Controlled for improved ductility |
| Sulfur (S) | ≤0.050% | Low sulfur for better mechanical properties |
| Silicon (Si) | 0.15-0.35% | Deoxidizer and strengthening element |
| Tensile Strength | ≥600 MPa | Minimum tensile strength for AISI 1045 cold-drawn condition |
| Yield Strength | ≥340 MPa | Minimum yield strength in cold-drawn state |
| Elongation | ≥16% | Ductility in 50mm gauge length |
| Hardness | 170-210 HBW | Brinell hardness range for cold-drawn bars |
| Diameter Range | 3mm - 300mm | Available diameter options for round bars |
| Length | 3m - 12m or custom | Standard and custom length options |
| Surface Finish | Bright, Polished, Peeled | Multiple surface treatment options |
| Straightness Tolerance | ≤1.5mm/m | High precision straightness per ASTM A108 |
| Application | Shafts, Gears, Fasteners, Machinery Parts | Typical industrial applications requiring precision |
| Certification | EN 10204 3.1, ISO 9001, Material Test Report | Quality certifications and traceability documents |
| MOQ | 5 tons | Minimum order quantity for standard grades |
Acceptable Quality with Initial Documentation Delay
Purchased 6 tons of 1018 bars, 20mm diameter for distribution inventory. Material quality met ASTM A108 standards, surface finish and dimensions within specification. Initial shipment arrived without mill test certificates, required follow-up emails over 5 days to receive documentation. Issue resolved professionally, certificates eventually provided showing compliant chemical composition. Product itself good for the price point, would order again with earlier documentation request.
Purchased 6 tons of 1018 bars, 20mm diameter for distribution inventory. Material quality met ASTM A108 standards, surface finish and dimensions within specification. Initial shipment arrived without mill test certificates, required follow-up emails over 5 days to receive documentation. Issue resolved professionally, certificates eventually provided showing compliant chemical composition. Product itself good for the price point, would order again with earlier documentation request.
