| Property | Parameter | Description |
|---|---|---|
| Product Name | Shipbuilding Steel Plate | Marine-grade structural steel for vessel construction |
| Material Grade | AH32, DH32, EH32, AH36, DH36, EH36 | Classification society approved grades |
| Standard Compliance | GB/T 712, ASTM A131, EN 10025-2, JIS G3131 | Meets international shipbuilding standards |
| Carbon (C) | ≤0.18% | Controlled for weldability and toughness |
| Manganese (Mn) | 0.90-1.60% | Enhances strength and hardenability |
| Phosphorus (P) | ≤0.035% | Restricted for improved ductility |
| Sulfur (S) | ≤0.035% | Low sulfur ensures weldability |
| Silicon (Si) | 0.10-0.50% | Deoxidizer and strengthening element |
| Tensile Strength | 440-590 MPa | High strength for marine applications |
| Yield Strength | ≥315 MPa (AH32/DH32/EH32) | Minimum yield strength per classification |
| Elongation | ≥22% | Ductility in 50mm gauge length |
| Impact Energy | ≥34J at -20°C (Grade D) | Charpy V-notch impact toughness |
| Thickness Range | 6mm - 150mm | Available thickness for hull structures |
| Width Range | 1500mm - 4000mm | Standard and custom widths available |
| Length Range | 6000mm - 18000mm | Custom length cutting service |
| Surface Treatment | Shot blasting, primer coating, bare | Multiple surface finish options |
| Application | Ship hulls, offshore platforms, marine structures | Certified for critical marine environments |
| Certification | CCS, ABS, LR, DNV-GL, BV, RINA | Classification society certificates provided |
| Delivery Condition | TMCP, Normalized, As-rolled | Thermo-mechanical controlled process |
| MOQ | 10 tons | Minimum order quantity for production |
Premium Grade E Plates for LNG Carrier
Ordered 38 tons of Grade E shipbuilding steel (22mm and 28mm thickness) for LNG carrier hull construction requiring enhanced low-temperature toughness. Impact test results at -40°C showed 85 Joules average, exceeding our 27 Joules minimum requirement. Phosphorus and sulfur content were exceptionally low at 0.018% and 0.022% respectively, ensuring excellent weldability. Technical team provided welding procedure qualification support. EN 10204 3.1 certificates and third-party inspection reports were comprehensive. Delivery completed in 36 days to Santos port.
Ordered 38 tons of Grade E shipbuilding steel (22mm and 28mm thickness) for LNG carrier hull construction requiring enhanced low-temperature toughness. Impact test results at -40°C showed 85 Joules average, exceeding our 27 Joules minimum requirement. Phosphorus and sulfur content were exceptionally low at 0.018% and 0.022% respectively, ensuring excellent weldability. Technical team provided welding procedure qualification support. EN 10204 3.1 certificates and third-party inspection reports were comprehensive. Delivery completed in 36 days to Santos port.
