Corten Steel Wall Panel - Weathering Steel Exterior Cladding for Architectural Projects

Tianjin TISCO International Trade Co., Ltd.

Verified Custom manufacturer · 5 yrs ·

China

Customizable Rock-bottom price

$580 1-49 ton Base price

$555 50-99 ton 4.3% off

$540 ≥100 ton 6.9% off

Price validity: subject to market conditions

Supplier's customization ability

Drawing-based customization
Sample-based customization
Full customization

Quantity

Minimum order quantity: 1 ton

Shipping total: To be negotiated

Subtotal of goods US$ 580.00

Start order request

Payment and delivery

Payment:: by contract — deposit, balance after your inspection
Lead time:: confirmed with the quotation
Packaging:: standard export packing
Samples:: available on request

Product details

Technical Specifications of Corten Steel Wall Panel

Property	Parameter	Description
Product Name	Corten Steel Wall Panel	Weathering steel panel for architectural cladding
Material Grade	ASTM A606 Type 4 / EN 10025-5 S355J2W / Corten A/B	International weathering steel grade equivalents
Standard Compliance	ASTM A606, ASTM A588, EN 10025-5, JIS G3125	Meets major international standards
Carbon (C)	≤0.15%	Carbon content for structural strength
Chromium (Cr)	0.50-1.25%	Enhances corrosion resistance
Copper (Cu)	0.25-0.55%	Forms protective patina layer
Phosphorus (P)	0.07-0.15%	Improves atmospheric corrosion resistance
Tensile Strength	485-620 MPa	Minimum tensile strength per ASTM A606
Yield Strength	≥345 MPa	Minimum yield strength
Elongation	≥21%	Ductility in 50mm gauge length
Thickness Range	1.5mm - 12mm	Available panel thickness options
Width Range	600mm - 1500mm	Standard and custom widths
Length Range	1000mm - 6000mm or custom	Standard and custom lengths
Surface Finish	Natural rusted, Pre-weathered, Mill finish	Multiple patina finish options
Patina Formation Time	3-6 months	Time to develop stable rust layer
Corrosion Rate	4-8 times slower than carbon steel	Superior atmospheric corrosion resistance
Application	Facade cladding, landscape walls, architectural features	Typical architectural applications
Certification	EN 10204 3.1, ISO 9001, ASTM test reports	Quality certifications provided
Packaging	Wooden crates, protective film, steel strapping	Standard export packaging
MOQ	500 kg	Minimum order quantity

Corten Steel Wall Panel - Weathering Steel Exterior Cladding for Architectural Projects

Corten steel wall panel represents a premium architectural cladding solution that combines exceptional durability with distinctive aesthetic appeal. Engineered from weathering steel alloy, these panels develop a protective rust-like patina that eliminates the need for painting while providing superior resistance to atmospheric corrosion. Architects and designers specify these panels for commercial buildings, residential facades, and landscape features where both structural integrity and visual character are essential requirements.

What is Corten Steel Wall Panel?

Corten steel wall panel is a pre-fabricated cladding system manufactured from ASTM A588 or EN 10025-5 weathering steel alloy. The material contains copper, chromium, and nickel additions that enable the formation of a stable, self-protecting oxide layer when exposed to atmospheric conditions. This protective patina typically develops within 18-36 months and reaches a thickness of 50-100 micrometers, effectively preventing further corrosion penetration.

Corten Steel Wall Panel Technical Specifications

Standard panels comply with ASTM A588 Grade B specifications with minimum yield strength of 345 MPa and tensile strength of 485 MPa. Typical panel thickness ranges from 2.0mm to 6.0mm, with standard widths of 1000mm, 1200mm, and 1500mm. The chemical composition includes carbon content limited to 0.19% maximum, manganese 0.80-1.25%, phosphorus 0.04% maximum, sulfur 0.05% maximum, silicon 0.30-0.65%, copper 0.25-0.40%, chromium 0.40-0.65%, and nickel 0.40% maximum per ASTM A588 requirements.

Corten steel wall panel supplier

Why Choose Our Corten Steel Wall Panel

Our manufacturing facility operates under ISO 9001:2015 quality management certification and maintains strict dimensional tolerances of ±0.5mm for thickness and ±2mm for length. We provide mill test certificates per EN 10204 3.1 standards documenting chemical composition and mechanical properties. Each production batch undergoes salt spray testing per ASTM B117 for 1000 hours minimum to verify corrosion resistance performance. Our panels feature precision-cut edges and pre-drilled mounting holes to specification, reducing installation time by approximately 30% compared to field-fabricated alternatives.

Frequently Asked Questions

What is the minimum order quantity (MOQ)?

Our standard minimum order quantity is 500 square meters per specification. For custom sizes or thicknesses, the MOQ increases to 1000 square meters. We offer flexibility for architectural projects requiring multiple panel configurations within a single order to meet the combined minimum threshold.

Do you provide material test certificates?

Yes, we supply comprehensive mill test certificates conforming to EN 10204 3.1 standards with every shipment. Documentation includes chemical composition analysis, mechanical property test results, dimensional inspection reports, and heat number traceability. Third-party inspection services from SGS, BV, or TUV are available upon request at additional cost.

What is the typical delivery time?

Standard panel sizes maintain inventory for shipment within 7-10 working days after order confirmation. Custom-cut panels require 15-20 working days for fabrication and quality inspection. Large-scale architectural projects exceeding 5000 square meters typically require 25-30 working days to ensure proper production scheduling and quality control procedures.

Corten steel wall panel manufacturer

Can you cut to custom sizes?

Our CNC cutting equipment accommodates custom panel dimensions from 500mm to 6000mm in length and 200mm to 1500mm in width. We provide precision cutting with tolerances of ±1mm and can incorporate mounting holes, notches, or edge treatments per architectural drawings. Custom cutting services include CAD drawing review and sample panel approval before full production commences.

Corten steel wall panel China

Get a Competitive Quote for Corten Steel Wall Panel

Contact our technical sales team to receive factory-direct pricing for your architectural cladding project. We provide detailed quotations including material specifications, fabrication requirements, surface treatment options, packaging methods, and delivery schedules. Our application engineers offer complimentary design consultation to optimize panel layout and installation details for your specific building envelope requirements.
