Technical Specifications of Carbon Steel Boiler Tube

Property	Parameter	Description
Product Name	Carbon Steel Boiler Tube	Seamless carbon steel tube designed for high-pressure boiler and heat exchanger service
Material Grade	ASTM A192 / SA192	Equivalent to EN 10216-2 P235GH, JIS G3461 STB340, GB 3087 20G
Standard Compliance	ASTM A192 / ASME SA192	Also available per ASTM A178, ASTM A210, EN 10216-2, GB 3087
Carbon (C)	≤ 0.18%	Per ASTM A192 specification for low-carbon boiler grade
Manganese (Mn)	0.27 – 0.63%	Provides adequate strength and toughness
Phosphorus (P)	≤ 0.035%	Controlled to minimize brittleness
Sulfur (S)	≤ 0.035%	Low sulfur content ensures weldability and ductility
Silicon (Si)	≤ 0.25%	Acts as deoxidizer during steelmaking process
Tensile Strength	≥ 325 MPa (47 ksi)	Minimum value per ASTM A192 standard requirement
Yield Strength	≥ 180 MPa (26 ksi)	Minimum yield strength ensuring structural integrity under pressure
Elongation	≥ 35%	Measured on 50 mm gauge length, longitudinal specimen
Outer Diameter (OD)	12.7 – 114.3 mm (0.5 – 4.5 in)	Custom sizes available upon request
Wall Thickness	1.5 – 12.0 mm	Various schedules from SCH 20 to SCH 80 and above
Length	3,000 – 18,000 mm	Fixed length, random length, or cut-to-length available
Surface Finish	Black painted / Oiled / Varnished	Hot-finished or cold-drawn with smooth inner and outer surfaces
Application	Boilers, Superheaters, Heat Exchangers	Widely used in power plants, petrochemical and thermal energy systems
Certification	ISO 9001, PED 2014/68/EU, TUV, Lloyd's, BV	Mill test certificate EN 10204 3.1 / 3.2 provided with each shipment
Packaging	Bundled with steel strips, plastic caps on ends	Seaworthy wooden cases or pallets for export; custom packing available

Carbon Steel Boiler Tube - ASTM Certified Manufacturer | Kuaima Steel Group

Carbon steel boiler tube serves critical roles in power generation, petrochemical processing, and industrial heating systems where reliable performance under sustained high temperatures and pressures is non-negotiable. Manufactured to meet stringent ASTM standards including A192, A178, and A210, these seamless and welded tubes deliver the thermal conductivity, mechanical strength, and long-term durability that boiler applications demand. As a mill-direct supplier with over a decade of export experience, Kuaima Steel Group provides premium-grade carbon steel boiler tubes with full traceability, competitive mill-direct rates, and global shipping capability to clients across 40+ countries.

What Is Carbon Steel Boiler Tube?

A carbon steel boiler tube is a pressure-rated tubular product specifically engineered for conveying steam, water, or flue gases within boiler systems, heat exchangers, superheaters, and economizers. Fabricated from low-to-medium carbon steel grades such as SA192, SA210 Grade A-1, and SA178 Grade C, these tubes are designed to withstand continuous operating temperatures up to 454°C (850°F) and working pressures exceeding 6 MPa. Their carbon content typically ranges from 0.06% to 0.35%, providing an optimal balance between weldability, formability, and tensile performance. Unlike general-purpose structural tubing, boiler tubes undergo mandatory hydrostatic testing, nondestructive examination, and flattening tests to ensure leak-free integrity under cyclic thermal stress.

Carbon Steel Boiler Tube Technical Specifications

The following table outlines the key standards, dimensions, and mechanical properties available from Kuaima Steel Group:

Carbon steel boiler tube manufacturer

Parameter	Specification
Applicable Standards	ASTM A192, ASTM A178, ASTM A210, EN 10216-2, GB/T 3087
Steel Grades	SA192, SA210 Gr. A-1 / Gr. C, SA178 Gr. A / Gr. C, 20G
Outside Diameter	15.88 mm – 114.3 mm (5/8" – 4-1/2")
Wall Thickness	1.5 mm – 12.7 mm (MWT per ASTM tolerance)
Length	4,000 mm – 18,000 mm or cut-to-length
Manufacturing Process	Hot-rolled seamless / Cold-drawn seamless / ERW
Tensile Strength (SA210 Gr. A-1)	≥415 MPa (60,000 psi)
Yield Strength (SA210 Gr. A-1)	≥255 MPa (37,000 psi)
Elongation (SA210 Gr. A-1)	≥30% in 50 mm gauge length
Hydrostatic Test Pressure	Per ASTM A450, minimum 6.9 MPa (1,000 psi)
Surface Finish	Black, oiled, varnished, or galvanized per request
End Finish	Plain end, beveled, or threaded

Each tube undergoes 100% hydrostatic testing, eddy current inspection, and dimensional verification. Chemical composition is verified via optical emission spectrometry with carbon content controlled to ±0.02% tolerance, ensuring batch-to-batch consistency for critical boiler drum and waterwall applications.

Carbon steel boiler tube supplier

Key Applications of Carbon Steel Boiler Tubes

Carbon steel boiler tubes find extensive application across multiple high-demand industries:

Thermal Power Plants: Waterwall panels, superheater sections, and economizer coils operating at steam temperatures up to 450°C.
Petrochemical Refineries: Process heater tubes and waste heat recovery systems handling hydrocarbon-laden flue gases.
Industrial Boilers: Fire-tube and water-tube boilers for textile, food processing, and pharmaceutical manufacturing.
Marine Engineering: Auxiliary boiler systems aboard vessels requiring classification society approvals (Lloyd's, DNV, BV).
District Heating Systems: High-pressure hot water distribution networks in municipal infrastructure projects.

Frequently Asked Questions

What is the MOQ?

Our minimum order quantity for carbon steel boiler tubes is 5 metric tons per size and grade. For less common specifications or trial orders, we can accommodate smaller quantities of 1–2 tons subject to stock availability.

Do you provide material test certificates?

Yes, every shipment includes EN 10204 Type 3.1 Mill Test Certificates (MTC) documenting chemical composition, mechanical properties, hydrostatic test results, and nondestructive examination records. Third-party inspection by SGS, TÜV, or BV is available upon request.

What is the typical delivery time?

Standard stock sizes ship within 7–15 business days. Custom-manufactured orders, including non-standard dimensions or special heat treatment requirements, typically require 25–40 days depending on production scheduling and quantity.

Can you cut to custom sizes?

Absolutely. We offer precision cut-to-length services with a tolerance of ±3 mm, along with beveling, threading, and protective end-cap installation. Custom bundling and marking per client specifications are also available at no additional charge.

Carbon steel boiler tube factory

Get a Competitive Quote for Carbon Steel Boiler Tube

Kuaima Steel Group maintains rolling inventory of over 10,000 metric tons of carbon steel boiler tubes across all major ASTM and EN grades, enabling rapid fulfillment for urgent project timelines. Our in-house quality laboratory, ISO 9001:2015 certified management system, and dedicated export logistics team ensure that every order arrives on specification, on time, and fully documented. Contact our technical sales team today with your project specifications—including grade, dimensions, quantity, and delivery destination—to receive a detailed quotation within 24 hours.
