316L Stainless Steel plate

Feihong Steel Co., Ltd.

Verified Custom manufacturer 6yrs

316L Stainless Steel plate image thumbnail

316L Stainless Steel Plate Product Attributes

Attribute	Parameter	Description
Product Name	316L Stainless Steel Plate	Low-carbon austenitic stainless steel plate with excellent corrosion resistance, especially in chloride-rich and marine environments.
Material Grades	316L / EN 1.4404 / UNS S31603	Best suited for welded structures, marine applications, and environments where reduced carbide precipitation is essential.
Chemical Composition	Cr 16-18.5%, Ni 10-14%, Mo 2-3%, C max 0.03%, Mn ≤ 2%, Si ≤ 1%, P ≤ 0.045%, S ≤ 0.03%	Molybdenum enhances pitting and crevice corrosion resistance; low carbon minimizes intergranular corrosion after welding.
Physical Properties	Density 7.98 g/cm³, Thermal Conductivity 16 W/m·K, Coefficient of Thermal Expansion 16.8×10^-6 /K	Strong mechanical properties, good thermal stability, and excellent corrosion resistance with a decorative finish.
Thickness Range	0.5 mm – 50 mm	Suitable for a wide range of applications from thin sheets to heavy plates for structural and chemical industries.
Width Range	1000 mm – 3000 mm	Standard and custom widths to fulfill diverse fabrication and design needs.
Surface Finish	2B, BA, HL, No. 4, Mirror, Polished	Multiple options for aesthetic, hygienic, and functional purposes.
Mechanical Properties	Tensile Strength ≥ 515 MPa, Yield Strength ≥ 205 MPa, Elongation ≥ 40%, Hardness max 95 HRB	High strength combined with ductility and toughness suitable for demanding environments.
Corrosion Resistance	Superior resistance to chlorides, marine environments, and industrial chemicals	Ideal for harsh conditions such as marine, chemical, and pharmaceutical environments.
Heat Resistance	Excellent oxidation resistance up to 1,200°C	Maintains structural integrity and corrosion resistance at high temperatures.
Welding & Fabrication	Excellent weldability; post-weld heat treatment typically not required	Suitable for welded assemblies, with minimal risk of sensitization or corrosion in weld zones.
Applications	Marine structures, chemical processing, Medical equipment, Food processing, Architectural paneling	Suitable for a wide range of highly corrosive or high-temperature environments requiring reliability and longevity.
Standards	ASTM A240, EN 10088-2, JIS G4304, ISO 15510	Conforms to top international standards, ensuring high quality and safety.
Packaging	Protective stripping, pallets, packing crates	Ensures product integrity and surface protection during shipping, handling, and storage.

316L Stainless Steel Plate Product Introduction

Applications and Industry Uses

316L stainless steel plate is extensively used in chemical processing, marine environments, medical instruments, and food processing industries. Its excellent corrosion resistance, particularly against chlorides and acidic environments, makes it ideal for use in harsh and hygienic applications. The material is also widely applied in architectural projects and marine hardware, ensuring durability and longevity even in aggressive settings.

Specifications and Material Composition

316L stainless steel plate typically ranges in thickness from 0.5mm to 20mm and widths from 1000mm to 2000mm. It contains 16-18% chromium, 10-14% nickel, and 2-3% molybdenum, with carbon levels below 0.03%, enhancing weldability and reducing carbide precipitation. The plates meet ASTM A240, JIS G4304, and EN 10088 standards. Surface finishes include 2B, No.4, and BA, offering options for both functional and decorative uses.

Performance Advantages and Industry Suitability

Thanks to its low carbon content, 316L stainless steel plate resists intergranular corrosion in welded structures, making it ideal for complex fabrications requiring durability and formability. It exhibits high tensile strength (around 515 MPa), excellent elongation, and superior resistance to chloride-induced corrosion. These qualities make it a top choice for harsh environments such as chemical plants, food processing, pharmaceuticals, and marine applications, ensuring long service life and operational reliability.
