304 Stainless Steel Plate Product Attributes

Attribute	Parameter	Description
Product Name	304 Stainless Steel Plate	Austenitic stainless steel plate with excellent corrosion resistance, high strength, and good formability.
Material Grade	304 / EN 1.4301 / UNS S30400	Most widely used stainless steel grade, known for versatility across many industrial applications.
Chemical Composition	Cr 18-20%, Ni 8-10.5%, Mn ≤ 2%, C ≤ 0.08%, Si ≤ 1%, P ≤ 0.045%, S ≤ 0.03%	Balanced composition offers corrosion resistance and mechanical strength for diverse environments.
Thickness Range	0.5 mm – 120 mm	Applicable for thin sheets to heavy-duty plates used in construction, manufacturing, and architectural contexts.
Width Range	1000 mm – 3000 mm	Standard and customizable widths to suit various fabrication and assembly processes.
Length Range	2000 mm – 6000 mm	Length options provided for efficient manufacturing and usage.
Surface Finish	2B (Bright Annealed), BA (Bright Acid), NO.1 (Hot Rolled), No. 4 (Brushed), Mirror	Multiple finishes allow for aesthetic appeal and functional surface requirements.
Mechanical Properties	Tensile Strength 520-720 MPa, Yield Strength ≥ 210 MPa, Elongation ≥ 45%, Hardness ≤ 215 HB	Offers high mechanical strength, ductility, and toughness suitable for a wide range of uses.
Corrosion Resistance	Excellent resistance to atmospheric, chemical, and marine corrosion	Suitable for harsh environments including acids, chloride, and oxidizing conditions.
Heat Resistance	Continuous service up to 870°C, intermittent to 925°C	Good oxidation resistance for high-temperature applications like heat exchangers and furnace parts.
Welding & Fabrication	Excellent weldability and formability	Easily welded with minimal risk of sensitization or loss of corrosion resistance in weld zones.
Applications	Food processing, chemical industry, architectural cladding, marine equipment	Extensive use in environments requiring hygiene, corrosion resistance, and structural performance.
Standards	ASTM A240, EN 10028, ISO 15510, JIS	Conforms to international standards for quality assurance and compliance.
Packaging	Protective plastic film, wooden crates	Packaging designed to maintain surface and structural integrity during transport and storage.

304 Stainless Steel Plate Product Introduction

Versatile Applications in Industry

304 stainless steel plate is widely used in applications demanding excellent corrosion resistance and formability, such as food processing equipment, chemical containers, architectural trim, and kitchen appliances. It is particularly suitable for products requiring hygienic conditions and resistance to harsh chemicals, making it a top choice in the pharmaceutical, food, marine, and chemical industries.

Specifications and Material Composition

304 stainless steel plate is typically available in thicknesses ranging from 0.5mm to 20mm and widths between 1000mm and 2000mm. Its chemical composition includes 18-20% chromium, 8-10.5% nickel, 2% manganese, and maximum carbon content of 0.08%. The material adheres to ASTM A240, JIS G4304, and EN 10088 standards with surface finishes like 2B, No.4, and BA to suit varied manufacturing demands.

Performance Benefits and Industrial Suitability

The alloy offers excellent corrosion resistance, good tensile strength (over 515 MPa), and an elongation exceeding 40%, providing durability and flexibility in fabrication. It exhibits superior resistance against oxidation and acidic environments while being easy to weld and fabricate. These qualities make 304 stainless steel plates ideal for marine applications, food processing, chemical plants, and architectural uses requiring long-term reliability and aesthetic appeal.
