316 Stainless Steel Plate Supplier - Custom Cut to Size
China
Supplier's customization ability
- Drawing-based customization
- Sample-based customization
- Full customization
Minimum order quantity: 4 Ton
Shipping total: To be negotiated
- Lead time:
- confirmed with the quotation
- Packaging:
- standard export packing
- Samples:
- available on request
Product details
Technical Specifications of 316 Stainless Steel Plate
| Property | Parameter | Description |
|---|---|---|
| Product Name | 316 Stainless Steel Plate | Austenitic molybdenum-bearing stainless steel flat product |
| Material Grade | AISI 316 / UNS S31600 | Equivalent: EN 1.4401, JIS SUS316, GB 06Cr17Ni12Mo2 |
| Standard Compliance | ASTM A240 / ASME SA240 | Also compliant with EN 10088-2, JIS G4304, GB/T 4237 |
| Chemical Composition – C | ≤ 0.08% | Low carbon content for improved corrosion resistance |
| Chemical Composition – Cr / Ni / Mo | Cr: 16.0–18.0%, Ni: 10.0–14.0%, Mo: 2.0–3.0% | Mo addition enhances resistance to pitting and crevice corrosion |
| Chemical Composition – Mn / Si / P / S | Mn ≤ 2.0%, Si ≤ 0.75%, P ≤ 0.045%, S ≤ 0.030% | Controlled impurity levels per ASTM A240 |
| Tensile Strength | ≥ 515 MPa (75 ksi) | Minimum tensile strength per ASTM A240 for annealed condition |
| Yield Strength | ≥ 205 MPa (30 ksi) | 0.2% proof stress in annealed condition per ASTM A240 |
| Elongation | ≥ 40% | Minimum elongation in 2 inches (50 mm) gauge length |
| Hardness | ≤ 217 HB / ≤ 95 HRB | Brinell and Rockwell B hardness in annealed condition |
| Thickness Range | 1.0 mm – 100 mm | Hot rolled: 3–100 mm; Cold rolled: 1–6 mm |
| Width & Length | Width: up to 2,500 mm; Length: up to 12,000 mm | Custom cutting available; standard sheet size 1,000×2,000 mm to 1,500×6,000 mm |
| Surface Finish | No.1, 2B, 2D, BA, No.4, No.8 Mirror | 2B is most common for industrial use; No.4 for decorative applications |
| Application | Chemical processing, marine, pharmaceutical, food equipment | Ideal for chloride-rich environments, heat exchangers, pressure vessels |
| Certification | Mill Test Certificate (MTC) per EN 10204 3.1 / 3.2 | Third-party inspection available (SGS, BV, TÜV) |
| Packaging | Wooden pallet with waterproof paper or steel strip bundling | Export seaworthy packaging; fumigation certificate available on request |
| MOQ | 1 Ton | Mixed specifications accepted; spot stock available for standard sizes |
316 Stainless Steel Plate
316 stainless steel plate is one of the most widely specified austenitic stainless steel products in industrial procurement, valued for its exceptional corrosion resistance, mechanical strength, and long service life across demanding environments. Whether you require standard mill dimensions or custom cut-to-size processing, our supply chain delivers consistent quality backed by full material traceability and certified test reports.
What Makes 316 Stainless Steel Plate the Preferred Choice?
The defining characteristic of 316 stainless steel plate lies in its molybdenum content — typically 2% to 3% — which significantly enhances resistance to pitting and crevice corrosion, particularly in chloride-rich environments such as seawater, brine solutions, and coastal industrial facilities. Compared to standard 304 grade, 316 offers measurably superior performance in acidic and saline conditions, making it the material of choice for engineers who cannot afford premature failure.
Key mechanical properties include:
- Tensile Strength: ≥515 MPa (75 ksi)
- Yield Strength: ≥205 MPa (30 ksi)
- Elongation: ≥40%
- Hardness (Brinell): ≤217 HB
- Operating Temperature: Up to 870°C (1600°F) in continuous service
Specifications and Available Dimensions
Our 316 stainless steel plate inventory covers a broad dimensional range to support diverse fabrication and structural requirements. Standard stock and custom processing options include:
- Thickness: 1.5 mm – 100 mm (and beyond for heavy plate)
- Width: Up to 2,500 mm
- Length: Up to 6,000 mm, or custom cut lengths
- Surface Finish: No.1 (hot rolled), No.2B (cold rolled), No.4 (brushed), BA (mirror), and PVC-coated
- Standards: ASTM A240, EN 10088-2, JIS G4304/G4305
- Grade Variants: 316, 316L (low carbon), 316H (high carbon for elevated temperature), 316Ti (titanium-stabilized)
All plates are supplied with mill test certificates (MTC) in accordance with EN 10204 3.1 or 3.2 upon request, ensuring full compliance with international procurement standards.
Industry Applications of 316 Stainless Steel Plate
The versatility of 316 stainless steel plate makes it indispensable across a wide range of sectors:
- Marine and Offshore: Vessel hulls, deck fittings, subsea equipment, and offshore platform components where saltwater exposure is constant
- Chemical Processing: Reactor vessels, storage tanks, heat exchangers, and piping systems handling aggressive acids and solvents
- Food and Beverage: Processing equipment, storage vats, conveyor components, and hygienic surfaces requiring frequent washdowns
- Pharmaceutical: Cleanroom equipment, bioreactors, and sterile processing environments demanding high purity and corrosion resistance
- Architecture and Construction: Cladding panels, structural supports, and decorative facades in coastal or urban pollution-heavy locations
- Oil and Gas: Wellhead components, manifolds, and process equipment exposed to H₂S and CO₂ environments
Custom Cut-to-Size 316 Stainless Steel Plate Processing
Beyond standard plate supply, we provide value-added processing services to reduce lead times and fabrication costs for your project. Available services include plasma cutting, waterjet cutting, laser cutting, shearing, grinding, and edge beveling. Tight tolerances are maintained across all cutting methods, and each processed piece is individually identified and traceable to its source coil or slab.
For high-volume OEM customers and engineering contractors, we offer blanket order programs with scheduled releases, ensuring material availability aligns with your production schedule without excess inventory carrying costs.
Why Source Your 316 Stainless Steel Plate From Us?
As a specialized stainless steel plate supplier, we combine mill-direct sourcing with in-house processing capabilities to deliver competitive pricing, short lead times, and consistent quality. Our quality management system is ISO 9001 certified, and our technical team is available to assist with grade selection, specification review, and application engineering support. Whether your requirement is a single sheet or a multi-ton project order, we are equipped to respond with precision and reliability.
Contact our sales team today to request a quotation, review current stock availability, or discuss custom processing requirements for your next project involving 316 stainless steel plate.
