| Property | Parameter | Description |
|---|---|---|
| Product Name | Stainless Steel Angle | L-shaped structural section with equal or unequal legs |
| Material Grade | 304 / 316 / 316L / 2205 / EN 1.4301 / 1.4404 / 1.4462 | International grade equivalents for corrosion resistance and strength |
| Standard Compliance | ASTM A554, ASTM A580, EN 10088-2, JIS G4303, GB/T 2101 | Meets major international standards for stainless steel structural sections |
| Carbon Content (C) | 304: ≤0.08%; 316L: ≤0.03%; 2205: ≤0.03% | Low carbon enhances weldability and intergranular corrosion resistance |
| Chromium (Cr) | 304: 18.0–20.0%; 316: 16.0–18.0%; 2205: 22.0–23.0% | Primary element for passive oxide layer formation |
| Nickel (Ni) | 304: 8.0–10.5%; 316: 10.0–14.0%; 2205: 4.5–6.5% | Stabilizes austenitic structure; improves toughness and ductility |
| Molybdenum (Mo) | 304: –; 316/316L: 2.0–3.0%; 2205: 3.0–3.5% | Enhances pitting and crevice corrosion resistance |
| Tensile Strength | 304: ≥515 MPa; 316: ≥515 MPa; 2205: ≥620 MPa | Minimum tensile strength per ASTM A554/A580 |
| Yield Strength | 304: ≥205 MPa; 316: ≥205 MPa; 2205: ≥450 MPa | Minimum 0.2% offset yield strength |
| Elongation | ≥30% (50mm gauge length) | Ductility requirement for structural integrity |
| Leg Dimensions | 20×20 mm to 200×200 mm (equal); up to 200×125 mm (unequal) | Standard metric sizes; custom dimensions available |
| Thickness Range | 3 mm – 25 mm | Wall thickness options for load-bearing applications |
| Length | 6m, 7m, 12m or cut-to-length | Standard mill lengths with precision cutting capability |
| Surface Finish | No.1, 2B, BA, Pickled, Shot Blasted | Options for aesthetic, functional, or post-processing requirements |
| Application | Architectural framing, chemical plant structures, marine platforms, food processing equipment | Typical industrial and infrastructure use cases |
| Certification | EN 10204 3.1, ISO 9001, MTC (Mill Test Certificate) | Traceable quality documentation per order |
| Packaging | Steel-banded bundles, waterproof wrapping, corner protectors | Export-grade protection against transit damage and corrosion |
| MOQ | 1 ton (minimum order quantity) | Flexible for sample orders and large-volume procurement |
Acceptable Quality with Minor Issues Resolved
Decent product quality overall, with one issue that was resolved. We ordered 7.4 tons of 304 stainless steel angle (45×45×4 mm, equal-leg, cut to 1,800 mm) for HVAC duct supports in Houston. Upon receipt, 5 pieces (out of 1,024) showed minor surface scratches near cut ends — likely from handling during plasma profiling. The scratches were superficial (<0.05 mm depth) but unacceptable for our visible interior application. To their credit, the supplier responded within 18 hours, issued a full replacement set with upgraded edge protection, and added a 2% goodwill credit. Overall acceptable. For aesthetic applications, suggest requesting additional end-cap protection and specifying 'scratch-free handling' in purchase order notes.
