| Property | Parameter | Description |
|---|---|---|
| Product Name | Stainless Steel Coil | Continuous rolled stainless steel strip in coil form |
| Material Grade | 304 / 316L / 430 / 2205 / EN 1.4301 / 1.4404 / 1.4016 / 1.4462 | Multi-standard grade equivalents for global compliance |
| Standard Compliance | ASTM A240, EN 10088-2, JIS G4303, GB/T 4237 | Meets major international stainless steel flat product standards |
| Carbon Content (C) | 304: ≤0.08%; 316L: ≤0.03%; 430: ≤0.12%; 2205: ≤0.03% | Low-carbon variants ensure optimal weldability and corrosion resistance |
| Chromium (Cr) | 304: 18.0–20.0%; 316L: 16.0–18.0%; 430: 16.0–18.0%; 2205: 21.0–23.0% | Primary element for passive oxide layer formation |
| Nickel (Ni) | 304: 8.0–10.5%; 316L: 10.0–14.0%; 430: ≤0.75%; 2205: 4.5–6.5% | Austenite stabilizer; enhances ductility and toughness |
| Molybdenum (Mo) | 304: –; 316L: 2.0–3.0%; 2205: 2.5–3.5% | Critical for pitting and crevice corrosion resistance |
| Tensile Strength | 304: ≥515 MPa; 316L: ≥480 MPa; 430: ≥450 MPa; 2205: ≥620 MPa | Minimum guaranteed tensile strength per ASTM A240 |
| Yield Strength | 304: ≥205 MPa; 316L: ≥170 MPa; 430: ≥205 MPa; 2205: ≥450 MPa | 0.2% offset yield strength at room temperature |
| Elongation | 304/316L: ≥40%; 430: ≥22%; 2205: ≥25% | Ductility measured on 50 mm gauge length |
| Thickness Range | 0.1 mm – 6.0 mm | Standard cold-rolled and hot-rolled coil thickness options |
| Width Range | 600 mm – 2000 mm | Custom widths available per customer requirement |
| Surface Finish | 2B, BA, No.1, No.4, HL, Mirror, Embossed | Multiple mill finishes for functional and aesthetic applications |
| Application | Automotive, Construction, Appliance, Chemical, Food Processing, Architectural | Industry-specific use cases aligned with material performance |
| Certification | EN 10204 3.1, ISO 9001, MTC, Third-party inspection (SGS/BV) | Traceable quality documentation for export and OEM compliance |
| Packaging | Wooden pallets, waterproof paper, plastic film, edge protectors, steel strapping | Export-grade packaging to prevent moisture and mechanical damage |
| MOQ | 1 ton (varies by grade and specification) | Minimum order quantity for standard stock items |
Acceptable Quality 304 Coil with Thickness Variation Resolved
Decent product quality overall, with one issue that was resolved. We noticed thickness variation up to ±0.027 mm on 4 coils out of a 14-ton order (0.8 mm × 1350 mm, 2B finish), exceeding the ±0.02 mm tolerance. The supplier acknowledged the variance, shared root-cause analysis (roll wear calibration), and offered a 3% credit plus priority recalibration for our next order. They also added real-time thickness monitoring data to future certs. Overall acceptable. For precision deep-drawing applications, recommend verifying thickness sampling before full production use.
Decent product quality overall, with one issue that was resolved. We noticed thickness variation up to ±0.027 mm on 4 coils out of a 14-ton order (0.8 mm × 1350 mm, 2B finish), exceeding the ±0.02 mm tolerance. The supplier acknowledged the variance, shared root-cause analysis (roll wear calibration), and offered a 3% credit plus priority recalibration for our next order. They also added real-time thickness monitoring data to future certs. Overall acceptable. For precision deep-drawing applications, recommend verifying thickness sampling before full production use.
