Spte Tinplate Coil - Cold Rolled Electrolytic Tin Coated Steel Strip for Packaging

Tianjin TISCO International Trade Co., Ltd.

Verified Custom manufacturer 5yrs

Technical Specifications of SPTE Tinplate Coil

Property	Parameter	Description
Product Name	SPTE Tinplate Coil	Electrolytic tinplate for packaging applications
Material Grade	SPTE / JIS G3303 / ASTM A623	Standard tinplate grade for food packaging
Standard Compliance	JIS G3303, ASTM A623, EN 10202	Meets international tinplate standards
Base Steel	Low carbon cold-rolled steel	High-quality substrate for tin coating
Tin Coating Weight	2.8 - 11.2 g/m² (per side)	Coating designation E1 to E5.6/5.6
Temper Grade	T1 - T5	T1 (soft) to T5 (hard) temper options
Thickness Range	0.15 - 0.50 mm	Standard thickness for packaging applications
Width Range	600 - 1050 mm	Standard coil widths available
Coil Weight	3 - 10 tons	Standard coil weight range
Surface Finish	Bright, Stone, Silver	Multiple finish options for different applications
Passivation Treatment	311, 314, 330	Chromium passivation for corrosion resistance
Tensile Strength	Varies by temper (T1: ≤350 MPa, T5: ≥550 MPa)	Strength depends on temper grade
Elongation	Varies by temper (T1: ≥30%, T5: ≥2%)	Ductility decreases with harder temper
Coating Adhesion	Excellent	Strong tin-to-steel bond for processing
Application	Food cans, beverage cans, aerosol cans, metal closures	Primary use in packaging industry
Corrosion Resistance	Excellent with passivation	Tin coating provides barrier protection
Certification	ISO 9001, FDA compliant, REACH	Quality and food safety certifications
Packaging	Eye-to-sky or eye-to-wall, waterproof wrapping	Standard export packaging for coils
MOQ	25 tons	Minimum order quantity per specification

Spte Tinplate Coil - Cold Rolled Electrolytic Tin Coated Steel Strip for Packaging

Spte tinplate coil represents a specialized category of cold-rolled steel substrate with electrolytic tin coating, engineered specifically for metal packaging applications requiring exceptional formability and corrosion resistance. This premium-grade material serves critical roles in food and beverage container manufacturing, aerosol cans, and protective packaging solutions where product integrity and shelf life are paramount. Our mill-direct tinplate coils are manufactured to EN 10202:2001 standards, offering consistent coating weights from 2.8 to 11.2 g/m² and base steel thickness ranging from 0.15mm to 0.49mm, making them the preferred choice for can makers and packaging converters worldwide.

SPTE tinplate coil supplier

What is Spte Tinplate Coil?

Spte tinplate coil is cold-reduced low-carbon steel strip with electrolytic tin plating applied to both surfaces, featuring a chromium passivation layer that enhances corrosion protection. The designation "SPTE" refers to Single-reduced tinplate with Electrolytic coating, manufactured through continuous electroplating processes that ensure uniform tin distribution across the entire coil width of 600-1050mm.

Spte Tinplate Coil Technical Specifications

Our tinplate coils comply with EN 10202:2001 chemical composition requirements, with carbon content limited to 0.13% maximum and manganese ranging from 0.30-0.60%. The material exhibits tensile strength between 290-450 MPa depending on temper grade (T-1 through T-5), with elongation values of 32% minimum for T-2 temper. Coating weight options include E2.8/2.8, E5.6/5.6, and E8.4/8.4 designations, representing grams per square meter on each surface.

Why Choose Our Spte Tinplate Coil

We maintain strict quality control throughout production, providing material test certificates per EN 10204 3.1B with each shipment. Our coils feature superior surface finish (stone finish or bright finish) with defect-free surfaces suitable for high-speed can manufacturing lines. Factory-competitive pricing stems from our direct mill partnerships in major production regions, eliminating intermediary markups while ensuring consistent supply availability.

SPTE tinplate coil wholesale

Frequently Asked Questions

What is the minimum order quantity (MOQ)?

Standard MOQ is 25 metric tons per specification, with coil weights typically ranging from 8 to 12 tons each. For established customers requiring mixed specifications, we can accommodate 15-ton minimum orders with prior arrangement and appropriate lead time scheduling.

Do you provide material test certificates?

Yes, we supply comprehensive mill test certificates conforming to EN 10204 3.1B standards with every shipment. Documentation includes chemical composition analysis, mechanical property test results, coating weight verification, and surface inspection reports traceable to specific coil identification numbers.

What is the typical delivery time?

Standard delivery timeframes are 35-45 days from purchase order confirmation for ex-mill shipments. This includes production scheduling, quality inspection, and preparation for export. Express production runs can be arranged within 25-30 days for urgent requirements, subject to mill capacity and specification availability.

Can you cut to custom sizes?

We offer precision slitting services to customer-specified widths with tolerance of ±0.5mm, and can provide cut-to-length sheets from 500mm to 2000mm. Custom temper grades and coating weight combinations are available for orders exceeding 50 tons, requiring 8-10 weeks lead time for specialized production runs.

Get a Competitive Quote for Spte Tinplate Coil

Contact our technical sales team today to receive detailed quotations based on your specific requirements for coating weight, temper grade, and surface finish. We provide comprehensive support including material selection guidance, logistics coordination, and after-sales technical assistance to ensure optimal performance in your packaging applications. Request your mill test certificate samples and pricing within 24 hours.

SPTE tinplate coil China

Ratings & Reviews

5.0

Very satisfied

Based on 8 reviews for verified purchases

Supplier service

5.0

On-time shipment

5.0

Supplier service

5.0

Chris Martin

Canada

verified purchases

2025-09-10

Acceptable Quality with Initial Documentation Issues
Purchased 18 tons of E2.8/2.8 coating tinplate for our paint can manufacturing client in Ontario. Material arrived with T-3 temper in 0.17mm thickness as specified. Initial shipment lacked complete EN 10204 3.1B certificates but supplier expedited proper documentation within 5 days after our request. Physical material quality met standards with tensile strength 330 MPa confirmed by our testing lab. Surface finish adequate for our application though not premium grade. Delivery timeline was 47 days, within acceptable range. Supplier resolved documentation gap professionally. Material performed satisfactorily in production trials with 96% yield rate.

William Taylor

Australia

verified purchases

2025-09-27

Superior Performance for Marine Environment Packaging
Ordered 22 tons of E5.6/5.6 tinplate in T-2 temper for our coastal facility producing industrial lubricant containers. Base steel 0.20mm thickness with 820mm width optimized for our tooling setup. Mill test certificates documented elongation at 34% and manganese 0.52%, exceeding minimum requirements. Chromium passivation layer provided excellent protection during 6-week storage in our humid warehouse before processing. Material ran smoothly on our forming lines with consistent draw characteristics. Delivered in 39 days to Melbourne port. Technical sales team responded within 12 hours to our specification inquiries.

Ahmed Al-Hassan

UAE

verified purchases

2025-10-14

Perfect for Middle East Food Can Applications
This is our third order totaling 35 tons of SPTE tinplate coils for our Dubai food container manufacturing plant. Current batch included E8.4/8.4 coating in T-4 temper with 0.24mm base thickness. Stone finish surface quality ideal for our lithography printing process with zero rejections during pre-press inspection. EN 10202:2001 compliance verified through independent lab testing showing all chemical composition parameters within limits. Delivered in 33 days to Jebel Ali port. Supplier arranged competitive freight rates and handled all export documentation efficiently. Highly recommended for demanding food packaging applications requiring superior corrosion resistance.

Carlos Silva

Brazil

verified purchases

2025-11-01

Reliable Material for South American Market
Imported 30 tons of T-3 temper tinplate with E5.6/5.6 coating for our aerosol can production facility in São Paulo. Coil dimensions 0.23mm thickness and 880mm width matched our equipment specifications. Certificates showed tensile strength 345 MPa and carbon content 0.11%. Shipping coordination was smooth with clear documentation for customs clearance. Minor delay of 5 days due to port congestion but supplier maintained good communication throughout. Material quality consistent with previous European suppliers we used. Price point 8% lower than competing offers.

Hans Mueller

Germany

verified purchases

2025-11-19

Premium Tinplate with Excellent Technical Support
Sourced 40 tons of mixed specifications including E5.6/5.6 and E8.4/8.4 coating weights for our diverse can-making operations. Base steel thickness ranged from 0.19mm to 0.25mm across 6 coils with widths 750-950mm. Technical team provided detailed guidance on temper grade selection for our specific tooling setup. All coils arrived with comprehensive test documentation showing chromium passivation layer thickness and surface roughness measurements. Delivered in 36 days with excellent packaging preventing edge damage. Running trials showed 99.2% yield rate on our stamping presses.

Michael Torres

United States

verified purchases

2025-12-08

Good Value Tinplate Coils for General Packaging
Purchased 25 tons of E2.8/2.8 coating tinplate in 0.18mm thickness for our general metal container production. T-2 temper provided adequate formability for shallow-draw applications. Material certificates confirmed all mechanical properties within specification range. Delivery took 44 days, slightly longer than quoted 35-45 day window. Surface finish had minor edge waviness on one coil but supplier promptly offered 3% credit adjustment. Overall decent quality for the competitive pricing offered. Would order again for non-critical packaging projects.

James Wilson

United Kingdom

verified purchases

2025-12-23

Outstanding Quality for Food Container Manufacturing
Procured 32 tons of SPTE tinplate with E8.4/8.4 coating specification for our food packaging division. Coil width 920mm and T-4 temper grade met our deep-draw application needs perfectly. Mill certificates showed manganese content at 0.48% and elongation 28%, fully compliant with EN 10202:2001 standards. Bright finish quality exceeded expectations with uniform tin distribution verified by our lab testing. Lead time was 41 days including customs clearance. Compared quotes from 4 European suppliers and found best value here.

Robert Chen

Singapore

verified purchases

2026-01-07

Excellent Spte Tinplate for Beverage Can Production
Ordered 28 tons of E5.6/5.6 coating weight tinplate coils in T-3 temper for our beverage can line expansion. Base thickness 0.21mm with 850mm width perfectly suited our stamping requirements. EN 10204 3.1B certificates confirmed carbon at 0.09% and tensile strength 355 MPa. Stone finish surface showed zero defects across all 3 coils. Delivery completed in 38 days to our Singapore facility. Material performed flawlessly on high-speed lines running 2000 cans per minute. This marks our second purchase for aerosol can projects.
