Prime Galvanized Steel Coil - ASTM A653, Z275 Coating, 0.12-2.0mm Thickness

Technical Specifications of Prime Galvanized Steel Coil

Prime Galvanized Steel Coil - ASTM A653, Z275 Coating, 0.12-2.0mm Thickness

Prime galvanized steel coil represents a premium-grade flat-rolled steel product featuring a protective zinc coating applied through continuous hot-dip galvanizing processes. Engineered to deliver exceptional corrosion resistance and extended service life, this material serves critical roles in construction, automotive manufacturing, appliance production, and industrial fabrication. Our prime galvanized steel coils comply with ASTM A653/A653M-20 standards, offering Z275 coating mass (275 g/m² total both sides) and thickness ranges from 0.12mm to 2.0mm, making them the preferred choice for demanding applications requiring both structural integrity and long-term durability in corrosive environments.

What is Prime Galvanized Steel Coil?

Prime galvanized steel coil is cold-rolled or hot-rolled steel substrate that has undergone continuous hot-dip galvanizing, where the steel passes through a molten zinc bath at approximately 450°C, forming a metallurgically bonded zinc-iron alloy layer. The "prime" designation indicates first-quality material with consistent coating thickness, superior surface finish, and full compliance with specified mechanical properties per ASTM A653 Grade 33 (minimum yield strength 228 MPa).

Prime Galvanized Steel Coil Technical Specifications

Our prime galvanized steel coils are manufactured according to ASTM A653/A653M-20 Section 6, featuring base metal thickness tolerance of ±0.02mm for material under 0.5mm and ±0.04mm for 0.5-2.0mm range. Zinc coating designation Z275 provides 275 g/m² total coating mass (approximately 39 μm per side) measured per ASTM A90 triple-spot test method, ensuring uniform corrosion protection with minimum coating adherence meeting bend test requirements of 180° over 1T radius without flaking.

Why Choose Our Prime Galvanized Steel Coil

We maintain ISO 9001:2015 certified production facilities with advanced Sendzimir galvanizing lines capable of processing widths from 600mm to 1,500mm with precise tension control systems ensuring flatness within I-unit 8 per ASTM A1030. Our mill-direct supply chain eliminates intermediary markups, offering cost-effective solutions with batch traceability, full material test reports per EN 10204 3.1 certification, and technical support for application-specific requirements including custom slitting, cut-to-length processing, and surface treatment options.

Frequently Asked Questions

What is the minimum order quantity (MOQ)?

Our standard MOQ is 25 metric tons per specification (thickness, width, coating grade combination). For trial orders or sample evaluation, we accommodate reduced quantities of 5-10 tons with adjusted pricing. Mixed container loading is available for established customers requiring multiple specifications within a single shipment.

Do you provide material test certificates?

Yes, every coil shipment includes EN 10204 Type 3.1 mill test certificates documenting chemical composition per heat analysis, mechanical properties (yield strength, tensile strength, elongation), coating mass measurements, and surface quality inspection results. Additional third-party inspection certificates from SGS, BV, or Intertek can be arranged upon request.

What is the typical delivery time?

For standard specifications (Z275 coating, 0.3-1.2mm thickness, 1000-1250mm width), delivery time ranges from 15-20 days from order confirmation for in-stock material. Custom specifications requiring production scheduling typically require 25-35 days, depending on mill capacity and order volume. Expedited processing is available for urgent requirements with applicable surcharges.

Can you cut to custom sizes?

Our processing center offers precision slitting services with width tolerance ±1.0mm for slit widths 100mm and above, edge burr controlled under 30 μm. Cut-to-length processing provides sheet lengths from 1000mm to 6000mm with squareness tolerance ±2.0mm per meter. Blanking and custom shearing services are available for high-volume orders with dedicated tooling setup.

Get a Competitive Quote for Prime Galvanized Steel Coil

Request your detailed quotation today by providing specifications including required thickness, width, coating designation, quantity, and delivery destination. Our technical sales team responds within 4 business hours with mill-direct pricing, material availability confirmation, and logistics coordination. Contact us for volume discounts, long-term supply agreements, and value-added processing solutions tailored to your manufacturing requirements.
