| Property | Parameter | Description |
|---|---|---|
| Product Name | Galvanized Steel | Carbon steel coated with zinc layer for corrosion protection, distributed in coil, sheet, and strip forms |
| Material Grade | DX51D / SGCC / S250GD / CS Type B | International equivalents: DX51D (EN 10346), SGCC (JIS G3302), S250GD (EN 10346), CS Type B (ASTM A653) |
| Standard Compliance | ASTM A653 / EN 10346 / JIS G3302 / GB/T 2518 | Hot-dip galvanized steel sheet and coil standards covering mechanical properties and coating requirements |
| Chemical Composition (C) | ≤ 0.12% | Low carbon content ensures good formability and weldability |
| Chemical Composition (Mn) | ≤ 0.60% | Manganese content for structural integrity |
| Chemical Composition (P / S) | P ≤ 0.10% / S ≤ 0.045% | Controlled phosphorus and sulfur for improved ductility and surface quality |
| Tensile Strength | 270–550 MPa | Varies by grade; e.g., DX51D ≥ 270 MPa, S350GD ≥ 420 MPa per EN 10346 |
| Yield Strength | 140–420 MPa | Minimum yield strength depending on grade; S250GD ≥ 250 MPa per EN 10346 |
| Elongation | ≥ 22% | Minimum elongation at fracture (A80mm) for standard commercial grades per EN 10346 |
| Zinc Coating Weight | Z60–Z275 (g/m²) / G30–G90 (oz/ft²) | Coating designation per EN/ASTM; Z275 = 275 g/m² total both sides; heavier coatings for harsh environments |
| Thickness Range | 0.12 mm – 6.00 mm | Available in various gauges; standard commercial range 0.3–3.0 mm for coil and sheet supply |
| Width Range | 600 mm – 1,500 mm | Slit coil and full-width coil available; custom slit widths upon request |
| Surface Finish | Regular Spangle / Minimized Spangle / Zero Spangle / Skin-passed | Surface options to suit painting, forming, or exposed applications; chromate or phosphate passivation available |
| Application | Construction, Automotive, HVAC, Agriculture, Electrical Enclosures | Roofing, wall cladding, structural framing, ductwork, appliance panels, and general fabrication |
| Certification | ISO 9001 / Mill Test Certificate (EN 10204 3.1) / RoHS | Third-party mill certificates provided; RoHS compliance for restricted substances in applicable markets |
| Packaging | Coil / Sheet / Slit Strip | Coils wrapped with waterproof paper and steel banding; sheets bundled on wooden pallets; export seaworthy packing available |
| MOQ | 5 Metric Tons (coil) / 1 Metric Ton (sheet) | Minimum order quantities vary by distributor; mixed grades and sizes accepted for full container load orders |
Initial coating weight variance issue — resolved satisfactorily
Our first order of 50 tons ASTM A653 G60 galvanized coil, 0.60mm, showed coating weight readings slightly below the 60 g/m² minimum on three coils out of twelve, flagged by our incoming QC. We raised this immediately with the distributor. To their credit, they arranged a third-party re-test within 48 hours, confirmed the variance, and replaced the three affected coils at no cost within 10 days. The replacement material was fully compliant. Communication during the resolution was transparent. We've since placed a follow-up order and quality has been correct. Cautiously optimistic going forward.
Our first order of 50 tons ASTM A653 G60 galvanized coil, 0.60mm, showed coating weight readings slightly below the 60 g/m² minimum on three coils out of twelve, flagged by our incoming QC. We raised this immediately with the distributor. To their credit, they arranged a third-party re-test within 48 hours, confirmed the variance, and replaced the three affected coils at no cost within 10 days. The replacement material was fully compliant. Communication during the resolution was transparent. We've since placed a follow-up order and quality has been correct. Cautiously optimistic going forward.
