| Property | Parameter | Description |
|---|---|---|
| Product Name | GL Steel Coil (Galvalume Steel Coil) | Aluminum-zinc alloy coated steel for superior corrosion resistance |
| Coating Composition | 55% Aluminum, 43.4% Zinc, 1.6% Silicon | AZ coating provides excellent heat and corrosion resistance |
| Standard Compliance | ASTM A792, EN 10215, JIS G3321 | Meets major international standards for metallic-coated steel |
| Base Metal | Cold Rolled Steel / Hot Rolled Steel | Carbon steel substrate with structural grade quality |
| Coating Mass | AZ50 to AZ185 (50-185 g/m²) | Common coating weights per ASTM A792 |
| Thickness Range | 0.12 - 2.0 mm | Available thickness options for various applications |
| Width Range | 600 - 1500 mm | Standard coil widths, custom sizes available |
| Coil ID | 508 mm / 610 mm | Inner diameter options for processing equipment |
| Coil Weight | 3 - 8 tons | Standard coil weight range |
| Tensile Strength | ≥270 MPa (Grade 33) | Minimum tensile strength per ASTM A792 |
| Yield Strength | ≥230 MPa | Minimum yield strength for structural applications |
| Elongation | ≥20% | Ductility in standard gauge length |
| Surface Treatment | Regular Spangle, Minimized Spangle, Skin Pass | Multiple surface finish options available |
| Heat Resistance | Up to 315°C | Excellent performance in high-temperature environments |
| Corrosion Resistance | 2-6 times better than galvanized steel | Superior protection in coastal and industrial atmospheres |
| Application | Roofing, Construction, Appliances, Automotive | Widely used in building and manufacturing industries |
| Certification | ISO 9001, EN 10204 3.1, SGS | Quality certifications provided with mill test certificate |
| Packaging | Waterproof paper, steel strapping, wooden pallet | Standard export seaworthy packaging |
| MOQ | 25 tons | Minimum order quantity per specification |
Premium GL Coil for Structural Applications
Supplied 35 tons of GL steel coil (0.9mm thickness, 1250mm width, Z225 coating) for our agricultural building frames project. Material exhibited excellent weldability using MAG welding process with minimal spatter. Zinc coating remained intact 15mm from weld seam. Mechanical properties consistent across entire order with elongation at 38-42%. Their metallurgical team provided welding parameter recommendations that reduced our defect rate by 60%. Cut-to-length service accuracy was within ±1.5mm tolerance.
