| Property | Parameter | Description |
|---|---|---|
| Product Name | Galvanized Steel for Industrial Construction | Hot-dip or electro-galvanized steel products for structural and industrial use |
| Material Grade | DX51D / S250GD / S350GD (EN); ASTM A653 CS / SS Grade 33–80; GB/T 2518 DX51D+Z | Equivalent grades available per regional standards; high-strength grades for load-bearing applications |
| Standard Compliance | ASTM A653/A653M, EN 10346, JIS G3302, GB/T 2518 | Meets international structural and coating quality requirements |
| Chemical Composition | C ≤ 0.12%, Mn ≤ 0.60%, P ≤ 0.10%, S ≤ 0.045%, Si ≤ 0.50% | Low-carbon steel base; composition varies by grade per applicable standard |
| Tensile Strength | 270–560 MPa (grade-dependent) | DX51D: ≥270 MPa; S350GD: ≥420 MPa per EN 10346; ASTM A653 SS Grade 50: ≥448 MPa |
| Yield Strength | 140–500 MPa | S250GD: ≥250 MPa; S350GD: ≥350 MPa; suitable for structural framing and industrial frameworks |
| Elongation | ≥14%–30% (A80mm) | Higher elongation for forming grades (DX51D); structural grades per EN 10346 Table 4 |
| Zinc Coating Weight | Z60–Z600 (g/m²); ZF60–ZF180 (galvannealed) | Coating designation per EN 10346 / ASTM A653; heavier coatings for harsh industrial environments |
| Coating Thickness | 8–85 µm per side (approx.) | Z275 (~19.5 µm/side) standard for construction; Z600 for heavy corrosion protection |
| Thickness Range | 0.3–6.0 mm | Coils and sheets; thicker gauges available for structural purlins, decking, and framing |
| Width Range | 600–1,500 mm | Custom slit widths available; standard coil widths per customer specification |
| Length / Coil Weight | Sheets: 1,000–6,000 mm; Coils: 3–15 MT | Cut-to-length sheets or full coils; inner diameter 508/610 mm |
| Surface Finish | Regular Spangle, Minimized Spangle, Zero Spangle, Skin-passed, Chromate/Oiled | Surface treatment selected based on painting, forming, or exposed structural requirements |
| Application | Structural framing, roofing, wall cladding, purlins, HVAC ducts, storage racks, industrial buildings | Widely used in pre-engineered buildings, warehouses, factories, and infrastructure projects |
| Certification | ISO 9001, CE Marking (EN 1090), Mill Test Certificate (EN 10204 3.1/3.2) | Third-party inspection available; SGS/BV/TÜV reports upon request |
| Packaging | Coils: steel-banded with waterproof paper and steel outer wrap; Sheets: bundled with steel strapping | Export seaworthy packaging; palletized sheets available for container loading |
| MOQ | 25 MT per order (coils); 5 MT (cut-to-length sheets) | Mixed grades and specifications accepted; trial orders negotiable |
Initial documentation gap resolved — material quality is solid
First order of 18 tonnes EN 10346 S280GD, 1.8 mm, Z275 coating for bridge walkway components in Dubai. The steel itself performed well — coating weight and tensile strength both within spec. However, the initial shipment was missing the third-party inspection certificate we had agreed upon, which caused a two-day hold at customs. After raising the issue, the supplier provided the correct documentation within 24 hours and followed up to ensure clearance. Problem was resolved professionally. Material is now installed and performing as expected. Would order again with clearer pre-shipment document checklist.
First order of 18 tonnes EN 10346 S280GD, 1.8 mm, Z275 coating for bridge walkway components in Dubai. The steel itself performed well — coating weight and tensile strength both within spec. However, the initial shipment was missing the third-party inspection certificate we had agreed upon, which caused a two-day hold at customs. After raising the issue, the supplier provided the correct documentation within 24 hours and followed up to ensure clearance. Problem was resolved professionally. Material is now installed and performing as expected. Would order again with clearer pre-shipment document checklist.
