Corten Steel Plate 20mm - Weathering Steel Sheet ASTM A588 Grade A

Tianjin TISCO International Trade Co., Ltd.

Verified Custom manufacturer 5yrs

Technical Specifications of Corten Steel Plate 20mm

Property	Parameter	Description
Product Name	Corten Steel Plate 20mm	Weathering steel plate with atmospheric corrosion resistance
Material Grade	ASTM A588 / EN 10155 S355J2W / JIS G3114 SMA490AW	International grade equivalents for weathering steel
Standard Compliance	ASTM A588, EN 10155, JIS G3114	Meets major international weathering steel standards
Thickness	20mm	Standard thickness specification
Carbon (C)	≤0.19%	Carbon content for structural strength
Chromium (Cr)	0.40-0.65%	Enhances corrosion resistance
Copper (Cu)	0.25-0.40%	Forms protective patina layer
Nickel (Ni)	0.40% max	Improves atmospheric corrosion resistance
Phosphorus (P)	0.07-0.15%	Strengthens protective oxide layer
Tensile Strength	≥485 MPa	Minimum tensile strength per ASTM A588
Yield Strength	≥345 MPa	Minimum yield strength for structural applications
Elongation	≥21%	Ductility in 50mm gauge length
Width Range	1000-3000mm	Standard and custom widths available
Surface Finish	Hot Rolled, Pickled, Pre-rusted	Multiple surface treatment options
Application	Bridges, Buildings, Outdoor Sculpture, Containers	Typical application in corrosive environments
Corrosion Resistance	4-8 times carbon steel	Superior atmospheric corrosion resistance
Certification	EN 10204 3.1, ISO 9001, ASTM	Quality certifications provided
Packaging	Steel strapping, waterproof cover, wooden pallet	Standard export packaging
MOQ	5 tons	Minimum order quantity

Corten Steel Plate 20mm - Weathering Steel Sheet ASTM A588 Grade A

Corten steel plate 20mm represents a specialized weathering steel solution engineered for structural applications requiring exceptional atmospheric corrosion resistance without protective coatings. This premium-grade material develops a stable, protective rust patina that eliminates the need for painting while delivering superior mechanical properties. Manufactured to ASTM A588 specifications, our 20mm thickness weathering steel plates serve critical roles in bridge construction, architectural facades, railway infrastructure, and outdoor sculptural installations where long-term durability and distinctive aesthetics are paramount.

What is Corten Steel Plate 20mm?

Corten steel plate 20mm is a high-strength, low-alloy structural steel with enhanced atmospheric corrosion resistance achieved through precise copper, chromium, and nickel alloying. The 20mm thickness specification provides optimal structural capacity for medium to heavy-duty applications while maintaining excellent formability and welding characteristics per AWS D1.1 standards.

Corten Steel Plate 20mm Technical Specifications

Our weathering steel plates comply with ASTM A588/A588M-19 Grade A requirements, featuring minimum yield strength of 345 MPa and tensile strength ranging from 485-620 MPa. Chemical composition includes carbon content limited to 0.19% maximum, manganese 0.80-1.25%, phosphorus 0.04% maximum, sulfur 0.05% maximum, silicon 0.30-0.65%, copper 0.25-0.40%, chromium 0.40-0.65%, and nickel 0.40% maximum, ensuring predictable weathering behavior and structural integrity.

Corten steel plate 20mm supplier

Why Choose Our Corten Steel Plate 20mm?

We provide mill-direct pricing on certified ASTM A588 weathering steel with complete material traceability and third-party test reports. Our inventory includes plasma-cut custom sizes, shot-blasted surface preparation options, and expedited delivery for projects requiring immediate material availability. Every plate undergoes ultrasonic testing per ASTM A435 to guarantee internal soundness for welded fabrications.

Frequently Asked Questions

What is the minimum order quantity (MOQ)?

Our standard MOQ for 20mm Corten steel plate is 5 metric tons per specification. For custom plasma-cut pieces, we accommodate orders starting at 1 metric ton with dimensional tolerances of ±3mm on length and width per ASTM A6 requirements.

Do you provide material test certificates?

Yes, every shipment includes EN 10204 Type 3.1 mill test certificates documenting chemical analysis, mechanical properties, heat number traceability, and compliance with ASTM A588 Grade A specifications. Additional certifications such as NACE MR0175 or CE marking are available upon request.

What is the typical delivery time?

Stock sizes ship within 5-7 business days from our distribution centers. Custom plasma-cut plates require 12-15 business days for processing, while special surface treatments like shot blasting add 3-5 additional days. Expedited production is available for critical path projects with surcharges.

Corten steel plate 20mm wholesale

Can you cut to custom sizes?

Our CNC plasma cutting capabilities handle plates up to 3000mm x 12000mm with cutting tolerances of ±2mm. We provide beveled edges for weld preparation at angles from 15° to 45° per your fabrication drawings. Nesting optimization reduces material waste for complex part geometries.

Get a Competitive Quote for Corten Steel Plate 20mm

Contact our technical sales team today for factory-direct pricing on ASTM A588 weathering steel plates. We provide same-day quotations with detailed weight calculations, cutting layouts, and logistics planning. Our metallurgical specialists offer complimentary application engineering support to optimize material selection for your specific environmental exposure conditions and structural loading requirements.

Corten steel plate 20mm China
