| Property | Parameter | Description |
|---|---|---|
| Product Name | Galvanized Steel Coil | Hot-dipped zinc coated steel coil for corrosion protection |
| Material Grade | SGCC, DX51D, S280GD, S350GD | International grade equivalents per ASTM A653, EN 10346 |
| Standard Compliance | ASTM A653, EN 10346, JIS G3302, GB/T 2518 | Meets major international galvanizing standards |
| Zinc Coating Weight | 60-275 g/m² | Total both sides, Z60 to Z275 coating designation |
| Coating Type | Hot-dipped galvanized (GI) | Continuous hot-dip galvanizing process |
| Base Steel Grade | Commercial, Structural, HSLA | Various substrate strength levels available |
| Tensile Strength | 270-550 MPa | Depends on base steel grade specification |
| Yield Strength | 140-420 MPa | Minimum yield strength per grade |
| Elongation | ≥20% | Ductility in 50mm gauge length |
| Thickness Range | 0.12 - 4.0 mm | Available thickness options for various applications |
| Width Range | 600 - 1500 mm | Standard coil widths, custom sizes available |
| Coil Weight | 3 - 10 tons | Standard coil weight range |
| Surface Treatment | Regular spangle, minimized spangle, zero spangle | Multiple surface finish options |
| Application | Roofing, construction, automotive, appliances | Corrosion-resistant applications across industries |
| Corrosion Resistance | Excellent outdoor durability | Zinc coating provides sacrificial protection |
| Certification | EN 10204 3.1, ISO 9001, SGS | Quality certifications and mill test reports provided |
| Packaging | Steel strapping, waterproof paper, wooden pallet | Standard export seaworthy packaging |
| MOQ | 25 tons | Minimum order quantity per specification |
Procured 25 tons of galvanized steel coil (1.8mm thickness, Z275 coating, minimized spangle) for marine equipment enclosures in Brisbane. Material demonstrated excellent corrosion resistance during our 720-hour salt spray testing, showing minimal red rust formation. Mechanical properties included 340 MPa tensile strength and 18% elongation. Supplier provided detailed technical data sheets and processing recommendations. Cut-to-length service delivered sheets within ±5mm tolerance. This is our fourth order over 18 months. Highly recommended for harsh coastal applications.
