Electrolytic Galvanized Steel Strip - Cold-Rolled, ASTM A653, Z100 Coating

Tianjin TISCO International Trade Co., Ltd.

Verified Custom manufacturer 5yrs

Electrolytic galvanized steel strip image thumbnail

Electrolytic galvanized steel strip image

Technical Specifications of Electrolytic Galvanized Steel Strip

Property	Parameter	Description
Product Name	Electrolytic Galvanized Steel Strip	Cold-rolled steel with electrolytic zinc coating
Base Material	SPCC / SPCD / Q195 / Q235	Cold-rolled carbon steel substrate
Manufacturing Process	Electrolytic galvanizing (electroplating)	Zinc deposited via electrochemical process
Standard Compliance	ASTM A879, JIS G3313, EN 10152	Meets international coating standards
Zinc Coating Weight	20-100 g/m² (per side)	Total coating: 40-200 g/m² (both sides)
Coating Thickness	2.8-14 μm (per side)	Thinner than hot-dip galvanizing
Tensile Strength	270-500 MPa	Depends on base material grade
Yield Strength	≥140-280 MPa	Varies with substrate specification
Elongation	≥20-35%	Ductility in 50mm gauge length
Thickness Range	0.15-3.0 mm	Precision thickness tolerance ±0.02mm
Width Range	20-1250 mm	Standard and custom slit widths
Surface Finish	Bright, smooth, uniform	Superior surface quality for painting
Coating Appearance	No spangle, matte finish	Uniform zinc layer without crystal pattern
Corrosion Resistance	240-480 hours (salt spray test)	Per ASTM B117, depends on coating weight
Phosphate Treatment	Optional chromate/phosphate passivation	Enhances paint adhesion and corrosion resistance
Application	Automotive parts, electronics, appliances	Precision stamping and deep drawing applications
Certification	ISO 9001, EN 10204 3.1, RoHS	Quality and environmental compliance
Packaging	Eye-to-wall or eye-to-sky, waterproof wrap	Standard export coil packaging
MOQ	5 tons	Minimum order quantity per specification

Electrolytic Galvanized Steel Strip - Cold-Rolled, ASTM A653, Z100 Coating

Electrolytic galvanized steel strip represents a precision-engineered cold-rolled product featuring a thin, uniform zinc coating applied through electroplating processes. This specialized steel strip serves critical roles in automotive components, electrical enclosures, and precision stamping applications where controlled coating thickness and superior surface finish are paramount. Manufactured to meet ASTM A653 specifications with Z100 coating designation, this material delivers exceptional formability combined with cost-effective corrosion protection for manufacturers requiring tight dimensional tolerances.

What is Electrolytic Galvanized Steel Strip?

Electrolytic galvanized steel strip is cold-rolled low-carbon steel substrate coated with a zinc layer through electrochemical deposition, typically ranging from 7.5 to 15 microns per side. Unlike hot-dip galvanizing, the electrolytic process produces remarkably uniform coating thickness with minimal spangle formation, making it the preferred choice for applications demanding consistent paintability and welding characteristics.

Electrolytic Galvanized Steel Strip Technical Specifications

Our electrolytic galvanized steel strip complies with ASTM A653/A653M-20 standards, featuring substrate thickness from 0.15mm to 3.0mm and width capabilities up to 1,250mm. The Z100 coating designation provides 100 g/m² total zinc mass (both sides), equivalent to approximately 7 microns per surface. Chemical composition maintains carbon content below 0.12% maximum, with manganese ranging 0.25-0.60% and phosphorus limited to 0.035% per ASTM requirements, ensuring optimal cold-forming properties.

Electrolytic galvanized steel strip supplier

Why Choose Our Electrolytic Galvanized Steel Strip

We maintain mill-direct partnerships with ISO 9001:2015 certified producers, ensuring factory-competitive pricing without compromising material integrity. Our electrolytic galvanized steel strip undergoes rigorous quality verification including coating weight testing per ASTM A90, adhesion testing conforming to ASTM B571, and dimensional inspection traceable to NIST standards. Every coil ships with complete mill test certificates documenting chemical analysis, mechanical properties, and coating specifications.

Electrolytic galvanized steel strip wholesale

Frequently Asked Questions

What is the minimum order quantity (MOQ)?

Our standard MOQ for electrolytic galvanized steel strip is 5 metric tons per specification. For high-volume contracts exceeding 50 tons monthly, we offer flexible scheduling and consignment inventory programs. Mixed-specification orders are accommodated with 10-ton minimum combined weight.

Do you provide material test certificates?

Yes, every shipment includes EN 10204 Type 3.1 mill test certificates signed by both manufacturer and independent inspection agency. Documentation details chemical composition per heat analysis, tensile properties, coating weight verification, and dimensional measurements. Additional third-party testing through SGS or Bureau Veritas can be arranged upon request.

What is the typical delivery time?

Standard lead time for in-stock specifications ranges 7-10 business days from order confirmation to departure from our warehouse. Custom thickness or width requirements necessitate 4-6 weeks for mill production scheduling. Expedited processing is available for urgent requirements, with partial shipments released as production completes.

Can you cut to custom sizes?

Our precision slitting capabilities accommodate width tolerances of ±0.5mm for strips 25mm to 1,220mm wide. Coil ID options include 508mm and 610mm to match your decoiling equipment. Cut-to-length services provide sheets from 500mm to 6,000mm with squareness tolerance within 2mm per meter. Edge conditioning options include deburred, rounded, or square-cut profiles.

Get a Competitive Quote for Electrolytic Galvanized Steel Strip

Request your detailed quotation today by providing target specifications including thickness, width, coating weight, and monthly volume requirements. Our technical sales team responds within 4 business hours with mill-direct pricing, material availability, and delivery scheduling options. Contact us now to discuss how our electrolytic galvanized steel strip solutions can optimize your manufacturing efficiency while reducing material costs.

Electrolytic galvanized steel strip China

Ratings & Reviews

5.0

Very satisfied

Based on 8 reviews for verified purchases

Supplier service

5.0

On-time shipment

5.0

Supplier service

5.0

Robert Brown

United Kingdom

verified purchases

2025-08-17

Premium Strip for Precision Stamping Operations
Supplied 9 tons of 0.4mm ultra-thin electrolytic galvanized strip for automotive sensor housings. Thickness tolerance held to ±0.02mm across entire 25-ton coil weight. Z100 coating provided 7.2 microns per side verified by our X-ray fluorescence testing. Carbon content at 0.08% delivered exceptional deep-draw characteristics through our 150-ton progressive dies. Custom slit to 380mm width with deburred edges - no tool damage after 50,000 stamping cycles. Technical support provided FEA recommendations for our complex forming geometry.

William Taylor

Australia

verified purchases

2025-09-05

Acceptable Quality with Initial Delivery Delay
Ordered 5 tons of 1.5mm electrolytic galvanized strip for marine equipment brackets. Material specifications met ASTM A653 requirements with proper documentation. Initial delivery was delayed by 8 days due to logistics issues, but supplier maintained communication and offered partial shipment option. Coating adhesion tested satisfactory per ASTM B571. Tensile properties at 320 MPa matched our requirements for cold forming operations. Issue was resolved professionally with expedited freight at no additional cost. Material performance has been adequate for our application.

Ahmed Al-Hassan

UAE

verified purchases

2025-09-30

Outstanding Service and Documentation
This is our fourth order - 15 tons of mixed specifications including 0.5mm, 0.8mm, and 1.0mm thickness for steel door frame production. Every coil arrived with detailed mill test certificates traceable to heat numbers. Sales engineer visited our Dubai facility to review forming parameters. Coating weight consistency across all three gauges maintained 98-103 g/m² range. Packaging was excellent with VCI paper and waterproof wrapping suitable for our outdoor storage. Delivery coordination was professional with 2-day advance shipping notice.

Carlos Silva

Brazil

verified purchases

2025-10-20

Reliable Material for HVAC Ductwork
Purchased 7 tons of 0.7mm electrolytic galvanized strip for ventilation duct manufacturing. ASTM A653 certification provided with complete chemical analysis showing manganese at 0.42%. Formability was good through our roll-forming lines. Coating uniformity acceptable though noticed slight variation at coil edges within 20mm. Lead time was 13 days including customs clearance to São Paulo. Price point reasonable for South American market. Would order again for standard ductwork projects.

Wei Chen

Singapore

verified purchases

2025-11-10

Perfect Surface Finish for Paint Applications
Supplied 10 tons of 1.0mm Z100 electrolytic galvanized strip to our furniture manufacturing client. Surface roughness measurements averaged Ra 0.6μm, ideal for their pre-painted steel requirements. Phosphorus content at 0.028% ensured excellent paint adhesion during their conversion coating process. Customer reported zero rejection rate through 5000-piece production run. Sales team responded within 3 hours with technical data sheets and coating weight distribution charts.

Hans Mueller

Germany

verified purchases

2025-12-02

Good Quality Strip at Competitive Pricing
Ordered 6 tons of 0.6mm electrolytic galvanized strip for appliance component manufacturing. Material quality meets specifications with coating weight at 98 g/m². Compared quotes from 4 European suppliers - pricing was 8% lower while maintaining ISO certification. Delivery took 11 days, slightly longer than promised 10 days. Slitting tolerance held to ±0.4mm for our 450mm width requirement. Minor edge burring required additional deburring step. Overall solid value for volume production.

Michael Johnson

United States

verified purchases

2025-12-23

Superior Weldability for Electrical Enclosures
Purchased 12 tons of 1.2mm x 1000mm electrolytic galvanized steel strip for control panel enclosures. ASTM A653 compliance verified through EN 10204 3.1 certificates. Welding characteristics were outstanding compared to hot-dip material we previously used - minimal spatter and clean seams with our resistance welding equipment. Technical team provided detailed forming recommendations. This is our second order in 3 months. Highly recommend for precision electrical applications.

James Wilson

United Kingdom

verified purchases

2026-01-07

Excellent Coating Uniformity for Automotive Stamping
Ordered 8 tons of 0.8mm thickness electrolytic galvanized strip with Z100 coating for automotive bracket production. Mill certificates confirmed zinc coating at 102 g/m² total, carbon content 0.09%. Surface finish was exceptionally uniform with minimal spangle, perfect for our powder coating line. Coating adhesion passed our internal bend testing without flaking. Delivered in 9 days to our Birmingham facility. Material performed flawlessly through progressive dies with no cracking issues.
