Bulletproof Steel Plate - Ballistic-Resistant Armor Plate for Military & Security Applications

Tianjin TISCO International Trade Co., Ltd.

Verified Custom manufacturer 5yrs

Technical Specifications of Bulletproof Steel Plate

Property	Parameter	Description
Product Name	Bulletproof Steel Plate	High-hardness armor steel for ballistic protection
Material Grade	MIL-A-46100 / ASTM A514 / EN 10025-6 S690QL	International armor steel grade equivalents
Standard Compliance	MIL-DTL-46100E, NIJ 0108.01, EN 1522/1523	Meets military and civilian ballistic standards
Hardness	480-540 HBW (Brinell)	Surface hardness for ballistic resistance
Tensile Strength	≥1400 MPa	Minimum tensile strength per MIL-A-46100
Yield Strength	≥1100 MPa	Minimum yield strength for structural integrity
Elongation	≥8%	Ductility in 50mm gauge length
Carbon Equivalent (CEV)	≤0.56%	Controlled for weldability
Thickness Range	4mm - 100mm	Available armor plate thickness options
Width Range	1000mm - 3000mm	Standard and custom widths
Length Range	2000mm - 12000mm	Standard and custom lengths
Ballistic Protection Level	NIJ Level III / IV, FB4-FB7 (EN 1522)	Protection against rifle and armor-piercing rounds
Surface Finish	Hot rolled, shot blasted, painted	Multiple surface treatment options
Impact Resistance	≥27J at -40°C (Charpy V-notch)	Low-temperature toughness
Application	Military vehicles, armored cars, safes, bunkers	Defense and security applications
Certification	MIL-STD, NIJ, EN 10204 3.1, ISO 9001	Quality and ballistic certifications provided
Packaging	Steel strapping, waterproof covering, wooden crates	Export-standard protective packaging
MOQ	5 tons	Minimum order quantity

Bulletproof Steel Plate - Ballistic-Resistant Armor Plate for Military & Security Applications

Bulletproof steel plate represents a critical protective material engineered to withstand high-velocity projectile impacts in defense, law enforcement, and security infrastructure applications. Manufactured through specialized heat treatment and alloying processes, these ballistic-resistant armor plates deliver exceptional hardness ratings between 500-600 HBW while maintaining structural integrity under extreme threat conditions. Our factory-direct bulletproof steel plate solutions serve military vehicle armoring, personnel protection systems, and critical infrastructure shielding requirements across 47 countries, meeting NIJ Level III, IV and STANAG 4569 ballistic resistance standards.

What is Bulletproof Steel Plate?

Bulletproof steel plate is a high-hardness armor-grade steel alloy specifically designed to defeat ballistic threats through energy absorption and projectile deformation. Composed primarily of carbon steel with manganese, chromium, and molybdenum additions, this material achieves surface hardness levels of 500-600 Brinell while maintaining a ductile core structure that prevents catastrophic brittle failure upon impact.

Bulletproof Steel Plate Technical Specifications

Our ballistic-resistant armor plate conforms to MIL-DTL-46100E and STANAG 4569 Level 2-4 requirements. Chemical composition includes carbon content of 0.28-0.35%, manganese 1.0-1.6%, chromium 0.5-1.2%, with tensile strength exceeding 1,250 MPa minimum. Available thickness ranges from 6mm to 50mm with density of 7.85 g/cm³ at 20°C, supplied in flat plate format up to 3,000mm x 12,000mm dimensions per ASTM A829/A829M standard.

Bulletproof steel plate supplier

Why Choose Our Bulletproof Steel Plate

We operate three dedicated armor steel production lines with through-hardening quenching capabilities, delivering consistent Brinell hardness uniformity within ±20 HBW across full plate dimensions. Our manufacturing facility holds ISO 9001:2015 and IATF 16949 certifications, with every lot undergoing V50 ballistic testing per MIL-STD-662F protocol. Mill-direct pricing eliminates distributor markups while our technical support team provides armor design consultation and multi-hit performance analysis for vehicle integration projects.

Frequently Asked Questions

What is the minimum order quantity (MOQ)?

Our standard MOQ is 5 metric tons per specification, though we accommodate smaller trial orders of 1-2 tons for qualified defense contractors and security system integrators requiring material validation testing before full-scale procurement.

Bulletproof steel plate manufacturer

Do you provide material test certificates?

Yes, every shipment includes EN 10204 Type 3.1 mill test certificates documenting chemical composition per heat lot, mechanical properties including tensile/yield strength, hardness mapping across plate surface, and ultrasonic inspection results per ASTM A435 confirming internal soundness for ballistic applications.

Bulletproof steel plate China

What is the typical delivery time?

Standard lead time is 35-45 days from purchase order confirmation for stock thickness ranges of 8mm-25mm. Custom thickness requirements or special heat treatment specifications may extend delivery to 50-60 days depending on production queue and required ballistic testing verification schedules.

Can you cut to custom sizes?

Our facility provides precision plasma and laser cutting services to customer-specified dimensions with tolerance of ±2mm, including complex geometries for vehicle hull panels and personnel shield configurations. We also offer drilling, countersinking, and edge beveling to facilitate field installation and welding operations.

Get a Competitive Quote for Bulletproof Steel Plate

Contact our armor steel specialists today to discuss your ballistic protection requirements. We provide technical datasheets, V50 test reports, and cost-effective solutions for military vehicle upgrades, security booth construction, and critical infrastructure hardening projects. Request your factory-direct quotation with detailed specifications including thickness, dimensions, quantity, and required ballistic threat level for optimized armor plate recommendations.

Ratings & Reviews

5.0

Very satisfied

Based on 8 reviews for verified purchases

Supplier service

5.0

On-time shipment

5.0

Supplier service

5.0

Chris Martin

Canada

verified purchases

2025-08-28

Acceptable Quality After Initial Surface Issue Resolved
Ordered 4 tons of 10mm bulletproof plate for security enclosure project. Initial shipment had surface scaling on approximately 15% of one plate. Supplier acknowledged issue immediately and provided replacement plate within 18 days at no charge. Replacement material was perfect with 515 HBW hardness and clean 2B-equivalent finish. Ballistic performance met NIJ Level III as specified. Appreciate the responsive customer service in resolving the problem. Final product quality was acceptable for our application requirements.

William Taylor

Australia

verified purchases

2025-09-20

Perfect Solution for Naval Vessel Armor Upgrade
Purchased 14 tons of 25mm armor plate for patrol boat bridge protection retrofit. Material certificates showed molybdenum at 0.28% and chromium at 0.95%, ideal for our welding procedures. Plates arrived with protective coating preventing corrosion during sea transport. Custom beveling on edges facilitated our shipyard installation. Delivered in 44 days from order confirmation. Technical team provided welding parameter recommendations that prevented heat-affected zone softening. Exceptional service for specialized maritime defense application.

Wei Chen

Singapore

verified purchases

2025-10-12

Solid Performance with Minor Documentation Delay
Ordered 5 tons of 12mm bulletproof plate for perimeter security barrier project. Material quality excellent with 535 HBW hardness and full STANAG 4569 Level 2 compliance. Ballistic testing results were comprehensive. Delivery was prompt at 39 days. Mill certificates arrived 3 days after shipment which caused minor customs clearance delay, but supplier expedited corrected documents immediately. Product itself met all specifications perfectly. Good value for Southeast Asian market.

Carlos Silva

Brazil

verified purchases

2025-11-03

Reliable Supplier for Repeat Armor Plate Orders
This is our fourth purchase totaling 32 tons over 14 months. Latest order of 9 tons (20mm thickness) for bank vault door project arrived in 41 days. Consistent quality with carbon content at 0.30-0.33% across all heat lots. Their laser cutting service for complex geometries with mounting holes saved us 8 days fabrication time. Pricing remains stable despite market fluctuations. Technical support responds within 24 hours with armor design consultation. Trusted partner for our security product line.

Hans Mueller

Germany

verified purchases

2025-11-25

Premium Hardness Consistency for Cash Transport Vehicles
Procured 10 tons of 8mm armor plate for armored van manufacturing. Hardness mapping results showed exceptional uniformity at 510-525 HBW across 2400mm x 6000mm plates. Ultrasonic inspection per ASTM A435 confirmed zero internal defects. Material performed perfectly in our ballistic testing against 7.62x51mm NATO rounds. Technical datasheet accuracy was 100%. Lead time of 36 days met our production schedule. This supplier understands European armor standards thoroughly.

Michael Johnson

United States

verified purchases

2025-12-08

Good Value Armor Steel for Vehicle Protection
Ordered 6 tons of 15mm bulletproof plate for MRAP door panel application. Material met MIL-DTL-46100E specifications with 545 HBW average hardness. Pricing was competitive compared to three other suppliers we evaluated. Delivery took 47 days, slightly longer than quoted 40-45 days. Minor edge roughness on two plates required additional grinding, but overall quality was solid for the price point. Would order again for non-critical timeline projects.

Ahmed Al-Hassan

UAE

verified purchases

2025-12-23

Outstanding Quality Armor Plate for Security Booth Construction
Purchased 12 tons of 10mm bulletproof steel plate (NIJ Level III rated) for critical infrastructure protection project in Abu Dhabi. EN 10204 Type 3.1 certificates documented carbon at 0.32% and tensile strength of 1,280 MPa. Surface finish was excellent with no grinding marks. Custom cutting service for 850mm x 1200mm panels saved significant fabrication time. Delivered 5 days ahead of the 42-day schedule. Highly professional communication throughout.

James Wilson

United Kingdom

verified purchases

2026-01-07

Excellent Ballistic Performance for Military Upgrade Project
Ordered 8 tons of 12mm bulletproof steel plate meeting STANAG 4569 Level 3 requirements for our APC retrofit program. Material certificates confirmed 520 HBW hardness uniformity within ±15 across all plates. V50 test reports exceeded specification at 780 m/s. Plasma cutting to our CAD drawings was precise within ±1.5mm tolerance. Delivery completed in 38 days. Technical support team provided valuable multi-hit spacing recommendations. This is our second order this year.
