Precision Steel Tube Suppliers - Custom Sizes Available

Kuaima Steel Co., Ltd.

Verified Custom manufacturer 7yrs

Precision steel tube suppliers image thumbnail

Technical Specifications of Precision Steel Tubes

Property	Parameter	Description
Product Name	Precision Steel Tube	Cold-drawn seamless tube with tight dimensional tolerances
Material Grade	E235 / E355 / ST52 / AISI 1020 / AISI 1045	Multiple carbon steel grades available
Standard Compliance	EN 10305-1, DIN 2391, ASTM A519, ISO 8535	Meets major international precision tube standards
Manufacturing Process	Cold Drawn Seamless (CDS) / Cold Pilgered	Ensures superior surface finish and dimensional accuracy
Carbon (C)	0.10 - 0.50%	Varies by grade, controls strength and hardness
Manganese (Mn)	0.30 - 1.60%	Improves hardenability and tensile strength
Phosphorus (P)	≤0.025%	Controlled for improved ductility
Sulfur (S)	≤0.025%	Low sulfur for enhanced machinability and weldability
Tensile Strength	340 - 800 MPa	Depends on material grade and heat treatment
Yield Strength	215 - 580 MPa	Minimum yield strength per applicable standard
Elongation	≥10 - 30%	Ductility varies by grade and wall thickness
OD Range	4mm - 120mm	Outer diameter tolerance up to ±0.05mm
Wall Thickness	0.5mm - 20mm	Wall thickness tolerance up to ±0.025mm
Surface Finish	Bright Annealed, Phosphated, Honed, Chrome Plated	Multiple surface treatment options for precision applications
Length	Up to 12m or custom cut	Fixed length and random length available
Application	Hydraulic systems, automotive, pneumatic cylinders, instrumentation	Typical high-precision application industries
Certification	EN 10204 3.1, ISO 9001, IATF 16949	Quality certifications provided with each shipment
Packaging	Bundled with VCI paper, plastic caps, wooden cases	Standard export packaging to prevent corrosion
MOQ	500 kg	Minimum order quantity for standard sizes

Precision Steel Tube Suppliers - Custom Sizes Available

Choosing the right precision steel tube suppliers is critical for industries that demand tight dimensional tolerances, superior surface finish, and consistent mechanical properties. Precision steel tubes serve as essential components in hydraulic systems, automotive assemblies, instrumentation lines, and mechanical engineering applications where standard tubing simply cannot meet the required accuracy. As a mill-direct supplier with over 15 years of export experience, we deliver cold-drawn and cold-rolled precision tubes manufactured according to EN 10305, ASTM A519, and DIN 2391 standards to clients across 40+ countries.

What Is Precision Steel Tube?

A precision steel tube is a seamless or welded-and-drawn tubular product manufactured through cold drawing or cold pilgering processes to achieve tight dimensional tolerances—typically ±0.05 mm on outer diameter and ±0.025 mm on wall thickness. Unlike hot-finished tubes, precision tubes undergo multiple reduction passes followed by bright annealing, resulting in a smooth internal and external surface with Ra values as low as 0.4 µm.

Precision Steel Tube Technical Specifications

Our precision tubing covers a comprehensive range of grades and dimensions to meet diverse engineering requirements:

Parameter	Range / Value
Outer Diameter	6 mm – 120 mm
Wall Thickness	0.5 mm – 12 mm
Length	Up to 12,000 mm (custom cut available)
Tolerances (OD)	±0.05 mm per EN 10305-1:2016
Surface Finish	Ra ≤ 0.8 µm (bright annealed)
Steel Grades	E235, E355, St35, St52, 20#, 45#, SAE 1020, SAE 1045
Standards	EN 10305-1/2/4, DIN 2391, ASTM A519, JIS G3441

Tensile strength ranges from 340 MPa for E235 grade to 640 MPa minimum for E355, with elongation values of 25% and 22% respectively as specified in EN 10305-1:2016 Annex A.

Key Applications for Precision Tubing

Hydraulic & pneumatic cylinders: Cold-drawn tubes with H8–H9 bore tolerance for piston and cylinder barrel assemblies
Automotive drivetrain: Propeller shafts, shock absorber tubes, and fuel injection lines requiring concentricity within 0.1 mm TIR
Instrumentation & control: Small-diameter tubes for pressure gauges, heat exchangers, and sensor housings
Mechanical engineering: Bearing sleeves, roller shafts, and linear guide components demanding superior roundness

Why Partner with Our Precision Steel Tube Supply Team

We operate dedicated cold-drawing lines with online eddy current and ultrasonic testing per EN 10893-8, ensuring zero-defect delivery. Every production lot ships with EN 10204 3.1 mill test certificates covering chemical composition, mechanical properties, and dimensional inspection reports. Our in-house CNC cutting center handles precision cutting to ±0.5 mm length tolerance, eliminating the need for secondary processing at your facility.

Frequently Asked Questions

What is the minimum order quantity (MOQ)?

Our standard MOQ starts at 500 kg per size and grade combination. For trial orders or prototype projects, we accommodate quantities as low as 200 kg with a small-lot processing surcharge.

Precision steel tube manufacturer

Do you provide material test certificates?

Yes. Every shipment includes EN 10204 Type 3.1 inspection certificates issued by our quality department, covering chemical analysis per heat and mechanical test results per lot. Third-party certificates from SGS or TÜV are available upon request.

What is the typical delivery time?

Stock items in common grades (E235, E355) ship within 7–10 working days. Custom-manufactured precision tubes with non-standard dimensions or special grades require 25–35 working days from order confirmation.

Precision steel tube wholesale

Can you cut to custom sizes?

Absolutely. Our CNC precision sawing equipment delivers burr-free cuts to lengths from 50 mm to 12,000 mm with a tolerance of ±0.5 mm. Deburring, chamfering, and end-facing services are also available as value-added processing options.

Precision steel tube China

Get a Competitive Quote for Precision Steel Tubes

Ready to source precision steel tubes with factory-competitive pricing and reliable lead times? Share your specifications—including grade, dimensions, tolerances, and annual volume—and our technical sales team will respond with a detailed quotation within 24 hours. Contact us today to experience the difference that a dedicated precision steel tube supplier delivers to your supply chain.
