| Property | Parameter | Description |
|---|---|---|
| Product Name | Construction Engineering Steel Tube | Structural steel tube for construction and civil engineering applications |
| Material Grade | Q235B / Q355B / S355JR | Carbon structural steel and low-alloy high-strength steel grades |
| Size Range (OD) | 21.3 mm – 914 mm | Outer diameter range covering standard construction specifications |
| Wall Thickness | 1.5 mm – 50 mm | Available in light, medium, and heavy wall thickness options |
| Length | 6 m – 12 m (custom available) | Standard mill lengths; cut-to-length service supported |
| Yield Strength | ≥ 235 MPa – 355 MPa | Minimum yield strength depending on material grade selected |
| Tensile Strength | 370 MPa – 630 MPa | Ultimate tensile strength per standard test requirements |
| Elongation | ≥ 20% | Minimum elongation at fracture ensuring ductility |
| Surface Treatment | Black / Galvanized / Painted / Epoxy Coated | Anti-corrosion treatment options for various site environments |
| Tube Type | Seamless / ERW Welded / LSAW / SSAW | Manufacturing process selected based on pressure and load requirements |
| Straightness Tolerance | ≤ 1.5 mm / m | Maximum allowable bow per meter of tube length |
| Packaging | Bundle (1,000 – 3,000 kg) / Bare / Wooden crate | Standard export bundling with steel strapping and end caps |
| Storage Conditions | Dry, covered warehouse; humidity ≤ 70% | Avoid direct contact with ground; use wooden or rubber supports |
| Application | Scaffolding, pile foundation, structural frame, formwork support | Widely used in building, bridge, tunnel, and infrastructure projects |
| Certification | ISO 9001 / CE / GB/T 8162 / EN 10210 | Quality management and product standard certifications |
| MOQ | 5 tons | Minimum order quantity per specification or grade |
| Supply Capacity | 5,000 tons / month | Monthly production and delivery capacity from mill stock |
Initial surface finish issue on galvanized tubes — resolved satisfactorily
Ordered 45 tons of hot-dip galvanized round steel tubes, 76.1mm OD x 4mm wall, AS/NZS 1163 equivalent grade, for outdoor structural framing in Queensland. On arrival, roughly 8% of the tubes in one bundle showed uneven zinc coating thickness below the 85 micron minimum we specified. Raised the issue with the supplier immediately — they responded within 24 hours, accepted the quality claim, and arranged a partial credit plus priority replacement shipment for the affected quantity, which arrived within 15 days. Issue was handled professionally. Will give them another chance on the next order.
