Prime Prepainted Galvanized Steel Coils - High-Quality PPGI Coils for Construction

Tianjin TISCO International Trade Co., Ltd.

Verified Custom manufacturer 5yrs

Prime prepainted galvanized steel coils image thumbnail

Prime prepainted galvanized steel coils image

Technical Specifications of Prime Prepainted Galvanized Steel Coils

Property	Parameter	Description
Product Name	Prime Prepainted Galvanized Steel Coils	Color-coated galvanized steel with organic coating
Material Grade	CGCC, DX51D+Z, ASTM A653, JIS G3312	International grade equivalents for prepainted steel
Standard Compliance	ASTM A755, EN 10169, JIS G3312, GB/T 12754	Meets major international coating standards
Base Metal	Galvanized Steel (GI) / Galvalume (GL)	Hot-dip zinc or aluminum-zinc coated substrate
Zinc Coating Weight	60-275 g/m²	Both sides total coating weight
Coating Type	Polyester (PE), Silicon Modified Polyester (SMP), PVDF	Multiple organic coating options
Coating Thickness	Top: 15-25 μm, Back: 5-10 μm	Standard coating thickness range
Yield Strength	≥205-550 MPa	Depends on base metal grade
Tensile Strength	≥270-600 MPa	Minimum tensile strength per standards
Elongation	≥20%	Ductility in standard test
Thickness Range	0.12 - 1.5 mm	Available substrate thickness
Width Range	600 - 1500 mm	Standard coil widths
Coil ID	508 mm / 610 mm	Inner diameter options
Color Options	RAL, Pantone color system	Customizable colors available
Surface Finish	Glossy, Matte, Wrinkle, Embossed	Multiple surface texture options
Application	Roofing, wall cladding, appliances, construction	Typical application industries
Certification	ISO 9001, EN 10204 3.1, SGS	Quality certifications provided
Packaging	Waterproof paper, steel strapping, wooden pallet	Standard export packaging
MOQ	25 tons	Minimum order quantity per color

Prime Prepainted Galvanized Steel Coils - High-Quality PPGI Coils for Construction

Prime prepainted galvanized steel coils represent a premium-grade coating solution that combines the corrosion protection of galvanized steel with factory-applied organic coatings. These value-driven PPGI coils serve critical roles in architectural cladding, roofing systems, and appliance manufacturing where both aesthetic appeal and long-term durability are essential. Engineered for contractors, fabricators, and OEM manufacturers, our prepainted galvanized coils deliver superior weather resistance and color retention across diverse climatic conditions.

Prime prepainted galvanized steel coils supplier

What is Prime Prepainted Galvanized Steel Coils?

Prime prepainted galvanized steel coils are continuous hot-dip galvanized substrates coated with organic paint layers through a continuous coil coating process. The manufacturing sequence includes chemical pretreatment, primer application, topcoat application, and thermal curing at temperatures between 200-250°C, resulting in a tightly bonded coating system with exceptional adhesion properties per ASTM A755/A755M standards.

Prime Prepainted Galvanized Steel Coils Technical Specifications

Our PPGI coils comply with ASTM A755/A755M-17 and EN 10169:2012 standards, featuring zinc coating mass from Z60 to Z275 (60-275 g/m²), base metal thickness ranging 0.18-1.50mm, and coil widths up to 1,500mm. The coating system includes 5-8 μm epoxy primer and 15-25 μm polyester topcoat, delivering total film thickness of 20-33 μm with pencil hardness ≥2H and T-bend flexibility ≤2T per ASTM D4145 testing protocols.

Why Choose Our Prime Prepainted Galvanized Steel Coils

Our manufacturing facility operates ISO 9001:2015 certified production lines with real-time coating thickness monitoring and chromatic aberration control within ΔE≤1.5. We maintain mill-direct pricing through vertical integration from galvanizing to coating, while our technical support team provides color matching services using international RAL, Pantone, and custom color systems with batch consistency guaranteed through spectrophotometric verification.

Frequently Asked Questions

What is the minimum order quantity (MOQ)?

Our standard MOQ is 25 metric tons per color and specification. For stock colors including RAL 9002, RAL 3009, and RAL 5015, we accommodate reduced quantities of 10 metric tons to support project-specific requirements and sample orders for qualification testing.

Do you provide material test certificates?

Yes, each shipment includes EN 10204 Type 3.1 mill test certificates documenting base metal composition per ASTM A653/A653M, zinc coating mass verification per ASTM A90, coating thickness measurements per ASTM D7091, and color coordinates per ASTM D2244. Additional testing reports for salt spray resistance (ASTM B117) and UV weathering (ASTM G154) are available upon request.

What is the typical delivery time?

For standard colors and specifications from our regular production schedule, delivery time is 15-20 days after deposit confirmation. Custom color orders requiring new paint formulation and color approval extend to 25-30 days. Express production for urgent projects can be arranged with 10-12 day lead times subject to capacity availability and premium scheduling fees.

Prime prepainted galvanized steel coils manufacturer

Can you cut to custom sizes?

Our precision slitting lines accommodate custom widths from 50mm to 1,500mm with tolerance ±1.0mm, while our cut-to-length service provides sheets from 600mm to 6,000mm length with straightness deviation ≤2.0mm/m. We offer edge trimming options including mill edge, slit edge, and deburred edge finishes to meet specific fabrication requirements.

Get a Competitive Quote for Prime Prepainted Galvanized Steel Coils

Contact our technical sales team for factory-competitive pricing on prime prepainted galvanized steel coils tailored to your project specifications. We provide comprehensive support including color selection consultation, coating system recommendations, and logistics coordination for container or break-bulk shipments. Request your detailed quotation with material certifications and technical data sheets today to experience our commitment to quality and responsive service.

Prime prepainted galvanized steel coils China
