China Prepainted Galvanized Steel Coil - Hot-Dipped Z275/Z350, ASTM A653, EN10142

Technical Specifications of China Prepainted Galvanized Steel Coil

China Prepainted Galvanized Steel Coil - Hot-Dipped Z275/Z350, ASTM A653, EN10142

China prepainted galvanized steel coil represents a premium-grade architectural material combining superior corrosion protection with aesthetic versatility for construction and manufacturing applications. Engineered through continuous hot-dip galvanizing followed by precision coating processes, this product delivers exceptional durability with zinc coating weights ranging from Z275 to Z350 g/m² per ASTM A653/A653M-20 specifications. Manufactured in state-of-the-art facilities across China's industrial hubs, these coils serve critical roles in metal roofing systems, wall cladding panels, appliance housings, and transportation equipment where both structural integrity and visual appeal are paramount.

What is China Prepainted Galvanized Steel Coil?

China prepainted galvanized steel coil is a value-engineered composite material consisting of cold-rolled steel substrate, hot-dipped zinc coating (galvanized layer), chemical conversion treatment, and factory-applied organic paint systems. The manufacturing process begins with continuous galvanizing per EN 10346:2015 standards, followed by chromate passivation and multi-layer coating application including primer, topcoat, and optional backing coat. This integrated structure provides synergistic protection against atmospheric corrosion while enabling diverse color customization through polyester, silicon-modified polyester (SMP), or polyvinylidene fluoride (PVDF) resin systems.

China Prepainted Galvanized Steel Coil Technical Specifications

Our mill-direct prepainted galvanized steel coils comply with ASTM A653/A653M, EN 10169-1:2012, and JIS G3312 international standards. Base metal thickness ranges from 0.13mm to 1.2mm with width options of 600mm-1500mm. Zinc coating designations include Z100, Z180, Z275, and Z350 (both sides total), tested per ASTM A90/A90M. The substrate steel grades available are DX51D, DX52D, DX53D (EN 10346), S280GD, S350GD (structural), CGCC, CGCD (JIS), and CS Type A/B/C (ASTM). Paint film thickness typically measures 15-25μm top side and 5-10μm reverse side, verified through electromagnetic induction per ISO 2808. Coil inner diameter standardizes at 508mm (20") or 610mm (24") with maximum coil weight of 8-12 metric tons depending on gauge.

Why Choose Our China Prepainted Galvanized Steel Coil

Our manufacturing facilities maintain ISO 9001:2015 quality management certification with full traceability from steel mill to finished coil. Each production lot undergoes rigorous testing including T-bend flexibility testing per ASTM D4145, pencil hardness evaluation (ASTM D3363), and salt spray resistance verification exceeding 1000 hours per ASTM B117. We provide comprehensive mill test certificates (MTC 3.1 per EN 10204) documenting chemical composition, mechanical properties, coating weight analysis, and paint adhesion results. Our value-driven pricing structure eliminates intermediary markups through direct mill partnerships, while maintaining inventory of 15+ standard RAL colors and custom color matching capability with 7-10 day lead time for special orders.

Frequently Asked Questions

What is the minimum order quantity (MOQ)?

Our standard MOQ is 25 metric tons per specification (grade, thickness, width, color combination). For stock colors in common dimensions, we accommodate smaller trial orders of 10 tons with adjusted pricing. Mixed container loading is available for export customers combining multiple specifications to reach economic shipping volumes.

Do you provide material test certificates?

Yes, we supply comprehensive Mill Test Certificates (MTC 3.1 per EN 10204) with every shipment documenting base steel chemistry per ASTM E415 optical emission spectroscopy, tensile properties per ASTM A370, zinc coating weight per ASTM A90 triple-spot testing, and paint system specifications including film thickness, gloss level, and color deviation (ΔE) measurements. Third-party inspection by SGS, BV, or Intertek can be arranged upon request.

What is the typical delivery time?

For standard stock specifications, delivery time is 15-20 days from order confirmation to port of loading. Custom color orders require 25-30 days including color matching, sample approval, and production scheduling. Rush orders may be accommodated with 10-12 day expedited processing subject to production capacity and material availability. Sea freight transit time varies by destination port (15-35 days typical).

Can you cut to custom sizes?

Our slitting capabilities accommodate width tolerances of ±3mm for slit widths from 50mm to 1500mm. We provide precision cut-to-length services with length accuracy of ±5mm for sheets ranging 500mm-6000mm. Edge quality meets A-edge or B-edge classifications per ASTM A924. For high-volume projects, we offer blanking and forming services including corrugation, roll-forming, and panel fabrication to customer-supplied drawings.

Get a Competitive Quote for China Prepainted Galvanized Steel Coil

Contact our technical sales team today to receive factory-competitive pricing on China prepainted galvanized steel coil tailored to your project requirements. Our application engineers provide complimentary material selection consultation, coating system recommendations based on environmental exposure categories (C1-C5 per ISO 12944), and delivered cost analysis including freight optimization. Request samples of our standard color range or submit your custom RAL/Pantone specifications for color matching evaluation. With strategically located warehouses in major ports and direct mill partnerships, we ensure reliable supply chain management for your construction and manufacturing operations.
