Prepaint Galvanized Steel Coil Quotes - Hot-Dip Coated Cold-Rolled Steel

Tianjin TISCO International Trade Co., Ltd.

Verified Custom manufacturer 5yrs

Prepaint galvanized steel coil quotes image thumbnail

Prepaint galvanized steel coil quotes image

Technical Specifications of Prepainted Galvanized Steel Coil

Property	Parameter	Description
Product Name	Prepainted Galvanized Steel Coil (PPGI)	Color-coated galvanized steel with organic coating
Base Material	Hot-dip Galvanized Steel (ASTM A653, EN 10346)	Zinc-coated steel substrate
Coating Type	Polyester (PE), Silicon Modified Polyester (SMP), PVDF	Multiple coating options for different applications
Zinc Coating	40-275 g/m² (Z40-Z275)	Zinc layer weight per ASTM A653
Top Coating Thickness	15-25 μm	Organic paint layer on surface
Back Coating Thickness	5-10 μm	Protective coating on reverse side
Thickness Range	0.13-1.5 mm	Available substrate thickness options
Width Range	600-1500 mm	Standard coil widths
Coil Weight	3-8 tons	Typical coil weight range
Tensile Strength	≥270 MPa	Minimum tensile strength per standard
Yield Strength	≥140 MPa	Minimum yield strength
Elongation	≥20%	Ductility in standard gauge length
Color Options	RAL, Pantone color systems	Customizable colors per international standards
Gloss Level	High gloss (>70GU), Medium (30-70GU), Matte (<30GU)	Surface finish options
Pencil Hardness	≥HB	Coating hardness measurement
Application	Roofing, wall panels, appliances, construction	Typical industrial applications
Certification	ISO 9001, EN 10169, ASTM A755	Quality and standard compliance
Packaging	Waterproof paper, steel strapping, wooden pallet	Standard export packaging
MOQ	25 tons	Minimum order quantity

Prepaint Galvanized Steel Coil Quotes - Hot-Dip Coated Cold-Rolled Steel

Prepaint galvanized steel coil quotes represent factory-direct pricing for color-coated steel products that combine hot-dip galvanization with organic coating systems. These pre-finished steel coils serve critical roles in construction, appliance manufacturing, and industrial applications where corrosion resistance meets aesthetic requirements. Our mill-competitive pricing structures deliver cost-effective solutions for contractors, fabricators, and OEM manufacturers seeking reliable material supply with consistent quality standards.

Prepaint galvanized steel coil quotes supplier

What is Prepaint Galvanized Steel Coil?

Prepaint galvanized steel coil is cold-rolled steel substrate that undergoes continuous hot-dip galvanizing followed by chemical pretreatment and organic coating application. The manufacturing process deposits zinc coating weights ranging from 60-275 g/m² (Z60-Z275 per ASTM A653), then applies primer and topcoat layers totaling 15-25 microns thickness. This dual-layer protection system provides superior resistance to corrosive environments compared to bare galvanized steel while offering factory-controlled color consistency.

Prepaint Galvanized Steel Coil Technical Specifications

Standard specifications comply with ASTM A755/A755M for metallic-coated steel and JIS G3312 for painted steel sheets. Base metal thickness ranges from 0.30-1.20mm with yield strength of 280-550 MPa depending on grade designation. Coating systems include polyester (PE), silicon-modified polyester (SMP), and polyvinylidene fluoride (PVDF) with color retention exceeding 5 years per ASTM D2244. Coil widths extend from 914-1250mm with maximum coil weight reaching 8 metric tons for efficient logistics.

Why Choose Our Prepaint Galvanized Steel Coil Services

Our value-driven pricing reflects direct mill relationships eliminating intermediary markups while maintaining ISO 9001:2015 certified quality management. We stock 200+ color options with RAL and Pantone matching capabilities, backed by material test certificates per EN 10204 3.1 standards. Custom slitting services accommodate widths from 100mm minimum with tolerance control of ±2mm, supported by protective edge masking to prevent transportation damage.

Frequently Asked Questions

What is the minimum order quantity (MOQ)?

Standard MOQ is 25 metric tons per specification to optimize production efficiency, though we accommodate 10-ton orders for stock colors with extended lead times of 15-20 days. Mixed container loading is available for export shipments combining multiple gauges or colors within single 20-foot containers.

Do you provide material test certificates?

Yes, every shipment includes mill test certificates documenting chemical composition per ASTM E1086, mechanical properties per ASTM E8, and coating weight verification per ASTM A90. Third-party inspection by SGS or Bureau Veritas can be arranged at buyer's request with 48-hour notice prior to shipment.

Prepaint galvanized steel coil quotes wholesale

What is the typical delivery time?

Stock colors ship within 7-10 business days from order confirmation, while custom color matching requires 20-25 days for coating line scheduling. Sea freight transit from major Chinese ports to North American destinations averages 18-22 days, with express air freight options available for urgent requirements under 5 tons.

Can you cut to custom sizes?

Our precision slitting lines handle widths from 100-1250mm with ±1mm tolerance control, while cut-to-length services produce sheets from 1000-6000mm length. Laser cutting for complex profiles is available through our fabrication partners with CAD file compatibility for DXF and DWG formats.

Get a Competitive Quote for Prepaint Galvanized Steel Coil

Request your detailed quotation by submitting specifications including thickness, width, coating designation, color requirements, and target delivery location. Our sales engineers respond within 4 business hours with mill-direct pricing, technical data sheets, and logistics recommendations. Volume discounts apply for annual contracts exceeding 500 tons with locked-in pricing protection against market fluctuations.
