| Property | Parameter | Description |
|---|---|---|
| Product Name | Roofing Color Steel Sheet | Pre-painted galvanized/galvalume steel sheet for roofing applications |
| Material Grade | SGCC / DX51D / CGCC / S280GD | Equivalent: JIS G3302 SGCC, EN 10346 DX51D+Z, ASTM A653 CS Type B |
| Standard Compliance | ASTM A755 / EN 10169 / JIS G3312 / GB/T 12754 | International standards for pre-painted metallic coated steel flat products |
| Chemical Composition (C) | ≤ 0.12% | Low carbon content ensures good formability and coating adhesion |
| Chemical Composition (Mn) | ≤ 0.60% | Manganese for structural integrity of base steel |
| Chemical Composition (P / S) | P ≤ 0.045% / S ≤ 0.045% | Controlled impurity levels per EN 10346 and GB/T 12754 |
| Tensile Strength | 270–560 MPa | Varies by grade; S280GD min. 360 MPa per EN 10346 |
| Yield Strength | ≥ 280 MPa | Minimum yield strength for structural roofing grades (S280GD+Z) |
| Elongation | ≥ 16% | A80 elongation ensuring bendability for roof profiling |
| Base Metal Thickness | 0.12 – 1.50 mm | Common roofing range: 0.30–0.80 mm; custom thickness available |
| Sheet Width | 600 – 1,250 mm | Standard coil width; slit-to-width service available |
| Coating Type | Zinc (Z80–Z275 g/m²) / Galvalume (AZ50–AZ150 g/m²) | Hot-dip zinc or 55% Al-Zn alloy coating for corrosion resistance |
| Paint Coating | Top coat: 15–25 μm PE/PVDF/SMP; Primer: 5–7 μm | Polyester (PE), PVDF or SMP topcoat; back coat 7–12 μm |
| Surface Finish | Smooth / Embossed / Matte / High Gloss | RAL color customization available; UV-resistant finish options |
| Application | Residential & commercial roofing, wall cladding, industrial buildings | Suitable for corrugated sheets, standing seam roofs, sandwich panels |
| Certification | ISO 9001 / CE Marking / SGS / BV | Third-party inspection and quality management system certified |
| Packaging | Coil or flat sheet; waterproof paper + steel strip bundling | Export seaworthy packaging; coil weight 3–8 MT typical |
| MOQ | 25 MT per color/specification | Mixed container orders accepted; sample available upon request |
Color inconsistency in first shipment — resolved professionally
First order of 18 tons (0.50mm corrugated, RAL 7035 light grey) showed visible color variation between two coils when panels were installed side by side. Raised the issue with the technical team immediately. They acknowledged the delta-E deviation exceeded tolerance, arranged a partial replacement shipment within 12 days, and issued a credit for the affected material. The replacement coils were perfectly matched. The resolution process was handled professionally and without dispute. Quality control on the replacement batch was clearly tighter. Willing to order again given how the complaint was managed.
