Heat Insulated Color Steel Sheet - Factory Price Supplier
China
Supplier's customization ability
- Drawing-based customization
- Sample-based customization
- Full customization
Minimum order quantity: 1 ton
Shipping total: To be negotiated
- Lead time:
- confirmed with the quotation
- Packaging:
- standard export packing
- Samples:
- available on request
Product details
Technical Specifications of Heat Insulated Color Steel Sheet
| Property | Parameter | Description |
|---|---|---|
| Product Name | Heat Insulated Color Steel Sheet | Pre-painted steel sheet with integrated thermal insulation core, used in building envelope systems |
| Material Grade | Q235B / DX51D+Z / S280GD+Z | International equivalents: ASTM A653 CS Type B, EN 10346 DX51D, JIS G3302 SGCC |
| Standard Compliance | GB/T 12754, EN 10169, ASTM A755 | Meets GB 50176 thermal design code; insulation core per GB/T 10294 (EPS/PU/rock wool) |
| Chemical Composition | C ≤0.12%, Mn ≤0.60%, P ≤0.045%, S ≤0.045%, Si ≤0.50% | Base steel low-carbon composition ensuring good formability and coating adhesion |
| Tensile Strength | 270–560 MPa | Per EN 10346 / GB/T 12754; varies by steel grade (DX51D: ≥270 MPa, S280GD: ≥360 MPa) |
| Yield Strength | 220–420 MPa | S280GD+Z: ReH ≥280 MPa; DX51D+Z: ReH ≥140 MPa (EN 10346) |
| Elongation | ≥16–22% | A80 elongation per EN 10346; higher elongation grades suitable for deep roll-forming profiles |
| Insulation Core Material | EPS / PU Foam / Rock Wool / Glass Wool | PU density 38–42 kg/m³; Rock wool density 100–120 kg/m³; EPS density 15–20 kg/m³ |
| Thermal Conductivity | PU: 0.022–0.024 W/(m·K); Rock Wool: 0.036–0.040 W/(m·K) | Per GB/T 10294 / ISO 8301; lower value indicates better insulation performance |
| Panel Thickness | 50 mm / 75 mm / 100 mm / 150 mm / 200 mm | Total panel thickness including steel skins and insulation core; custom thickness available |
| Steel Skin Thickness | 0.3 mm – 0.8 mm | Top skin: 0.4–0.6 mm; bottom skin: 0.3–0.5 mm; zinc coating Z100–Z275 g/m² |
| Panel Width | Effective width: 900 mm / 1000 mm / 1150 mm | Overall width up to 1200 mm; effective coverage width depends on profile design |
| Panel Length | 2000 mm – 12000 mm (customizable) | Standard lengths 3–6 m; max single piece up to 12 m for wall/roof applications |
| Surface Finish | PVDF / PE / SMP coating; RAL color options | Top coat 20–25 μm (PE), 25–30 μm (PVDF); gloss level 30–70%; salt spray resistance ≥500 h |
| Application | Industrial buildings, cold storage, warehouses, prefab structures, clean rooms | Roof panels, wall cladding, partition walls; suitable for temperature-controlled environments |
| Certification | ISO 9001, CE Marking, FM Approval (fire-rated), SGS | Fire performance per EN 13501-1; thermal performance per EN ISO 6946 |
| Packaging | Steel strip bundled, PE film wrapped, wooden pallet | Panels stacked with protective foam interleaving; export seaworthy packaging available |
| MOQ | 500 m² per order | Mixed specifications acceptable; OEM/custom color and profile available above MOQ |
Heat Insulated Color Steel Sheet - Factory Price Supplier
Heat insulated color steel sheet has become an indispensable material in modern construction, delivering an exceptional combination of thermal efficiency, structural durability, and aesthetic appeal. As global demand for energy-efficient building envelopes continues to rise, this composite panel solution finds extensive application in industrial warehouses, cold storage facilities, commercial roofing systems, agricultural structures, and prefabricated buildings. Engineered to minimize heat transfer while maintaining the mechanical integrity of galvanized or Galvalume steel substrates, these panels significantly reduce HVAC energy consumption — studies indicate thermal resistance values (R-value) ranging from R-10 to R-38 depending on insulation core thickness. The color-coated surface, available in a spectrum of RAL and custom shades, provides outstanding anti-corrosion properties with a service life exceeding 25 years under standard atmospheric conditions. Whether you are sourcing materials for a large-scale commercial project or a specialized industrial facility, our mill-direct supply chain ensures consistent quality at highly competitive rates.
What is Heat Insulated Color Steel Sheet?
Heat insulated color steel sheet is a composite building panel consisting of a color-coated steel facing layer — typically pre-painted galvanized steel (PPGI) or Galvalume steel — bonded to a rigid thermal insulation core such as expanded polystyrene (EPS), polyurethane (PU), or rock wool. This sandwich construction delivers simultaneous load-bearing capacity, weatherproofing, and thermal regulation, making it a premium grade solution for energy-conscious construction applications worldwide.
Heat Insulated Color Steel Sheet Manufacturing Process
Production begins with cold-rolled steel coils that undergo hot-dip galvanizing or Galvalume coating to achieve a zinc layer of 60–275 g/m². The substrate is then chemically pretreated, primer-coated, and finished with a polyester, PVDF, or SMP topcoat at thicknesses of 15–25 μm. The insulation core — EPS at densities of 14–18 kg/m³, PU foam at 40–45 kg/m³, or rock wool at 100–120 kg/m³ — is continuously laminated or injected between the steel facings under controlled pressure and temperature, forming a monolithic panel with superior bond strength exceeding 0.1 MPa.
Heat Insulated Color Steel Sheet Technical Specifications
Standard panel widths range from 950 mm to 1,200 mm with customizable lengths up to 12,000 mm. Steel substrate thickness spans 0.3 mm to 0.8 mm per GB/T 12754 and ASTM A755 standards. Core thickness options of 50 mm, 75 mm, 100 mm, 150 mm, and 200 mm yield thermal conductivity values (λ) as low as 0.022 W/(m·K) for PU cores. Fire resistance ratings achieve Class A1 with rock wool cores per EN 13501-1. Bending strength of the panel system reaches a minimum of 120 MPa, ensuring structural reliability under wind and snow loads.
Get a Competitive Quote for Heat Insulated Color Steel Sheet
Partner with a trusted factory-direct supplier to access mill-direct rates on heat insulated color steel sheet tailored to your exact project specifications. Our team delivers rapid quotations, certified documentation, and end-to-end logistics support to streamline your procurement process.
- 24/7 customer support available
- Free samples for quality evaluation
- Competitive pricing for bulk orders
- Professional technical consultation
Contact us today to get your free quote within 24 hours!
