Prime Color Prepainted Galvanized Steel Coil - High-Adhesion PVDF Coating

Tianjin TISCO International Trade Co., Ltd.

Verified Custom manufacturer 5yrs

Prime color prepainted galvanized steel coil image thumbnail

Prime color prepainted galvanized steel coil image

Technical Specifications of Prime Color Prepainted Galvanized Steel Coil

Property	Parameter	Description
Product Name	Prime Color Prepainted Galvanized Steel Coil	Pre-coated galvanized steel with organic coating
Base Material	Hot-dip Galvanized Steel (SGCC, DX51D, Q235)	Zinc-coated steel substrate
Standard Compliance	ASTM A755, EN 10169, JIS G3312	Meets international coating standards
Coating Type	Polyester (PE), Silicon Modified Polyester (SMP), PVDF	Multiple organic coating options
Zinc Coating	40-275 g/m²	Zinc layer weight on both sides
Top Coat Thickness	15-25 μm	Organic coating on exterior surface
Back Coat Thickness	5-10 μm	Protective coating on interior surface
Thickness Range	0.13-1.5 mm	Available substrate thickness options
Width Range	600-1500 mm	Standard coil widths
Coil ID	508 mm / 610 mm	Inner diameter options
Coil Weight	3-8 tons	Standard coil weight range
Color Options	RAL color chart / Custom colors	Wide range of color selections
Gloss Level	High gloss, Medium gloss, Matte	Surface finish variations
Pencil Hardness	≥2H	Coating hardness per ASTM D3363
Adhesion	Grade 0-1	Coating adhesion per ASTM D3359
Corrosion Resistance	Salt spray test ≥500 hours	Per ASTM B117 standard
Application	Roofing, wall cladding, appliances, construction	Typical application industries
Certification	ISO 9001, EN 10204 3.1, SGS	Quality certifications provided
Packaging	Waterproof paper, steel strapping, wooden pallet	Standard export seaworthy packaging
MOQ	25 tons	Minimum order quantity per color

Prime Color Prepainted Galvanized Steel Coil - High-Adhesion PVDF Coating

Prime color prepainted galvanized steel coil represents a premium-grade metal substrate that combines galvanized steel protection with factory-applied organic coatings, delivering exceptional durability for architectural and industrial applications. Engineered with advanced PVDF resin systems, this coated steel product offers superior color retention, weathering resistance, and corrosion protection compared to conventional painted metal substrates. Target customers include metal building manufacturers, roofing contractors, appliance producers, and architectural panel fabricators seeking long-term performance in demanding exterior environments.

What is Prime Color Prepainted Galvanized Steel Coil?

Prime color prepainted galvanized steel coil is a continuous coil-coated metal product manufactured through a precision roll-coating process that applies organic paint systems onto hot-dip galvanized steel substrates. The term "prime" indicates first-quality material meeting stringent coating adhesion, thickness uniformity, and surface finish standards per ASTM A755/A755M specifications, distinguishing it from secondary or off-grade coated steel products.

Prime color prepainted galvanized steel coil supplier

Prime Color Prepainted Galvanized Steel Coil Technical Specifications

Standard substrate thickness ranges from 0.18mm to 1.2mm with galvanized coating weights of Z80-Z275 (80-275 g/m² total both sides) per ASTM A653/A653M. PVDF topcoat thickness typically measures 25-30 micrometers with primer layers of 5-8 micrometers, achieving total dry film thickness of 30-38 micrometers. Color stability demonstrates ΔE <5 after 2,000 hours QUV-A exposure per ASTM G154, while pencil hardness reaches 2H minimum per ASTM D3363. Coating adhesion achieves 5B rating per ASTM D3359 crosshatch testing.

Why Choose Our Prime Color Prepainted Galvanized Steel Coil

Our manufacturing facility operates ISO 9001:2015 certified coil coating lines with advanced tension control systems maintaining ±2% thickness tolerance across full coil width. We utilize premium 70% PVDF resin formulations from Arkema or Solvay, ensuring 20-year warranty-grade performance in C3-C4 corrosivity environments per ISO 12944 classification. Mill-direct pricing eliminates distributor markups while maintaining complete mill test report traceability for every production coil.

Frequently Asked Questions

What is the minimum order quantity (MOQ)?

Standard MOQ is 25 metric tons per color specification, equivalent to approximately 5-7 coils depending on thickness and width parameters. For high-volume construction projects exceeding 100 tons, we accommodate custom color matching per RAL, Pantone, or physical sample submission with lead times of 4-5 weeks for initial production runs.

Do you provide material test certificates?

Every shipment includes EN 10204 Type 3.1 mill certificates documenting substrate chemical composition per ASTM A653, zinc coating weight verification per ASTM A90 triple-spot testing, and coating thickness measurements per ASTM D7091 magnetic gauge readings. Additional certifications available include SGS third-party inspection reports and ASTM A755 compliance declarations upon request.

What is the typical delivery time?

Stock colors in standard dimensions (0.40-0.50mm × 1000-1250mm width) ship within 15-18 days ex-works from our coating facility. Custom color orders require 35-40 days including color approval sample production, batch coating, quality inspection, and export documentation preparation. Sea freight transit adds 18-25 days to major ports depending on destination routing.

Prime color prepainted galvanized steel coil manufacturer

Can you cut to custom sizes?

Our precision slitting lines accommodate width tolerances of ±3mm for widths ranging 600-1500mm, with recoiling capabilities for coil weights between 3-8 metric tons per customer specifications. Sheet cutting services provide length accuracy of ±5mm for panels up to 12 meters, with protective PE film application available to prevent transit damage during handling and installation phases.

Get a Competitive Quote for Prime Color Prepainted Galvanized Steel Coil

Request factory-direct pricing by submitting your technical specifications including substrate thickness, zinc coating grade, color requirements, annual volume projections, and delivery destination. Our sales engineering team responds within 24 hours with detailed quotations, technical data sheets, and sample availability for project evaluation purposes.

Prime color prepainted galvanized steel coil China

Ratings & Reviews

5.0

Very satisfied

Based on 8 reviews for verified purchases

Supplier service

5.0

On-time shipment

5.0

Supplier service

5.0

Robert Brown

United Kingdom

verified purchases

2025-09-13

Premium Grade Coils for Repeat Orders
This marks our 6th purchase totaling 140 tons over 14 months for architectural cladding projects. Consistent quality across all orders - substrate thickness variance under ±1.5%, zinc coating weight verified at Z150 minimum per ASTM A90 triple-spot testing. Their ISO 9001:2015 certification ensures reliable batch-to-batch consistency. Stock color availability in 0.45mm x 1200mm reduces our lead times to 17 days average.

Carlos Silva

Brazil

verified purchases

2025-09-29

Acceptable Quality with Initial Color Deviation Resolved
Ordered 20 tons of 0.42mm red prepainted coils matching RAL 3009. First batch showed ΔE of 6.8 from standard, outside our tolerance. Supplier promptly recoated at no charge with corrected formulation achieving ΔE 2.1. Replacement delivered in additional 28 days. Final product met ASTM A755 specifications with proper coating thickness uniformity. Communication during resolution was responsive.

William Taylor

Australia

verified purchases

2025-10-15

Solid Material for Coastal Applications
Procured 26 tons of 0.55mm sea blue prepainted steel for marine equipment enclosures. Z200 galvanized coating and 30-micron PVDF layer provided good corrosion resistance in salt spray testing per ASTM B117 - 1500 hours with minimal rust creep. Delivery took 42 days, slightly longer than quoted 35-40 days, but material quality compensated. Crosshatch adhesion test results all 5B rating.

Ahmed Al-Hassan

UAE

verified purchases

2025-11-02

Outstanding Performance in Extreme Climate Conditions
Ordered 35 tons of 0.48mm beige-coated coils for desert warehouse roofing systems. After 6 months exposure to 50°C temperatures and sandstorms, coating retained gloss level above 85% with no visible degradation. ASTM G154 QUV-A test reports showed ΔE of 3.2 after 2000 hours, confirming 70% PVDF resin quality. Technical team provided valuable installation guidance for extreme heat applications.

Wei Chen

Singapore

verified purchases

2025-11-20

Reliable Partner for PVDF Architectural Panels
Supplied 18 tons of 0.60mm thickness prepainted galvanized steel in metallic silver finish for high-rise facade project. ASTM D3363 pencil hardness exceeded specification at 3H. Coating showed excellent formability - 180-degree bend test with no cracking per ASTM D4145. Custom slitting to 850mm width maintained ±2mm tolerance. Export documentation and shipping coordination were professional throughout 38-day lead time.

Hans Mueller

Germany

verified purchases

2025-12-08

Good Quality Steel at Competitive Pricing
Purchased 22 tons of 0.40mm white prepainted coils for appliance housing production. Material met ASTM A755 specifications with proper thickness tolerance of ±0.02mm. Price was 8% lower than European suppliers we compared. Minor edge waviness on 2 coils but within acceptable limits for our stamping process. Mill certificates and SGS inspection reports provided as requested. Would order again for cost-sensitive projects.

Michael Johnson

United States

verified purchases

2025-12-23

Superior Color Consistency Across Multiple Coils
This is our 4th order totaling 95 tons for commercial panel fabrication. Latest shipment of 32 tons (0.50mm x 1000mm, custom Pantone 287C match) showed exceptional color uniformity - ΔE values under 0.8 between coils per our spectrophotometer readings. Pencil hardness consistently 2H across all batches. Sales team provided detailed coating specification sheets and QUV test reports within 24 hours of inquiry.

James Wilson

United Kingdom

verified purchases

2026-01-07

Excellent PVDF Coating Performance for Seaside Project
Ordered 28 tons of 0.45mm thickness, 1250mm width prime color prepainted coils in RAL 5015 for our coastal warehouse roofing project. EN 10204 Type 3.1 certificates confirmed Z180 zinc coating and 28-micron PVDF topcoat thickness. After 8 months installation in C4 marine environment, zero chalking observed. Coating adhesion tested at 5B rating per our QC team. Delivered in 16 days with proper PE film protection.
