| Property | Parameter | Description |
|---|---|---|
| Product Name | Galvanized Steel for Construction | Hot-dip or electro-galvanized steel products used in structural and building applications |
| Material Grade | DX51D / S250GD / S350GD / SGCC / G550 | International equivalents: ASTM A653 CS/SS, EN 10346, JIS G3302, AS 1397 |
| Standard Compliance | ASTM A653/A653M, EN 10346, JIS G3302, GB/T 2518 | Meets international hot-dip galvanized steel sheet and coil standards for structural use |
| Chemical Composition | C ≤0.12%, Mn ≤0.60%, P ≤0.10%, S ≤0.045%, Si ≤0.50% | Base metal composition per EN 10346 / ASTM A653; zinc coating layer: Zn ≥99.5% |
| Tensile Strength | 270–550 MPa | Varies by grade: DX51D ≥270 MPa; S350GD ≥420 MPa; G550 ≥550 MPa (per EN 10346 / AS 1397) |
| Yield Strength | 140–550 MPa | S250GD ≥250 MPa; S350GD ≥350 MPa; G550 ≥550 MPa; suitable for load-bearing construction |
| Elongation | ≥2%–22% | DX51D A80 ≥22%; high-strength grades (G550) ≥2%; per respective testing standards |
| Zinc Coating Weight | Z60–Z600 (g/m²); ZF60–ZF180 (galvannealed) | Coating designation per EN 10346 / ASTM A653; Z275 (275 g/m²) most common for construction |
| Thickness Range | 0.12–6.00 mm | Standard construction grades: 0.3–3.0 mm (sheet/coil); structural sections up to 6.0 mm |
| Width Range | 600–1,500 mm | Coil and sheet widths; custom slit widths available upon request |
| Length / Coil Weight | Sheets: 1,000–6,000 mm; Coils: 3–15 MT | Cut-to-length sheets or full coils; inner diameter 508/610 mm standard |
| Surface Finish | Regular Spangle, Minimized Spangle, Zero Spangle, Skin-passed | Options include chromate passivation, oiled or dry surface treatment for corrosion protection |
| Application | Roofing, wall cladding, purlins, framing, decking, HVAC ducts, fencing | Widely used in residential, commercial, and industrial construction for corrosion-resistant structures |
| Certification | ISO 9001:2015, CE Marking, Mill Test Certificate (EN 10204 3.1/3.2) | Third-party inspection available; SGS, BV, TÜV reports upon request |
| Packaging | Coils: steel-strapped with waterproof wrapping; Sheets: bundled with wooden pallet | Export seaworthy packaging; moisture-proof paper interleaving available for sheet bundles |
| MOQ | 25 MT per order (coil); 5 MT per grade/size (sheet) | Mixed container orders accepted; spot stock available for standard grades (Z275, DX51D) |
Initial Coating Inconsistency Flagged — Issue Resolved Satisfactorily
On our first order of 70 MT of DX51D, 0.7 mm, Z220 coating for metal roofing panels, our QC team found coating weight on 4 coils measured at Z195–Z205 g/m² rather than the specified Z220 minimum per ASTM A653. We raised the nonconformance immediately. The supplier's technical team responded within 12 hours, reviewed our test reports, acknowledged the variance, and arranged a partial replacement shipment within 2 weeks at no additional cost. Subsequent coils were fully in spec. Appreciated the professional resolution. Will give a second order a chance.
