| Property | Parameter | Description |
|---|---|---|
| Optical Fiber Product Name | Plug and Play Fiber Cable | Pre-terminated, factory-tested fiber cable assembly ready for immediate deployment |
| Fiber Grade & ITU-T Classification | ITU-T G.652D / G.657A1 / G.657A2 | Single-mode standard or bend-insensitive grade; multimode OM3/OM4/OM5 available on request |
| Core & Cladding Diameter Range | 9/125 μm (SM); 50/125 μm (MM) | Single-mode 9 μm core; multimode 50 μm core with 125 μm cladding standard |
| Attenuation Coefficient at 1310nm | ≤ 0.35 dB/km | Measured per IEC 60793-1-40; applies to G.652D single-mode fiber |
| Attenuation Coefficient at 1550nm | ≤ 0.20 dB/km | Low-loss performance suitable for long-haul and data center interconnect applications |
| Macrobending Loss Performance | ≤ 0.10 dB (R=15 mm, 10 turns, 1550nm) | G.657A2 bend-insensitive fiber option available; compliant with IEC 60793-2-50 |
| Chromatic Dispersion Coefficient | ≤ 18 ps/(nm·km) at 1550nm | Zero-dispersion wavelength 1300–1324 nm; dispersion slope ≤ 0.092 ps/(nm²·km) |
| Connector Type & Insertion Loss | LC/SC/MPO/MTP; IL ≤ 0.3 dB | Factory-polished UPC or APC connectors; return loss ≥ 50 dB (UPC), ≥ 60 dB (APC) |
| Batch Qualification Rate | ≥ 99.5% | 100% end-face inspection and optical performance testing performed on every assembly before shipment |
| Manufacturing Environment Standards | ISO Class 7 Cleanroom (ISO 14644-1) | Connector termination and polishing performed in controlled cleanroom environment to ensure low IL/RL |
| Core Raw Material Source | Corning / Prysmian / Sumitomo OFS | Tier-1 fiber preform suppliers; traceable lot documentation available upon request |
| Packaging Specification | Individual reel or coiled bag; 1 m – 300 m per assembly | ESD-protective bag with dust caps on all connectors; custom lengths and breakout configurations available |
| Storage Conditions | -20°C to +70°C; RH ≤ 85% non-condensing | Store away from direct UV exposure; avoid mechanical stress on connector ferrules during storage |
| Valid Shelf Life | 25 years (fiber); 5 years (connector polish) | Fiber lifetime per IEC 60793-1-30; connector end-face re-polishing service available after 5 years |
| Application Scenarios | Data center, MTP trunk, FTTH, 5G fronthaul, enterprise LAN | Suitable for structured cabling, high-density patch panels, and rapid network deployment scenarios |
| Compliance & Certification | IEC 61754-20, TIA-568, RoHS, REACH, UL Listed | Compliant with international fiber optic cabling standards; CE and UL certifications available |
| Minimum Order Quantity (MOQ) | 10 assemblies per SKU | Custom lengths, connector types, and fiber counts accepted from MOQ; sample orders supported |
| Monthly Supply Capacity | 50,000 assemblies/month | Scalable production capacity with 15-day standard lead time; expedited 7-day lead time available |
Minor connector cap issue on first shipment — resolved promptly
Ordered 450 SC-APC OS2 assemblies (LSZH, 10 m) for an outdoor FTTH distribution project. On arrival, approximately 15 units had loose dust caps that had shifted during transit, raising contamination concerns before installation. Contacted support immediately — they arranged an expedited replacement shipment for the affected units within 5 business days and provided a prepaid return label. Post-replacement inspection confirmed all connectors met the ≥60 dB APC return loss spec. The resolution was handled professionally. Packaging has apparently been reinforced since then. Cautiously optimistic for our next order.
