High Density Pre Terminated Fiber Solution Supplier
China
Supplier's customization ability
- Drawing-based customization
- Sample-based customization
- Full customization
Minimum order quantity: 1 piece
Shipping total: To be negotiated
- Lead time:
- confirmed with the quotation
- Packaging:
- standard export packing
- Samples:
- available on request
Product details
Technical Specifications of High Density Pre Terminated Fiber Solution
| Property | Parameter | Description |
|---|---|---|
| Product Name | High Density Pre Terminated Fiber Solution | Factory-terminated, plug-and-play fiber optic cabling system for high-density data center and enterprise deployments |
| Fiber Type | OS2 / OM3 / OM4 / OM5 | OS2: 9/125µm SMF; OM3/OM4/OM5: 50/125µm MMF; selection based on distance and bandwidth requirements |
| Standard Compliance | IEC 61754-20, IEC 61300, TIA-568.3-D, ISO/IEC 11801 | Compliant with international fiber optic performance and dimensional standards |
| Connector Type | LC, MPO-12, MPO-24, SC, MTP® | Pre-polished and factory-tested connectors; MPO/MTP available in Type A/B/C polarity configurations |
| Insertion Loss | ≤0.35 dB (LC/SC); ≤0.6 dB (MPO-12/24) | Per IEC 61300-3-4; low-loss performance verified at 850nm, 1310nm, and 1550nm wavelengths |
| Return Loss | ≥26 dB (UPC); ≥55 dB (APC) | Per IEC 61300-3-6; APC connectors recommended for single-mode long-haul applications |
| Tensile Strength | ≥50 N (per fiber); ≥200 N (trunk cable) | Per IEC 61300-2-4; ensures mechanical integrity during installation and operation |
| Operating Temperature | -20°C to +70°C | Storage: -40°C to +85°C; suitable for indoor data center and structured cabling environments |
| Cable Jacket Material | LSZH / PVC / Plenum-rated OFNP | LSZH per IEC 60332-1; Plenum per NFPA 262; flame-retardant options available per application |
| Fiber Count per Trunk | 12F, 24F, 48F, 72F, 96F, 144F, 288F, 432F | MPO-based trunk cables support scalable fiber counts; custom configurations available |
| Cable Outer Diameter | 3.0 mm – 18.0 mm (depending on fiber count) | Compact round or flat ribbon design; optimized for high-density tray and conduit routing |
| Length Range | 1 m – 300 m (standard); custom lengths available | Factory-cut and terminated to specified lengths; length tolerance ±1% or ±0.5 m |
| Surface Finish / End-face | PC / UPC / APC polished | End-face geometry per IEC 61300-3-11; factory-tested with interferometer for each connector |
| Application | Data center interconnect, MDA/HDA/EDA cabling, 40G/100G/400G/800G migration, FTTH, enterprise LAN | Supports Base-8 and Base-12 structured cabling architectures; compatible with IEEE 802.3 standards |
| Certification | UL Listed, RoHS, CE, ISO 9001:2015 | Third-party tested; each assembly shipped with factory test report (insertion loss and return loss per fiber) |
| Packaging | Individual reel/drum with protective end caps; labeled with fiber count, length, polarity, and lot number | Anti-static packaging; pull-out box or wooden reel options for trunk cables over 50 m |
| MOQ | 1 unit (standard configurations); 10 units (custom configurations) | Standard assemblies available from stock; custom lead time 5–15 business days |
High Density Pre Terminated Fiber Solution Supplier
A high density pre terminated fiber solution is the cornerstone of modern data center infrastructure, enabling rapid deployment, reduced installation errors, and maximized rack space utilization across enterprise and hyperscale environments. As global bandwidth demands continue to surge — with data center traffic projected to exceed 20 zettabytes annually — network architects increasingly rely on factory-terminated fiber assemblies to meet aggressive installation timelines without compromising optical performance. These pre-engineered systems arrive on-site fully tested, polarity-verified, and ready for immediate plug-and-play integration, eliminating the labor-intensive field termination process that traditionally accounts for up to 60% of cabling project costs. Whether deployed in spine-leaf architectures, high-performance computing clusters, or colocation facilities requiring OM4/OM5 multimode or OS2 single-mode connectivity, a well-engineered pre terminated fiber solution delivers measurable gains in uptime reliability, scalability, and total cost of ownership across the full network lifecycle.
What is a High Density Pre Terminated Fiber Solution?
A high density pre terminated fiber solution is a factory-assembled optical cabling system in which fiber trunk cables, MTP/MPO connectors, cassettes, and patch panels are precision-terminated, tested, and packaged as complete, deployment-ready modules. Designed to support 40G, 100G, 400G, and emerging 800G transmission speeds, these systems achieve port densities of up to 144 fibers per 1U panel, dramatically reducing rack unit consumption while maintaining insertion loss values consistently below 0.35 dB per connector per IEC 61753-1 standards.
High Density Pre Terminated Fiber Solution Manufacturing Process
Production begins with precision cleaving and fusion splicing of individual fiber strands within controlled cleanroom environments maintaining ISO Class 7 conditions. MTP/MPO ferrules are polished to APC or UPC end-face geometry, achieving return loss exceeding 65 dB for APC variants. Each completed assembly undergoes 100% end-to-end insertion loss testing, OTDR trace verification, and polarity validation per TIA-568-C.0 standards before receiving individual serialized documentation and protective packaging for field deployment.
High Density Pre Terminated Fiber Solution Technical Specifications
Standard configurations support fiber counts from 12F to 3,456F per trunk system, with available jacket ratings including LSZH, plenum-rated OFNP, and armored variants for harsh environments. Typical insertion loss per MTP/MPO connector measures ≤0.35 dB (UPC) and ≤0.25 dB (APC). Operating temperature range spans -20°C to +70°C, with bend radius ratings of 10× cable diameter minimum. Compatible fiber types include OM3 (2,000 MHz·km bandwidth), OM4 (4,700 MHz·km), OM5 wideband multimode, and G.652.D/G.657.A2 single-mode variants meeting ITU-T specifications.
Get a Competitive Quote for High Density Pre Terminated Fiber Solution
Partner with our engineering team to design a pre terminated fiber solution precisely matched to your port count, rack layout, and transmission speed requirements. We deliver mill-direct rates on custom assemblies with lead times as short as 5 business days, backed by full traceability documentation and a 25-year performance warranty.
- 24/7 customer support available
- Free samples for quality evaluation
- Competitive pricing for bulk orders
- Professional technical consultation
Contact us today to get your free quote within 24 hours!
