G.657A2 9/125μm single-mode optical cable, high performance with bending resistance.

Customizable Rock-bottom price

$85 1-49 km Base price

$82 50-99 km 3.5% off

$79 ≥100 km 7.1% off

Price validity: subject to market conditions

Supplier's customization ability

Drawing-based customization
Sample-based customization
Full customization

Quantity

Minimum order quantity: 1 km

Shipping total: To be negotiated

Subtotal of goods US$ 85.00

Start order request

Payment and delivery

Payment:: by contract — deposit, balance after your inspection
Lead time:: confirmed with the quotation
Packaging:: standard export packing
Samples:: available on request

Product details

Technical Specifications of G.657A2 9/125μm Single-Mode Optical Cable

Property	Parameter	Description
Product Name	G.657A2 9/125μm Single-Mode Optical Cable	Bend-insensitive single-mode fiber optic cable with high bending resistance performance
Fiber Type	Single-Mode, G.657A2	Compatible with G.652D; core/cladding diameter 9/125μm; optimized for FTTH/FTTX deployments
Standard Compliance	ITU-T G.657A2, IEC 60793-2-50	Meets ITU-T G.657 Category A2 bend-insensitive fiber standard; backward compatible with G.652D
Attenuation	≤0.35 dB/km @ 1310nm; ≤0.20 dB/km @ 1550nm	Low attenuation ensures long-distance signal transmission with minimal loss
Chromatic Dispersion	≤18 ps/(nm·km) @ 1550nm	Compliant with ITU-T G.657A2 dispersion specification for single-mode transmission
Bending Radius (Macro)	R=7.5mm, 10 turns, ≤0.1 dB @ 1550nm	Superior macro-bend performance; suitable for tight routing in indoor and FTTH installations
Cutoff Wavelength	≤1260nm (cable cutoff)	Ensures single-mode operation across full operating wavelength range 1260–1625nm
Mode Field Diameter	8.6–9.5μm @ 1310nm	Optimized MFD for low splice loss and compatibility with standard G.652D fiber
Numerical Aperture	0.14 ± 0.02	Standard NA ensuring efficient light coupling and low connection loss
Operating Temperature	-40°C to +70°C (installation); -60°C to +85°C (storage)	Wide temperature range suitable for indoor, outdoor, and harsh environment applications
Cable Construction	Tight-buffered / Loose-tube / LSZH jacketed options	Available in simplex, duplex, ribbon, and multi-fiber configurations per project requirement
Outer Diameter	2.0mm / 3.0mm (standard); custom sizes available	Compact design for space-saving installation in conduits, trays, and micro-ducts
Tensile Strength	≥100N (short-term); ≥60N (long-term)	Per IEC 60794-1-2 Method E1; ensures mechanical integrity during installation and service
Application	FTTH, FTTX, indoor wiring, data centers, access networks	Ideal for last-mile connectivity, building riser/horizontal cabling, and tight-space routing
Certification	RoHS, REACH, UL, CE, ISO 9001	Internationally certified for safety, environmental compliance, and quality management
Packaging	Wooden drum / plastic reel; 1km, 2km, 4km per reel standard	Custom reel lengths available; labeled with fiber count, length, and batch traceability
MOQ	1 km	Flexible order quantities supported; volume pricing available for OEM and project orders

G.657A2 Single-Mode Optical Cable - Bend Resistant Supplier

The G.657A2 single-mode optical cable represents a breakthrough solution for modern fiber-to-the-home (FTTH) and indoor network deployments where tight routing conditions demand exceptional performance. Engineered to the ITU-T G.657A2 standard, this 9/125μm single-mode optical cable delivers a minimum bend radius of just 7.5 mm, enabling installers to route fibers around sharp corners, through conduits, and along building structures without inducing signal degradation. Compared to conventional G.652D cables, the G.657A2 design achieves significantly reduced macro-bending loss — typically less than 0.1 dB per turn at a 7.5 mm radius for 1550 nm wavelength — making it the preferred choice for dense urban installations, multi-dwelling units (MDUs), and last-mile connectivity projects. As a professional G.657A2 single-mode optical cable supplier, we provide mill-direct rates, rigorous quality control, and full traceability documentation to support procurement teams across telecommunications, data center, and enterprise network sectors worldwide.

G.657A2 9/125μm single-mode optical cable supplier

What is G.657A2 9/125μm Single-Mode Optical Cable?

The G.657A2 9/125μm single-mode optical cable is a bend-insensitive fiber optic cable standardized by the ITU-T G.657 Category A2 specification. It features a 9 μm core diameter and 125 μm cladding, maintaining full backward compatibility with G.652D infrastructure. Its advanced trench-assisted or nanostructured fiber design suppresses bending-induced attenuation, achieving a maximum attenuation of 0.4 dB/km at 1310 nm and 0.3 dB/km at 1550 nm under standard operating conditions.

G.657A2 Single-Mode Optical Cable Technical Specifications

Our G.657A2 bend resistant single-mode optical cable meets rigorous international performance benchmarks critical for high-density and confined-space deployments:

Parameter	Specification
ITU-T Standard	G.657A2
Core / Cladding Diameter	9 / 125 μm
Coating Diameter	245 ± 10 μm
Attenuation @ 1310 nm	≤ 0.40 dB/km
Attenuation @ 1550 nm	≤ 0.30 dB/km
Minimum Bend Radius (Installation)	7.5 mm (10 turns, ≤ 0.1 dB @ 1550 nm)
Minimum Bend Radius (Long-Term)	15 mm
Mode Field Diameter @ 1310 nm	8.6 – 9.2 μm
Cable Cut-off Wavelength	≤ 1260 nm
Operating Temperature	-40°C to +70°C
Proof Test Level	≥ 0.69 GPa (100 kpsi)
Compatibility	Fully backward compatible with G.652D

This G.657A2 single-mode optical cable finds extensive application in FTTH drop cable assemblies, indoor riser and plenum installations, patch cord manufacturing, and high-density data center interconnects where cable routing imposes unavoidable bending stress. Its superior macro-bending performance ensures consistent signal integrity across wavelengths from 1260 nm to 1625 nm, supporting current and next-generation passive optical network (PON) architectures including GPON, XGS-PON, and NG-PON2.

Get a Competitive Quote for G.657A2 Single-Mode Optical Cable

Partner with a trusted G.657A2 bend resistant optical cable supplier offering mill-direct pricing, certified product documentation, and responsive logistics support. Whether you require small evaluation quantities or large-volume project orders, our team delivers tailored solutions within your timeline and budget requirements.

G.657A2 9/125μm single-mode optical cable manufacturer

24/7 customer support available
Free samples for quality evaluation
Competitive pricing for bulk orders
Professional technical consultation

Contact us today to get your free quote within 24 hours!

G.657A2 9/125μm single-mode optical cable factory

Ratings & Reviews

4.5

Based on 8 reviews

5 5

4 2

3 1

2 0

1 0

Carlos N.

United States

2025-01-01

Initial labeling issue resolved promptly — product quality is fine

We ordered 20,000 meters of G.657A2 9/125μm cable for a NG-PON2 pilot in Texas. The fiber itself tested well — attenuation at 1310 nm was ≤0.40 dB/km and bend loss at 7.5 mm radius was within ITU-T G.657A2 limits. However, roughly 15% of reels arrived with incorrect reel length labels, which complicated our inventory tracking. I raised the issue and the supplier responded within 4 hours, provided corrected documentation, and offered a partial credit on the next order. The problem was fully resolved within two days. Product performance is solid; just needs tighter QC on outgoing labeling.

Rachel M.

United Kingdom

2025-01-23

Solid G.657A2 product at a competitive mill-direct price

We purchased 35,000 meters for indoor plenum cable installations across several commercial buildings in Manchester. The G.657A2 spec was fully met — attenuation at 1550 nm averaged 0.29 dB/km and the 15 mm long-term bend radius is well suited to our conduit routing constraints. Pricing was noticeably better than our previous UK-based distributor. Deducting one star because the initial quote took closer to 30 hours rather than the advertised 24 hours. Once engaged, the technical consultation was thorough and the shipment was well packaged. Good overall supplier.

Ahmed K.

UAE

2025-02-14

Good value for FTTH deployment — minor lead time variance

Ordered 45,000 meters of G.657A2 9/125μm cable for an FTTH project in Dubai. The bend performance at 7.5 mm radius is excellent for routing along building facades in our climate — the ≤0.1 dB loss per 10 turns at 1550 nm held up well in field testing. Pricing was competitive for this volume. The only reason I'm giving 4 stars is that the quoted lead time of 14 days stretched to 19 days on this order. Quality documentation and product specs were fully compliant with ITU-T G.657A2. Would order again given the overall value.

Know your supplier

Anxun optical fiber Co., Ltd.

7 yrs on Sinoali.com

Located in China

Company information More goods

FAQ

Q: What types of single-mode fiber do you supply?

A:We supply OS1, OS2, G.652D, G.655, G.657 bend-insensitive and low-loss single-mode fiber for telecom and data transmission.

Q: What is the core and cladding diameter of single-mode fiber?

Q: What is the main application of single-mode fiber?

Q: What is the difference between single-mode and multi-mode fiber?

Q: Can single-mode fiber be used for outdoor and underground projects?

Q: What transmission speeds does single-mode fiber support?
