China Color Coated Steel Roof Panel - Galvanized Corrugated Metal Sheets for Construction

Tianjin TISCO International Trade Co., Ltd.

Verified Custom manufacturer 5yrs

China Color coated steel roof panel image thumbnail

China Color coated steel roof panel image

Technical Specifications of China Color Coated Steel Roof Panel

Property	Parameter	Description
Product Name	Color Coated Steel Roof Panel	Pre-painted galvanized steel roofing sheet
Base Material	Galvanized Steel / Galvalume Steel	SGCC, DX51D+Z, ASTM A653, JIS G3302
Coating Type	PVDF / SMP / PE / HDP	Polyester, Silicon Modified, Fluorocarbon coating
Zinc Coating	60-275 g/m²	Z60, Z80, Z100, Z120, Z150, Z275 available
Thickness Range	0.12 - 1.5 mm	Common: 0.3mm, 0.4mm, 0.5mm, 0.6mm
Width Range	600 - 1250 mm	Effective width varies by profile type
Length	Customized	Standard: 2-12m, custom length available
Color Options	RAL Color Chart	Standard colors: RAL 9002, 3009, 5015, 6005
Tensile Strength	≥270 MPa	Minimum tensile strength per ASTM A653
Yield Strength	≥205 MPa	Minimum yield strength
Elongation	≥20%	Ductility in standard gauge length
Profile Types	Corrugated, Trapezoidal, IBR, Box Rib	Multiple wave patterns available
Coating Thickness	Top: 15-25μm / Back: 5-10μm	Varies by coating type and application
Temperature Resistance	-40°C to +120°C	Suitable for various climate conditions
Application	Industrial buildings, warehouses, residential roofing	Suitable for roofing and wall cladding
Certification	ISO 9001, EN 10169, ASTM A755	Quality certifications provided
Packaging	Waterproof paper, steel straps, wooden pallet	Standard export seaworthy packaging
MOQ	25 tons	Minimum order quantity per container

China Color Coated Steel Roof Panel - Galvanized Corrugated Metal Sheets for Construction

China color coated steel roof panels represent a premium-grade roofing solution engineered for commercial and residential construction projects requiring superior weather resistance and aesthetic versatility. Manufactured through continuous hot-dip galvanizing followed by precision color coating processes, these corrugated metal sheets deliver exceptional durability against corrosive environments while offering architects extensive design flexibility through diverse color options and profile configurations.

China Color coated steel roof panel supplier

What is China Color Coated Steel Roof Panel?

Color coated steel roof panels are pre-painted galvanized steel sheets formed into corrugated or trapezoidal profiles specifically designed for roofing applications. The base substrate undergoes zinc coating per ASTM A653/A653M standards with coating weights ranging from Z180 to Z275 (180-275 g/m²), followed by chromate treatment and polyester, silicon-modified polyester, or polyvinylidene fluoride (PVDF) topcoat application achieving film thickness of 18-27 micrometers for optimal corrosion protection.

China Color Coated Steel Roof Panel Technical Specifications

Standard manufacturing specifications include base metal thickness of 0.35-0.80mm with tolerance of ±0.02mm, yield strength minimum 280 MPa per GB/T 12754 requirements, and tensile strength exceeding 350 MPa. Color coating systems comply with ASTM D3363 pencil hardness rating of 2H minimum, demonstrating superior scratch resistance for installation and service life durability in construction environments.

Why Choose Our Color Coated Roof Panels

Our manufacturing facility operates continuous galvanizing lines with annual capacity exceeding 500,000 metric tons, ensuring consistent quality control and mill-direct competitive pricing for volume orders. All products undergo rigorous testing including salt spray resistance per ASTM B117 (1000+ hours), impact resistance per ASTM D2794, and color fastness verification per ASTM D4214, with comprehensive material test certificates provided for every shipment batch.

Frequently Asked Questions

What is the minimum order quantity (MOQ)?

Standard MOQ is 25 metric tons per color and profile specification. For mixed container orders combining multiple colors or thicknesses, minimum 5 tons per SKU applies with 25-ton total shipment requirement to optimize freight economics and production scheduling efficiency.

Do you provide material test certificates?

Comprehensive mill test certificates accompany every order, documenting chemical composition analysis, mechanical property test results, zinc coating weight verification, and color coating adhesion data. Third-party inspection by SGS, BV, or equivalent agencies can be arranged upon request with associated costs.

What is the typical delivery time?

Standard production lead time ranges 18-25 days from deposit receipt for stock color selections, extending to 28-35 days for custom RAL color matching requiring specialized paint formulation. Ocean freight transit adds 20-40 days depending on destination port, with FOB Qingdao or Shanghai terms commonly applied.

Can you cut to custom sizes?

Precision slitting services accommodate custom width requirements from 600mm to 1250mm with ±2mm tolerance. Length cutting is available for panels up to 12 meters with computerized shearing ensuring square ends within ±3mm deviation, ideal for reducing on-site waste and installation labor costs.

Get a Competitive Quote for China Color Coated Steel Roof Panel

Contact our technical sales team to receive factory-direct pricing tailored to your project specifications. Provide details including required thickness, color preferences, profile type, quantity, and delivery destination for comprehensive quotations including material cost, surface treatment options, packaging specifications, and logistics coordination. Volume discounts available for orders exceeding 100 metric tons with flexible payment terms for established construction partners.

China Color coated steel roof panel manufacturer

China Color coated steel roof panel wholesale

Ratings & Reviews

5.0

Very satisfied

Based on 8 reviews for verified purchases

Supplier service

5.0

On-time shipment

5.0

Supplier service

5.0

David Anderson

Canada

verified purchases

2025-09-09

Premium Quality Repeat Order for Mining Sector
Third consecutive order totaling 52 tons of heavy-gauge 0.70mm panels for mining equipment shelters in northern Alberta. Material consistently demonstrates superior low-temperature impact resistance critical for -40°C winter operations. Zinc coating and paint adhesion remain intact after two years field exposure in first installation. Custom slitting to 950mm width reduces waste for our standard building modules. Factory maintains excellent quality control with zero rejected coils across all orders. Delivery to Vancouver averaged 24 days with reliable scheduling for our project timelines.

William Taylor

Australia

verified purchases

2025-09-27

Acceptable Quality with Resolved Packaging Issue
Ordered 18 tons of 0.40mm panels for marina facility roof replacement. Product quality met Australian standards with proper test documentation. Initial shipment had inadequate moisture protection causing surface rust spots on approximately 8% of materials. Supplier immediately arranged replacement sheets air-freighted at their cost and improved packaging for remaining order. Final delivered product performed as specified. Communication during problem resolution was professional. Would recommend requesting enhanced export packaging for long sea transit to Southern Hemisphere ports.

Ahmed Al-Hassan

UAE

verified purchases

2025-10-14

Perfect Solution for Extreme Heat Environment
Selected silicon-modified polyester coating system for 35 tons order serving Dubai warehouse project exposed to 50°C+ summer temperatures. Color coating adhesion tested at 100% per cross-hatch method, no delamination after thermal cycling tests. Panels in light colors (RAL 9002) demonstrating excellent solar reflectance reducing cooling loads. Width precision at 1220mm (±1mm variance) facilitated rapid installation. Supplier accommodated urgent 20-day delivery schedule. This is our fourth project using their materials for Gulf region climate demands.

Carlos Silva

Brazil

verified purchases

2025-11-01

Reliable Quality for Large-Scale Project
Supplied 85 tons across three shipments for shopping center roofing covering 12,000 square meters. Consistency between batches was good with color matching within acceptable Delta E standards. Base metal thickness measured 0.48mm average (specified 0.50mm, within ±0.02mm tolerance). Packaging was adequate though two coils had minor handling marks on edges not affecting usable area. Communication during production was responsive. Overall satisfied with quality-to-price ratio for this volume. Transit time to Santos Port averaged 38 days per container.

Hans Mueller

Germany

verified purchases

2025-11-19

Outstanding Technical Support and Documentation
Ordered 25 tons of 0.55mm trapezoidal profile panels in custom RAL 7016 for industrial facility expansion. Engineering team provided detailed CAD drawings and load-bearing calculations within 48 hours of inquiry. All products accompanied by comprehensive mill certificates documenting tensile strength (368 MPa), impact resistance per ASTM D2794, and color fastness data. Third-party SGS inspection arranged at factory before shipment. Material performed excellently during installation in winter conditions. Lead time was 31 days including custom color formulation.

Michael Torres

United States

verified purchases

2025-12-08

Good Value Polyester Coated Panels
Purchased 40 tons of 0.45mm corrugated panels with standard polyester coating for agricultural building project. Price was competitive compared to domestic suppliers, approximately 18% lower for equivalent specifications. Material quality meets ASTM A653 Z180 requirements with acceptable surface finish. Delivery took 33 days total including ocean freight to Houston. Minor issue with one pallet having slight edge waviness (within 3mm tolerance but visible), supplier quickly offered 5% credit adjustment. Would order again for budget-conscious projects.

James Wilson

United Kingdom

verified purchases

2025-12-23

Superior Zinc Coating for Coastal Application
We specified Z275 galvanized substrate (0.60mm thickness) for a seaside resort roofing project requiring enhanced corrosion protection. Material test certificates confirmed zinc coating weight at 278 g/m² with uniform distribution. Ordered 28 tons in custom lengths up to 11 meters, cutting tolerance maintained within ±2mm as promised. Yield strength tested at 295 MPa, exceeding GB/T 12754 minimum requirements. This is our second order this year. Panels arrived FOB Southampton in 26 days from deposit payment.

Robert Chen

Singapore

verified purchases

2026-01-07

Excellent PVDF Coating Performance for Tropical Climate
Ordered 32 tons of 0.50mm color coated roof panels in RAL 5015 for our commercial warehouse project. PVDF coating thickness verified at 25 micrometers with complete ASTM D3363 test certificates showing 2H pencil hardness. After 6 months installation in high-humidity tropical environment, zero chalking or fading observed. Salt spray resistance exceeded 1200 hours per lab reports. Production completed in 22 days, delivery to Jurong Port was seamless. Technical team provided excellent support during profile selection.
