Cold Rolled Color Coated Steel Coil - Mill Direct Supplier
China
Supplier's customization ability
- Drawing-based customization
- Sample-based customization
- Full customization
Minimum order quantity: 1 ton
Shipping total: To be negotiated
- Lead time:
- confirmed with the quotation
- Packaging:
- standard export packing
- Samples:
- available on request
Product details
Technical Specifications of Cold Rolled Color Coated Steel Coil
| Property | Parameter | Description |
|---|---|---|
| Product Name | Cold Rolled Color Coated Steel Coil | Pre-painted cold rolled steel coil with organic coating on substrate |
| Material Grade | CGCC / DX51D+Z / TDC51D | Equivalent to ASTM A755, EN 10169, JIS G3312 grades; base metal cold rolled low carbon steel |
| Standard Compliance | ASTM A755 / EN 10169 / JIS G3312 / GB/T 12754 | Meets international pre-painted steel coil standards for structural and decorative use |
| Chemical Composition | C ≤0.12%, Mn ≤0.60%, P ≤0.045%, S ≤0.045%, Si ≤0.50% | Low carbon cold rolled substrate ensuring good formability and paint adhesion |
| Tensile Strength | 270–560 MPa | Varies by substrate grade; per EN 10169 / ASTM A755 requirements |
| Yield Strength | 140–420 MPa | Dependent on base material grade and temper; suitable for roll forming and bending |
| Elongation | ≥16–30% | High elongation ensures crack-free forming during profiling and deep drawing |
| Substrate Thickness | 0.14–1.50 mm | Total thickness including coating; base metal thickness range for standard applications |
| Coil Width | 600–1,500 mm | Custom slit widths available; standard widths 914 mm, 1,000 mm, 1,219 mm, 1,250 mm |
| Coating Type | Polyester (PE) / PVDF / SMP / HDP / Epoxy | Top coat 5–25 μm; primer 5–7 μm; back coat 5–15 μm; PVDF for high weather resistance |
| Zinc Coating (Base) | Z60–Z275 g/m² (hot-dip galvanized substrate) | Galvanized or galvalume substrate provides corrosion protection beneath organic coating |
| Surface Finish | Smooth / Embossed / Matte / High Gloss / Textured | RAL color system available; 60° gloss value 10–85 GU; uniform color consistency |
| Coil Weight | 3–10 MT per coil | Inner diameter 508 mm or 610 mm; outer diameter up to 1,500 mm |
| Application | Roofing, wall cladding, home appliances, garage doors, HVAC ducts, signage | Widely used in construction, automotive interiors, and household appliance panels |
| Certification | ISO 9001 / SGS / BV / CE / RoHS | Third-party inspection available; mill test certificate (MTC) provided per EN 10204 3.1 |
| Packaging | Eye-to-sky or eye-to-wall on wooden pallet; waterproof paper + steel strip strapping | Moisture-proof inner wrapping; suitable for sea freight, rail, and road transport |
| MOQ | 25 MT per order | Mixed grades and colors accepted; OEM color matching available with minimum 50 MT |
Cold Rolled Color Coated Steel Coil - Mill Direct Supplier
Cold rolled color coated steel coil represents one of the most versatile and aesthetically refined flat steel products available in today's construction and manufacturing markets. Produced by applying a polymer-based coating onto a cold rolled steel substrate, this material combines the dimensional precision of cold rolling with long-lasting surface protection and vibrant color retention. It finds extensive application in roofing panels, wall cladding, home appliances, automotive interior components, and commercial shelving systems. With a base metal thickness typically ranging from 0.12 mm to 1.5 mm and a total coated thickness that may reach up to 1.6 mm, these coils deliver consistent flatness tolerances within ±0.02 mm, ensuring seamless downstream processing. As a mill-direct supplier, we source material conforming to EN 10169, ASTM A755, and GB/T 12754 standards, guaranteeing traceable quality from melt to finished coil. Whether your project demands standard RAL colors or custom-matched shades, our cold rolled color coated steel coil portfolio covers the full spectrum of industrial and architectural requirements.
What is Cold Rolled Color Coated Steel Coil?
Cold rolled color coated steel coil is a flat-rolled steel product manufactured by continuously applying one or more layers of organic coating—such as polyester (PE), polyvinylidene fluoride (PVDF), or silicon-modified polyester (SMP)—onto a cold rolled, galvanized, or galvalume substrate. The result is a corrosion-resistant, color-stable material with a smooth surface finish that retains its mechanical properties, including a minimum yield strength of 250 MPa for structural grades, while offering superior decorative performance.
Cold Rolled Color Coated Steel Coil Manufacturing Process
Production begins with a premium-grade cold rolled or hot-dip galvanized coil substrate, which undergoes alkaline degreasing, chromate or chrome-free passivation, and primer application in a continuous coil coating line. A topcoat layer—commonly 15–25 µm for polyester or 25–35 µm for PVDF—is then applied and cured in a controlled thermal oven at temperatures between 200°C and 260°C. A protective backing coat of 5–10 µm is simultaneously applied to the reverse side, completing the sandwich structure before recoiling.
Cold Rolled Color Coated Steel Coil Technical Specifications
Our cold rolled color coated steel coils are available in the following standard parameters:
- Base substrate: Cold rolled steel (SPCC/DC01), galvanized (DX51D+Z), or galvalume (DX51D+AZ)
- Total thickness: 0.12 mm – 1.5 mm (tolerance ±0.02 mm)
- Coil width: 600 mm – 1,500 mm (slit-to-width service available)
- Zinc coating mass: Z60 – Z275 g/m² (per EN 10346 / ASTM A653)
- Topcoat type: PE (15–25 µm), SMP (25 µm), PVDF (25–35 µm)
- Pencil hardness: ≥ 2H (ASTM D3363)
- T-bend flexibility: 0T – 2T (ASTM D4145)
- Salt spray resistance: ≥ 500 hours (ASTM B117) for standard PE; ≥ 1,000 hours for PVDF grades
- Color options: Full RAL chart; custom color matching available with ΔE ≤ 1.0
- Coil weight: 3–8 MT per coil; inner diameter 508 mm or 610 mm
- Applicable standards: EN 10169, ASTM A755/A755M, GB/T 12754
All coils are inspected for surface defects, coating adhesion, and color uniformity prior to dispatch, with full mill test certificates (MTC) provided for every heat.
