| Property | Parameter | Description |
|---|---|---|
| Product Name | Matte Finish Color Coated Aluminum Plate | Pre-painted aluminum plate with low-gloss matte surface coating |
| Material Grade | 1100, 3003, 3105, 5052, 6061 (AA Standard) | Equivalent to EN AW-1100, EN AW-3003, EN AW-5052; JIS A1100, A3003 |
| Standard Compliance | ASTM B209, EN 485-2, GB/T 3880 | Coating standard per ASTM D3359, EN 13523; color per RAL/Pantone system |
| Chemical Composition (Al) | Al ≥ 99.00% (1100); Al+Mn: 3003; Al+Mg: 5052 | Si ≤ 0.25%, Fe ≤ 0.40%, Cu ≤ 0.05–0.20%, Mn 0–1.5%, Mg 0–2.5% |
| Tensile Strength | 110–290 MPa (varies by alloy/temper) | 1100-H14: ≥110 MPa; 3003-H14: ≥150 MPa; 5052-H32: ≥230 MPa (ASTM B209) |
| Yield Strength | 85–215 MPa | 1100-H14: ≥95 MPa; 3003-H14: ≥130 MPa; 5052-H32: ≥195 MPa |
| Elongation | 3–12% | Varies by alloy and temper; 5052-H32: ≥12%; 3003-H14: ≥3% (per ASTM B209) |
| Thickness Range | 0.20–4.00 mm | Common coil thickness: 0.30–1.50 mm; sheet up to 4.00 mm available |
| Width Range | 100–2650 mm | Standard widths: 1000 mm, 1220 mm, 1500 mm; custom slitting available |
| Length | Coil or 1000–6000 mm sheets | Coil inner diameter: 505 mm or 610 mm; sheet cut-to-length on request |
| Coating Type | PVDF, PE (Polyester), FEVE | Matte gloss level: 10–30 GU (60° gloss meter per ASTM D523); dry film thickness 20–35 µm |
| Surface Finish | Matte (low-gloss) color coated, one-side or two-side | Smooth matte texture; anti-fingerprint, UV-resistant; primer coat 5–8 µm + top coat |
| Color Options | RAL, Pantone, NCS custom colors | White, grey, black, champagne, wood grain, and custom colors available |
| Application | Architecture, interior decoration, signage, ACP panels, appliances | Curtain walls, ceilings, roofing, furniture panels, electronic enclosures |
| Certification | ISO 9001, SGS, RoHS, REACH | PVDF coating meets AAMA 2605; PE coating meets AAMA 2603 standards |
| Packaging | Waterproof paper + wooden pallet or steel coil packaging | PE protective film on surface; export seaworthy packaging available |
| MOQ | 1 MT (coil); 500 kg (sheet) | Standard lead time: 15–25 days; sample order accepted |
Color Variance in First Shipment – Resolved Promptly
Our initial order of 4 tonnes of 1100-H14 matte charcoal plates at 1.0 mm showed a noticeable Delta E variance of approximately 1.8 between two coils, which was outside our accepted tolerance for signage panel production. We raised the issue immediately with the supplier's QC team, who confirmed the discrepancy and arranged replacement coils within 14 days at no additional cost. The replacement batch was fully within spec. The supplier also provided updated CIE Lab reports going forward. Issue was handled professionally. We have since placed a follow-up order and quality has been consistent.
