Alloy Color Coated Aluminum Sheet - Mill Direct Supplier

Xinpeng Color Coating Co., Ltd.

Verified Custom manufacturer · 2 yrs ·

China

Customizable Rock-bottom price

$2980 1-49 ton Base price

$2849 50-99 ton 4.4% off

$2783 ≥100 ton 6.6% off

Price validity: subject to market conditions

Supplier's customization ability

Drawing-based customization
Sample-based customization
Full customization

Quantity

Minimum order quantity: 1 ton

Shipping total: To be negotiated

Subtotal of goods US$ 2,980.00

Start order request

Payment and delivery

Payment:: by contract — deposit, balance after your inspection
Lead time:: confirmed with the quotation
Packaging:: standard export packing
Samples:: available on request

Product details

Technical Specifications of Alloy Color Coated Aluminum Sheet

Property	Parameter	Description
Product Name	Alloy Color Coated Aluminum Sheet	Pre-painted aluminum sheet with alloy substrate and polymer coating
Material Grade	1100, 3003, 3105, 5052, 6061 (AA/EN AW equivalent)	Common alloy grades; 3003 and 5052 most widely used for coated applications
Standard Compliance	ASTM B209, EN 573-3, GB/T 3880, JIS H4000	Substrate standards; coating per ASTM D3359, EN 13523 series
Chemical Composition (3003)	Al≥98.6%, Mn: 1.0–1.5%, Cu: 0.05–0.20%, Fe≤0.7%, Si≤0.6%	Balanced Mn content provides improved strength over 1xxx series
Chemical Composition (5052)	Al≥95.25%, Mg: 2.2–2.8%, Cr: 0.15–0.35%, Fe≤0.4%, Si≤0.25%	Mg-Cr alloying enhances corrosion resistance and formability
Tensile Strength	110–290 MPa (varies by alloy and temper)	3003-H14: ≥150 MPa; 5052-H32: ≥210 MPa per ASTM B209
Yield Strength	85–240 MPa	3003-H14: ≥130 MPa; 5052-H32: ≥160 MPa
Elongation	4–12%	Measured on 50 mm gauge length; higher elongation for O temper
Coating Type	PVDF, PE (Polyester), SMP, HDP	PVDF offers superior UV resistance; PE suitable for interior applications
Coating Thickness	Top coat: 18–25 μm; Primer: 5–8 μm; Back coat: 8–12 μm	Total dry film thickness per EN 13523-1 measurement method
Thickness Range	0.2–4.0 mm	Standard coil/sheet thickness; custom gauges available on request
Width Range	600–2200 mm	Slit coils available from 20 mm; standard widths 1000/1220/1500 mm
Length / Coil Weight	Sheets: 1000–6000 mm; Coils: 2–5 MT per coil	Cut-to-length sheets or coil supply; inner diameter 405/505 mm
Surface Finish	Smooth, Embossed, Brushed, Wood-grain, Stone-pattern	RAL/Pantone custom color matching available; gloss range 10–90 GU
Application	ACP panels, roofing, cladding, signage, interior decoration, automotive trim	Widely used in construction, transportation, and consumer electronics sectors
Certification	ISO 9001, SGS, CE, RoHS, REACH	Mill test certificate (MTC) per EN 10204 3.1 available upon request
Packaging	Eye-to-sky coils on wooden pallets; sheets interleaved with PE film	Waterproof kraft paper wrapping; export seaworthy packaging standard
MOQ	5 MT per order (mixed alloys/colors acceptable)	Sample orders accepted; lead time 15–25 days for standard specifications

Alloy Color Coated Aluminum Sheet - Mill Direct Supplier

Alloy color coated aluminum sheet is a premium-grade surface-treated metal product that finds extensive application across construction, transportation, home appliances, and industrial manufacturing sectors. Produced by applying high-performance organic coatings — such as PVDF, polyester (PE), or epoxy — onto alloy aluminum substrates, these sheets deliver a compelling combination of aesthetic appeal, structural integrity, and long-term durability. The coating process not only enhances visual versatility with a broad spectrum of RAL and custom colors, but also significantly improves resistance to UV radiation, moisture, and chemical exposure. As a mill-direct supplier, we offer consistent product quality backed by rigorous quality control at every production stage, ensuring that each sheet meets international standards such as ASTM B209, EN 485, and GB/T 17748. Whether you require standard stock dimensions or custom-cut panels for large-scale projects, our alloy color coated aluminum sheet solutions are engineered to meet the most demanding specifications at cost-effective mill-direct rates.

Alloy color coated aluminum sheet manufacturer

What is Alloy Color Coated Aluminum Sheet?

Alloy color coated aluminum sheet refers to an aluminum alloy substrate — commonly 1100, 3003, 3105, 5052, or 6061 series — that has been pre-treated, primed, and finished with one or more layers of organic coating. The result is a lightweight yet structurally robust panel that combines the natural corrosion resistance of aluminum with enhanced surface protection and decorative functionality, making it suitable for both interior and exterior environments.

Alloy color coated aluminum sheet supplier

Alloy Color Coated Aluminum Sheet Manufacturing Process

Manufacturing begins with selecting a qualified alloy substrate, followed by degreasing and chromate or chromate-free chemical pre-treatment to ensure optimal coating adhesion. A primer coat is applied first, then one or two finish coats of PVDF or polyester resin are cured in a continuous coil-coating furnace at temperatures between 200°C and 250°C. Final inspection includes adhesion cross-cut testing, pencil hardness evaluation (≥2H), and T-bend flexibility assessment to confirm coating integrity before coiling and packaging.

Alloy color coated aluminum sheet wholesale

Alloy Color Coated Aluminum Sheet Technical Specifications

Available alloy grades include 1100-H14, 3003-H16, 3105-H24, and 5052-H32, with thickness ranging from 0.20 mm to 4.00 mm and width up to 1,600 mm. Tensile strength varies by alloy — for instance, 5052-H32 achieves a minimum of 228 MPa per ASTM B209. Coating thickness for PVDF finish is typically 25–30 µm (top coat) with a 5–7 µm primer, offering a salt spray resistance exceeding 1,000 hours per ASTM B117. Gloss level is customizable from 10 to 85 GU (60° geometry), and more than 200 standard RAL colors are available alongside custom color matching services.

Get a Competitive Quote for Alloy Color Coated Aluminum Sheet

Partner with our mill-direct team to source alloy color coated aluminum sheet at transparent, factory-level pricing. We support OEM specifications, custom dimensions, and sample requests to help you evaluate quality before placing bulk orders. Our experienced technical team is ready to assist with alloy selection, coating system recommendations, and compliance documentation.

24/7 customer support available
Free samples for quality evaluation
Competitive pricing for bulk orders
Professional technical consultation

Contact us today to get your free quote within 24 hours!

Ratings & Reviews

4.5

Based on 8 reviews

5 5

4 2

3 1

2 0

1 0

Ahmed K.

UAE

2025-02-01

Initial colour batch variance flagged — resolved promptly, quality now confirmed

Our first order of 5 tonnes of 3105-H24 at 0.80 mm in a custom sand-beige tone showed a visible gloss variance between two coils — one measured 38 GU, the other 29 GU against our approved 35 GU target. We raised this immediately. The supplier's quality team acknowledged the batch inconsistency within 24 hours, arranged replacement coils at no additional cost, and shipped within 8 days. The replacement batch measured 34–36 GU consistently. ASTM B117 salt spray data on the replacement was also provided. Issue was handled professionally. We have since placed a follow-up order and quality has been consistent.

Oliver H.

United Kingdom

2025-02-22

Competitive pricing and consistent quality — slight lead time extension on custom width

We placed an order for 7 tonnes of 3003-H16 at 0.60 mm, custom width 1,500 mm, polyester finish in RAL 6019. Standard orders from this supplier typically arrive in 18–20 days, but the custom width pushed lead time to 28 days — not a problem once flagged upfront, but we'd have preferred earlier communication. Product itself was excellent: gloss at 45 GU matched the sample, coating adhesion GT0, and no edge waviness on the custom-width coils. Mill-direct pricing saved us approximately 12% versus our previous UK-based distributor. Overall a solid B2B supplier relationship.

Jennifer L.

United States

2025-03-16

Good value for PVDF coated 5052 — minor documentation delay but product is solid

Ordered 15 tonnes of 5052-H32 at 1.00 mm with PVDF finish in RAL 9003 for a West Coast commercial project. Product quality is genuinely strong — coating thickness averaged 26 µm, salt spray performance confirmed beyond 1,000 hours, and tensile values aligned with ASTM B209. Our only friction point was that the third-party inspection report arrived 3 days after the shipment departed, which caused a brief hold at customs. The team resolved it quickly by sending digital copies within hours of our call. Pricing at mill-direct rates is competitive versus domestic distributors. Would order again.
