| Property | Parameter | Description |
|---|---|---|
| Product Name | Prepainted Steel Coil (PPGI/PPGL) | Color-coated galvanized or galvalume steel coil |
| Base Material | Cold Rolled / Hot-Dip Galvanized / Galvalume | Multiple substrate options available |
| Standard Compliance | ASTM A755, EN 10169, JIS G3312, GB/T 12754 | Meets major international standards |
| Zinc Coating | Z40 - Z275 (40-275 g/m²) | Galvanized coating weight per ASTM A653 |
| Base Metal Thickness | 0.12 - 1.2 mm | Available substrate thickness range |
| Width Range | 600 - 1250 mm | Standard and custom widths |
| Coil Weight | 3 - 8 tons | Typical coil weight per roll |
| Top Paint Coating | PE, SMP, HDP, PVDF | Polyester, silicone modified, high durability, fluorocarbon |
| Top Coat Thickness | 15 - 25 μm | Front side paint film thickness |
| Back Coat Thickness | 5 - 15 μm | Reverse side protective coating |
| Pencil Hardness | ≥2H (PE) / ≥3H (PVDF) | Surface hardness per ASTM D3363 |
| Gloss Level | 10-90% (60° angle) | Adjustable gloss per ASTM D523 |
| Bend Resistance | ≤2T (PE) / ≤1T (SMP) | T-bend flexibility test result |
| Color Options | RAL, Pantone, or custom colors | Wide range of color matching available |
| Yield Strength | ≥235 - 550 MPa | Depends on base metal grade (G250-G550) |
| Application | Roofing, wall cladding, sandwich panels, appliances | Typical application industries |
| Certification | ISO 9001, SGS, BV, EN 10204 3.1 | Quality certifications provided |
| Packaging | Eye-to-sky, waterproof paper, steel strip bundled | Standard seaworthy export packaging |
| MOQ | 25 tons | Minimum order quantity per color |
Acceptable PPGI Coils — Surface Marking Issue Resolved After Claim
Ordered 20 tons of PPGI coils, 0.3mm thickness, 800mm width, PE coating, RAL 1015 light ivory for re-export to a Southeast Asian buyer. Upon inspection at our Singapore warehouse, we identified minor surface roller marks on approximately 15% of one coil — visible under direct light but not affecting paint adhesion or mechanical properties. Submitted a photographic claim within 48 hours of receipt. Supplier responded within one business day, reviewed the photos, and agreed to a partial credit of 3% on the affected coil weight. Resolution was fair and handled professionally. MTCs and other coils in the shipment were fully compliant. We would consider reordering for non-critical surface applications, but will request pre-shipment SGS inspection for future orders involving cosmetic-grade surface requirements.
