| Property | Parameter | Description |
|---|---|---|
| Product Name | Custom Length Steel Bars for Construction | Hot-rolled or cold-drawn steel bars cut to specified lengths for structural and reinforcement applications |
| Material Grade | ASTM A615 Gr.40/60, BS4449 B500B, HRB400/HRB500 (GB) | Equivalent grades: S400/S500 (EN), SD390/SD490 (JIS G3112); grade selected per project requirement |
| Standard Compliance | ASTM A615/A615M, EN 10080, JIS G3112, GB/T 1499.2 | Meets international construction and structural reinforcement standards |
| Chemical Composition | C ≤ 0.30%, Mn ≤ 1.60%, Si ≤ 0.55%, P ≤ 0.045%, S ≤ 0.045%, Ceq ≤ 0.55% | Composition controlled for weldability, ductility, and corrosion resistance in structural use |
| Tensile Strength | ≥ 550 MPa (Gr.60 / HRB400); ≥ 620 MPa (HRB500) | Per ASTM A615M and GB/T 1499.2; ensures load-bearing capacity in reinforced concrete structures |
| Yield Strength | ≥ 400 MPa (HRB400); ≥ 500 MPa (HRB500); ≥ 420 MPa (Gr.60) | Minimum yield strength guaranteed per applicable standard; critical for structural integrity |
| Elongation | ≥ 16% (HRB400); ≥ 15% (HRB500); ≥ 9% (ASTM Gr.60) | Measured on gauge length of 5d or 8d; ensures ductility under seismic and dynamic loads |
| Bar Diameter Range | 6 mm – 50 mm (round/deformed); flat bars 20×3 mm – 200×25 mm | Custom diameters and cross-sections available; deformed bars with standard rib patterns |
| Custom Length Range | 500 mm – 18,000 mm (custom cut-to-length) | Standard mill lengths 6 m / 9 m / 12 m; custom lengths cut per drawing or purchase order |
| Length Tolerance | +50 mm / 0 mm (standard); ±5 mm (precision cut) | Precision cutting available via CNC sawing or shearing for tight-tolerance construction projects |
| Surface Finish | Hot-rolled scaled, pickled, or galvanized (optional) | Deformed surface for rebar; smooth or polished for structural bars; epoxy-coated option available |
| Application | Reinforced concrete structures, bridges, foundations, columns, beams, retaining walls | Suitable for residential, commercial, and infrastructure construction projects worldwide |
| Certification | ISO 9001:2015, CE Marking, Mill Test Certificate (EN 10204 3.1/3.2) | Third-party inspection available; certificates traceable to heat/lot number |
| Packaging | Bundled in 2–5 MT bundles, steel-strapped; seaworthy packing available | Bundles labeled with grade, heat number, diameter, and length; export packing on request |
| MOQ | 5 MT per size/grade | Mixed container orders accepted; spot stock and scheduled production both available |
Initial length tolerance issue — resolved promptly by supplier
Our first order of 20 tons of D25 Grade 60 ASTM A615 bars in 11,000 mm custom lengths had around 3% of pieces measuring 11,040 mm to 11,060 mm — just outside the ±25 mm tolerance band. I raised this with the technical team immediately. They acknowledged the issue within four hours, issued a corrective action report, and arranged a partial replacement shipment at no charge within nine working days. The replacement batch was spot-on. The after-sales response was genuinely good and we have since placed a follow-up order. Worth noting for first-time buyers: verify a sample on receipt, but the support process works.
