| Property | Parameter | Description |
|---|---|---|
| Product Name | Deformed Steel Bars for Construction | Hot-rolled ribbed reinforcing bars with transverse and longitudinal ribs for enhanced concrete bonding |
| Material Grade | HRB400 / HRB500 / Grade 60 / B500B | Equivalent to ASTM A615 Gr.60, EN 10080 B500B, BS 4449 Grade 500B, GB/T 1499.2 HRB400/500 |
| Standard Compliance | ASTM A615 / EN 10080 / GB/T 1499.2 / BS 4449 / JIS G3112 | Meets international construction reinforcement standards for structural concrete applications |
| Chemical Composition – Carbon (C) | ≤ 0.25% | Controls hardness and weldability; lower carbon improves field welding performance |
| Chemical Composition – Manganese (Mn) | 0.60% – 1.60% | Enhances tensile strength and hardenability of the rebar |
| Chemical Composition – Silicon (Si) | 0.10% – 0.80% | Acts as deoxidizer; contributes to strength improvement |
| Chemical Composition – Phosphorus (P) | ≤ 0.045% | Strictly controlled to prevent cold brittleness in finished bars |
| Chemical Composition – Sulfur (S) | ≤ 0.045% | Controlled to avoid hot shortness and reduce ductility loss |
| Tensile Strength | 570 – 750 MPa | HRB400: ≥ 570 MPa; HRB500: ≥ 630 MPa; ASTM A615 Gr.60: ≥ 620 MPa (per respective standards) |
| Yield Strength | 400 – 500 MPa | HRB400: ≥ 400 MPa; HRB500: ≥ 500 MPa; ASTM Gr.60: ≥ 420 MPa |
| Elongation | ≥ 14% – 16% | Minimum elongation at fracture; ensures ductility for seismic and structural applications |
| Diameter Range | 6 mm – 50 mm | Common sizes: 6, 8, 10, 12, 14, 16, 18, 20, 22, 25, 28, 32, 36, 40, 50 mm |
| Length | 6 m / 9 m / 12 m or custom | Standard mill lengths; custom cutting available per project requirement |
| Surface Finish | Hot-rolled deformed (ribbed) surface | Transverse ribs and longitudinal ribs improve mechanical bond with concrete; mill scale finish |
| Application | Reinforced concrete structures | Foundations, beams, columns, slabs, bridges, tunnels, high-rise buildings, infrastructure projects |
| Certification | ISO 9001 / CE Marking / Mill Test Certificate (MTC) | Third-party inspection available; SGS, BV, TÜV reports upon request |
| Packaging | Bundled in hexagonal bundles, 2–5 MT per bundle | Steel wire tied; seaworthy export packing available; bare or with waterproof wrapping |
| MOQ | 25 MT per size | Mixed container orders accepted; full container load (FCL) preferred for export shipments |
Initial documentation delay — resolved satisfactorily before shipment
Ordered 180 MT of 16 mm and 22 mm deformed bars per GB/T 1499.2-2018 for a residential high-rise in Pune. The original MTCs provided were missing the silicon content data required by our project specification. I raised this with the technical team, who obtained a supplementary test report from the mill within 48 hours confirming silicon at 0.22%. Shipment was not delayed as the issue was caught early. Mechanical properties — yield 432 MPa, elongation 11% — were fully compliant. Customer service response was professional once the issue was flagged.
