Jacket Multi-Mode Fiber Wire For Industrial Supply

Anxun optical fiber Co., Ltd.

Verified Custom manufacturer · 7 yrs ·

China

Customizable Rock-bottom price

$85 1-49 kilometers Base price

$81 50-99 kilometers 4.7% off

$79 ≥100 kilometers 7.1% off

Price validity: subject to market conditions

Supplier's customization ability

Drawing-based customization
Sample-based customization
Full customization

Quantity

Minimum order quantity: 1 kilometers

Shipping total: To be negotiated

Subtotal of goods US$ 85.00

Start order request

Payment and delivery

Payment:: by contract — deposit, balance after your inspection
Lead time:: confirmed with the quotation
Packaging:: standard export packing
Samples:: available on request

Product details

Technical Specifications of Jacket Multi-Mode Fiber Wire

Property	Parameter	Description
Optical Fiber Product Name	Jacket Multi-Mode Fiber Wire	Jacketed multi-mode optical fiber wire for data transmission and networking applications
Fiber Grade & ITU-T Classification	OM1 / OM2 / OM3 / OM4 (ITU-T G.651.1)	Graded-index multi-mode fiber compliant with ITU-T G.651.1 standard series
Core & Cladding Diameter Range	Core: 50/62.5 μm; Cladding: 125 μm	Standard 50/125 μm or 62.5/125 μm configurations with tight tolerance ±1 μm
Attenuation Coefficient at 850nm	≤ 3.5 dB/km (OM1); ≤ 2.3 dB/km (OM3/OM4)	Low attenuation at 850 nm window for short-range high-speed transmission
Attenuation Coefficient at 1310nm	≤ 1.0 dB/km	Measured per IEC 60793-1-40 using OTDR method at 1310 nm wavelength
Attenuation Coefficient at 1550nm	≤ 0.8 dB/km	Measured per IEC 60793-1-40 using OTDR method at 1550 nm wavelength
Macrobending Loss Performance	≤ 0.5 dB at bend radius 15 mm (100 turns)	Tested per IEC 60793-1-47; jacket provides enhanced bend protection
Chromatic Dispersion Coefficient	≤ 3.5 ps/(nm·km) at 1310 nm	Modal and chromatic dispersion controlled for high-bandwidth multi-mode transmission
Bandwidth (Modal)	≥ 200 MHz·km (OM1); ≥ 4700 MHz·km (OM4)	Overfilled launch (OFL) bandwidth measured per IEC 60793-1-41
Batch Qualification Rate	≥ 99.5%	Each production batch undergoes 100% optical parameter testing before shipment
Manufacturing Environment Standards	ISO 9001:2015 / ISO 14001:2015 cleanroom production	Manufactured in dust-controlled environment; temperature and humidity strictly regulated
Core Raw Material Source	High-purity SiO₂ preform; LSZH / PVC jacket material	Silica core with low-smoke zero-halogen or PVC outer jacket for safety compliance
Packaging Specification	Wooden drum / plastic reel; 500 m, 1000 m, 2000 m per reel	Standard reel lengths available; custom lengths accepted upon request
Storage Conditions	Temperature: -20°C to +60°C; Humidity: 10%–85% RH (non-condensing)	Store in dry, ventilated warehouse away from direct sunlight and corrosive substances
Valid Shelf Life	≥ 20 years (under recommended storage conditions)	Jacket material UV-stabilized; fiber coating designed for long-term mechanical stability
Application Scenarios	LAN, data centers, CCTV, medical imaging, industrial automation, FTTH indoor wiring	Suitable for short-to-medium distance multi-mode transmission up to 550 m at 10 Gbps
Compliance & Certification	IEC 60793-2-10, RoHS, REACH, UL Listed, TIA-492AAAD	Meets international safety and environmental standards for global market access
Minimum Order Quantity (MOQ)	500 m per fiber type	Mixed specifications accepted; OEM and custom jacket color available above MOQ
Monthly Supply Capacity	500,000 m / month	Stable supply chain with buffer stock; lead time 7–15 business days for standard orders

Jacket Multi-Mode Fiber Wire For Industrial Supply

Jacket multi-mode fiber wire is a cornerstone solution in modern industrial and commercial communication infrastructure, delivering high-bandwidth optical transmission across short to medium distances with exceptional reliability. As data centers, manufacturing facilities, enterprise campuses, and FTTH networks continue to scale, the demand for robust jacketed multimode optical fiber cables has surged globally. This product serves as the backbone for structured cabling systems, supporting Gigabit Ethernet, 10G, 40G, and 100G transmission protocols. With a protective outer jacket engineered to withstand mechanical stress, chemical exposure, and extreme temperature fluctuations, jacketed multi-mode fiber wire ensures uninterrupted signal integrity in the most demanding industrial environments. Its versatility across indoor, outdoor, and plenum-rated installations makes it the preferred choice for system integrators, telecom contractors, and industrial procurement specialists seeking a dependable, cost-effective optical connectivity solution at competitive wholesale pricing.

What is Jacket Multi-Mode Fiber Wire?

Jacket multi-mode fiber wire is an optical cable consisting of one or more multi-mode glass or plastic fiber cores enclosed within a durable protective outer jacket, typically manufactured from LSZH, PVC, or polyurethane materials. Designed in compliance with IEC 60793, ITU-T G.651, and TIA-568 standards, it supports simultaneous transmission of multiple light modes, making it ideal for high-speed short-range data communication across distances up to 2,000 meters depending on the fiber grade and wavelength used.

Jacket Multi-Mode Fiber Wire Manufacturing and Production Process

Production of jacketed multimode fiber wire takes place in ISO-certified cleanroom environments where fiber preforms are precision-drawn at temperatures exceeding 2,000°C to achieve consistent core-cladding geometry. Each fiber strand undergoes UV-cured acrylate coating followed by tight-buffering or loose-tube stranding. The protective outer jacket is extruded using automated co-extrusion lines with real-time diameter monitoring. Every production batch is subjected to OTDR testing, tensile strength verification, and RoHS compliance screening before shipment approval.

Jacket multi-mode fiber wire supplier

Jacket Multi-Mode Fiber Wire Technical Specifications

Core/Cladding Diameter: OM1 62.5/125 µm, OM2/OM3/OM4 50/125 µm; Attenuation: ≤3.5 dB/km at 850 nm (OM1), ≤3.0 dB/km at 850 nm (OM3/OM4); Bandwidth: up to 4,700 MHz·km (OM4 at 850 nm); Operating Temperature: -40°C to +85°C; Jacket Material: LSZH / PVC / PE; Tensile Load: 600–2,700 N; Minimum Bend Radius: 10× cable outer diameter; Available Configurations: simplex, duplex, multi-fiber breakout (4F–144F).

Get a Competitive Quote for Jacket Multi-Mode Fiber Wire

Partner with our global supply team to source premium jacket multi-mode fiber wire at industry-leading wholesale rates. We support bulk OEM orders, custom jacket colors, and private-label packaging with fast lead times. All shipments include full certification documentation and are backed by our end-to-end logistics guarantee for timely, damage-free delivery worldwide.

Jacket multi-mode fiber wire manufacturer

24/7 expert optical communication engineer support
Full ITU-T, ISO, RoHS compliance guarantee for all batches
Exclusive wholesale discounts for bulk telecom, FTTH and data center orders
Complete technical data sheets and on-site deployment guidance included

Contact us today to get your free quote and full specification sheet within 24 hours!

Jacket multi-mode fiber wire wholesale

Ratings & Reviews

4.5

Based on 8 reviews

5 5

4 2

3 1

2 0

1 0

Oliver W.

United Kingdom

2025-02-02

Initial shipment had labeling inconsistency — supplier resolved promptly

Ordered 10,000 meters of OM4 50/125 µm LSZH 24-fiber breakout for a hospital network installation requiring strict IEC 60793 traceability. Upon receipt, approximately 8% of reels had batch number labels that did not match the accompanying OTDR test reports — a compliance concern for our client audit. I contacted the supplier immediately; their team issued corrected documentation within 48 hours and dispatched replacement labeled reels for the affected quantity within one week. Cable performance itself was fully within spec. Issue was resolved professionally, and I would consider reordering with closer QC coordination upfront.

David K.

United States

2025-02-24

Solid OM1 fiber quality for budget-conscious retrofit project

Purchased 4,000 meters of OM1 62.5/125 µm PVC simplex fiber for a building retrofit supporting legacy Gigabit Ethernet infrastructure. Attenuation measured at 3.4 dB/km at 850 nm — within the ≤3.5 dB/km spec. Tensile load rating of 600 N was adequate for our short conduit runs. Wholesale pricing was competitive and the quote turnaround was under 6 hours. Packaging could be improved — two reels had minor label adhesion issues on arrival, though the cable itself was undamaged. Would order again for similar retrofit scopes.

Linda H.

Australia

2025-03-18

Good value OM3 fiber for enterprise campus — minor documentation delay

Ordered 6,000 meters of OM3 50/125 µm 12-fiber breakout cable for a corporate campus 40G network installation. Cable performance met TIA-568 specifications with attenuation at 2.9 dB/km. Pricing was approximately 15% below our previous European supplier for equivalent spec. Delivery to Sydney took 16 days. One note: the full technical data sheet arrived two days after the shipment rather than simultaneously — not a major issue but worth flagging for time-sensitive projects. Overall strong value for bulk procurement at this price point.

Know your supplier

Anxun optical fiber Co., Ltd.

7 yrs on Sinoali.com

Located in China

Company information More goods

FAQ

Q: What types of multi-mode fiber do you supply?

A:We supply OM1, OM2, OM3, OM4 and OM5 multi-mode fiber cables and bulk fiber for different data transmission requirements.

Q: What is the difference between OM1, OM2, OM3, OM4 and OM5?

Q: What are the core and cladding diameters of multi-mode fiber?

Q: What applications are multi-mode fiber mainly used for?

Q: Do you offer indoor and outdoor multi-mode fiber cables?

Q: Can multi-mode fiber be mixed with single-mode fiber equipment?

Product display

Anxun Optical Fiber Co., Ltd. is a technology-driven enterprise specializing in the research, development, and manufacturing of high-quality optical fiber products and communication solutions. With a strong focus on innovation and precision engineering, the company provides a wide range of products, including fiber optic cables, connectivity components, and customized network solutions for telecommunications, data centers, and industrial applications.

Committed to international standards and strict quality control, Anxun ensures reliable performance and long-term durability in all its products. The company continuously invests in advanced production equipment and technical expertise to meet the evolving demands of global communication infrastructure. Guided by a customer-centric approach, Anxun Optical Fiber Co., Ltd. strives to deliver efficient, cost-effective, and sustainable solutions, building long-term partnerships with clients worldwide.
