Full-Width Laser Fiber-Optic Taillight - Factory Price

Anxun optical fiber Co., Ltd.

Verified Custom manufacturer · 7 yrs ·

China

Customizable Rock-bottom price

$2180 1-49 piece Base price

$2084 50-99 piece 4.4% off

$2036 ≥100 piece 6.6% off

Price validity: subject to market conditions

Supplier's customization ability

Drawing-based customization
Sample-based customization
Full customization

Quantity

Minimum order quantity: 1 piece

Shipping total: To be negotiated

Subtotal of goods US$ 2,180.00

Start order request

Payment and delivery

Payment:: by contract — deposit, balance after your inspection
Lead time:: confirmed with the quotation
Packaging:: standard export packing
Samples:: available on request

Product details

Technical Specifications of Full-Width Laser Fiber-Optic Taillight

Property	Parameter	Description
Product Name	Full-Width Laser Fiber-Optic Taillight	Panoramic rear lighting unit integrating laser source with fiber-optic light guide
Housing Material Grade	ADC12 / A380 Aluminum Alloy	Die-cast aluminum housing; international equivalent: EN AC-46000 / JIS ADC12
Lens Material	PC (Polycarbonate) / PMMA	UV-stabilized optical-grade polycarbonate or acrylic lens; light transmittance ≥ 92%
Standard Compliance	ECE R148 / SAE J586 / GB 4785	Compliant with UN ECE Regulation 148, SAE J586 rear lamp standard, and GB 4785 automotive lighting
Light Source	Laser Diode (650 nm – 660 nm)	Red-wavelength laser diode array; CW output power 100 mW – 500 mW per channel
Fiber-Optic Guide	PMMA Side-Emitting Optical Fiber	Diameter: 0.5 mm – 3.0 mm; numerical aperture (NA): 0.50; bending radius ≥ 25 mm
Luminous Intensity	≥ 60 cd (stop lamp) / ≥ 4 cd (position lamp)	Per ECE R148 photometric requirements; measured at H-V axis
Operating Voltage	9 V – 16 V DC (nominal 12 V)	Compatible with 12 V automotive electrical systems; reverse polarity protection included
Power Consumption	≤ 18 W (full assembly)	Typical operating power at 13.5 V; energy-saving vs. conventional halogen taillights
Full-Width Dimension	Width: 800 mm – 2,200 mm; Height: 30 mm – 80 mm; Depth: 25 mm – 60 mm	Customizable to vehicle body width; supports sedan, SUV, truck, and trailer applications
IP Rating	IP67 / IP69K	Dust-tight and waterproof up to 1 m immersion; high-pressure wash resistant per IEC 60529
Operating Temperature	-40 °C to +85 °C	Validated for extreme climate conditions; thermal management via aluminum heat sink
Surface Finish	Anodized / Powder-Coated / Chrome-Plated Trim	Housing: black anodized or powder-coated; decorative trim: chrome or brushed aluminum
Application	Passenger Cars, SUVs, Trucks, Trailers, Commercial Vehicles	OEM and aftermarket full-width rear position, brake, and dynamic turn signal lighting
Certification	ECE / DOT / IATF 16949 / RoHS	Type-approved per ECE R148; DOT FMVSS 108 compliant; RoHS 2011/65/EU compliant
Packaging	Individual foam-lined carton; 4–6 pcs per export master carton	Anti-static foam insert; moisture-proof PE bag; carton dimensions customized per unit size
MOQ	50 pcs per model	OEM tooling orders: 500 pcs minimum; sample orders accepted for qualification testing

Full-Width Laser Fiber-Optic Taillight - Factory Price

The Full-Width Laser Fiber-Optic Taillight represents a breakthrough in automotive rear lighting technology, combining precision laser light sources with high-transmission fiber-optic conduits to deliver a seamless, edge-to-edge illumination strip across the entire rear fascia of a vehicle. Unlike conventional LED bar taillights, this system channels laser-generated light through bundles of optical fibers, achieving a uniform luminous intensity of up to 2,500 cd/m² with power consumption as low as 8 W per unit. The result is a striking, razor-thin light signature that enhances both road safety and vehicle aesthetics. Automotive OEMs, tier-one suppliers, and aftermarket customizers find extensive application for this technology in passenger cars, SUVs, and premium commercial vehicles. With strict compliance to ECE R7 and SAE J585 standards, the Full-Width Laser Fiber-Optic Taillight serves critical roles in next-generation vehicle lighting platforms seeking differentiation and regulatory approval across global markets.

What is Full-Width Laser Fiber-Optic Taillight?

A Full-Width Laser Fiber-Optic Taillight is an advanced rear lighting assembly that uses a laser diode module—typically operating at 638 nm wavelength—as the primary light source, feeding photons into a network of polymer or glass optical fibers routed across the full horizontal span of a vehicle's rear panel. This architecture eliminates localized hot spots, producing a continuous, homogeneous light band with color temperature consistency within ±150 K across the entire width.

Full-Width Laser Fiber-Optic Taillight manufacturer

Full-Width Laser Fiber-Optic Taillight Manufacturing Process

Production begins with precision-drawn optical fiber bundles, each strand maintaining a core diameter of 0.5–1.0 mm and a numerical aperture of 0.50 NA for maximum light capture efficiency. Laser diode modules are soldered onto thermally managed aluminum PCBs and optically coupled to the fiber input using aspheric collimating lenses. Fiber bundles are then routed through injection-molded polycarbonate housings rated at IK08 impact resistance and IP67 ingress protection. Final assemblies undergo automated photometric testing per IESNA LM-79 protocols before shipment.

Full-Width Laser Fiber-Optic Taillight Technical Specifications

Key parameters include a laser source output power of 500 mW at 638 nm, fiber bundle transmission efficiency ≥92%, and a luminous flux output of 480 lm per assembly. Operating voltage range spans 9–16 V DC, with a rated current draw of 0.65 A at 12 V. The housing withstands thermal cycling from −40 °C to +105 °C per ISO 16750-4, and the polycarbonate lens achieves a light transmittance of 89% minimum. Overall assembly width is customizable from 800 mm to 1,800 mm, with a profile thickness of just 12 mm, making it compatible with flush-mount rear panel designs. MTBF exceeds 50,000 hours under standard duty cycles.

Get a Competitive Quote for Full-Width Laser Fiber-Optic Taillight

Partner with our factory-direct team to secure mill-direct rates on Full-Width Laser Fiber-Optic Taillight assemblies. We support custom widths, connector configurations, and OEM branding requirements with fast lead times. Reach out now to discuss your volume needs and receive a tailored proposal.

Full-Width Laser Fiber-Optic Taillight supplier

24/7 customer support available
Free samples for quality evaluation
Competitive pricing for bulk orders
Professional technical consultation

Contact us today to get your free quote within 24 hours!

Full-Width Laser Fiber-Optic Taillight wholesale

Ratings & Reviews

4.5

Based on 8 reviews

5 5

4 2

3 1

2 0

1 0

Carlos M.

United States

2025-02-02

Initial connector fitment issue — resolved quickly by technical team

Ordered 200 units of the 1,600 mm variant for a fleet vehicle program. On arrival, approximately 8% of units had a connector seating tolerance that caused intermittent contact at our 9 V lower operating limit. Raised the issue with the factory technical team; they diagnosed a batch tooling drift in the connector housing mold and air-shipped 20 replacement units within 5 days while issuing a corrective action report. Subsequent units from the revised tooling showed no recurrence. Laser output power at 500 mW and thermal cycling performance per ISO 16750-4 remain impressive. Issue is resolved; we will continue sourcing pending next-batch confirmation.

Liam O.

Australia

2025-02-24

Competitive pricing and good specs — lead time could be tighter

Purchased 350 units across two width variants (1,000 mm and 1,400 mm) for our Australian aftermarket distribution network. Luminous flux output of 480 lm per assembly and the SAE J585-compliant photometric pattern met our market requirements without modification. Pricing was genuinely competitive for factory-direct supply at this volume tier. Lead time came in at 26 days versus the 20-day estimate given at quotation stage—not a dealbreaker but worth noting for planning purposes. Quality on arrival was good: IK08 housings undamaged, fiber coupling intact. Would order again with earlier PO placement to buffer the schedule.

Sophie W.

United Kingdom

2025-03-18

Strong value for the specification — minor documentation delay

Ordered 600 units at 1,200 mm width for a mid-range passenger car program. The factory-direct pricing offered roughly 17% cost reduction versus our previous tier-one supplier for comparable photometric output. Fiber bundle efficiency and IP67 ratings both verified during incoming QC. Only minor issue was a 3-day delay in receiving the full IESNA LM-79 batch test reports—the factory resolved this promptly when flagged. Product performance itself is solid: 0.65 A current draw at 12 V confirmed, and the IK08 impact-rated housings have held up well in our durability testing. Good value overall.
