Aerial Outdoor Optical Fiber Cable for High-Speed Networks

Anxun optical fiber Co., Ltd.

Verified Custom manufacturer · 7 yrs ·

China

Customizable Rock-bottom price

$112 1-49 kilometers Base price

$107 50-99 kilometers 4.5% off

$105 ≥100 kilometers 6.3% off

Price validity: subject to market conditions

Supplier's customization ability

Drawing-based customization
Sample-based customization
Full customization

Quantity

Minimum order quantity: 1 kilometers

Shipping total: To be negotiated

Subtotal of goods US$ 112.00

Start order request

Payment and delivery

Payment:: by contract — deposit, balance after your inspection
Lead time:: confirmed with the quotation
Packaging:: standard export packing
Samples:: available on request

Product details

Technical Specifications of Aerial Outdoor Optical Fiber

Property	Parameter	Description
Optical Fiber Product Name	Aerial Outdoor Optical Fiber	Self-supporting or lashed aerial fiber cable designed for outdoor overhead deployment
Fiber Grade & ITU-T Classification	G.652D / G.657A1 / G.657A2	Single-mode fiber compliant with ITU-T standards for aerial long-haul and access networks
Core & Cladding Diameter Range	Core: 8.2–9.0 μm; Cladding: 125.0 ± 0.7 μm	Standard single-mode geometry ensuring low splice loss and compatibility with connectors
Attenuation Coefficient at 1310nm	≤ 0.34 dB/km	Measured per IEC 60793-1-40; suitable for metro and access aerial links
Attenuation Coefficient at 1550nm	≤ 0.20 dB/km	Low loss at C-band wavelength enabling long-span aerial transmission
Macrobending Loss Performance	≤ 0.10 dB (R=15 mm, 1550 nm); ≤ 0.50 dB (R=10 mm, 1550 nm)	Compliant with ITU-T G.657A2; resistant to bending stress from wind and ice loading
Chromatic Dispersion Coefficient	≤ 18 ps/(nm·km) at 1550 nm; ≤ 3.5 ps/(nm·km) at 1310 nm	Meets ITU-T G.652D dispersion specification for standard single-mode fiber
Batch Qualification Rate	≥ 99.5%	Per-reel screening with proof test at 100 kpsi; full attenuation and geometry verification
Manufacturing Environment Standards	ISO 9001:2015; Class 1000 cleanroom fiber draw	Controlled humidity and particle environment during preform collapse and fiber drawing
Core Raw Material Source	High-purity synthetic SiO₂ preform (OVD/VAD process)	Ultra-low OH content preform ensuring consistent optical performance across reels
Packaging Specification	Wooden reel; 2 km, 4 km, 6 km per reel; reel diameter 500–800 mm	Moisture-resistant wrapping with end-cap protection; labeled with reel ID and test data
Storage Conditions	Temperature: -20°C to +60°C; Humidity: ≤ 85% RH, non-condensing	Store indoors on flat surface; avoid direct UV exposure and mechanical compression
Valid Shelf Life	≥ 25 years (installed); 2 years (warehoused on reel)	UV-stabilized jacket and gel-filled loose tube design extend outdoor service life
Application Scenarios	FTTH aerial drop, ADSS self-supporting spans, figure-8 lashed cable, rural last-mile	Suitable for span lengths 50–200 m; withstands wind load ≥ 900 Pa and ice load ≥ 10 mm
Compliance & Certification	ITU-T G.652D / G.657A1 / G.657A2; IEC 60794-1; RoHS 2011/65/EU; CE	Third-party test reports available; UL listing optional upon request
Minimum Order Quantity (MOQ)	10 reels (≥ 20 km total fiber length)	Mixed reel lengths accepted within single order; custom reel length available ≥ 50 km order
Monthly Supply Capacity	≥ 500,000 km fiber / month	Supported by automated draw towers with inline geometry and attenuation monitoring

Aerial Outdoor Optical Fiber Cable for High-Speed Networks

Aerial outdoor optical fiber cable has established itself as a cornerstone infrastructure solution for modern high-speed telecommunications networks worldwide. Designed specifically for overhead deployment along utility poles, towers, and suspension systems, this category of outdoor fiber optic cable delivers exceptional signal integrity across long-distance spans while withstanding the harshest environmental conditions. From rural broadband expansion and FTTH last-mile connectivity to backbone transmission corridors and smart grid communications, aerial optical fiber cable serves as the preferred choice for network operators, utility providers, and municipal telecom planners. The global demand for aerial fiber optic cable continues to surge as governments and private enterprises accelerate 5G rollout, fiber-to-the-home projects, and cross-regional data transmission initiatives. With proven mechanical resilience, low attenuation performance, and cost-effective installation advantages over underground alternatives, aerial outdoor optical fiber cable represents outstanding market value for large-scale network deployments across diverse geographic and climatic environments.

Aerial Outdoor Optical Fiber supplier

What is Aerial Outdoor Optical Fiber Cable?

Aerial outdoor optical fiber is a ruggedized fiber optic cable engineered for overhead, self-supporting, or lashed installation in outdoor environments. Compliant with ITU-T G.652D, G.657A, IEC 60794, and ANSI/ICEA standards, it typically incorporates single-mode or multimode glass fibers encased in UV-resistant polyethylene sheathing, with reinforced steel or aramid yarn strength members to withstand wind load, ice accumulation, and mechanical tension across pole-to-pole spans.

Aerial Outdoor Optical Fiber Manufacturing and Production Process

Production of aerial outdoor fiber optic cable begins with precision optical fiber drawing in ISO-certified clean-room facilities, followed by tight or loose tube stranding around a central strength member. Gel-filling or dry water-blocking compounds are applied for moisture protection. Armored steel wire or dielectric FRP reinforcement layers are added before UV-stabilized HDPE outer jacket extrusion. Every production batch undergoes 100% attenuation testing, tensile load verification, and temperature cycling validation per IEC 60794-1 protocols to ensure full RoHS and REACH compliance.

Aerial Outdoor Optical Fiber manufacturer

Aerial Outdoor Optical Fiber Technical Specifications

Key technical parameters for standard aerial outdoor optical fiber cable include: fiber count options from 2 to 288 cores; attenuation ≤0.35 dB/km at 1310 nm and ≤0.20 dB/km at 1550 nm (ITU-T G.652D); tensile strength up to 2700 N (installation) and 1000 N (long-term); operating temperature range −40°C to +70°C; minimum bend radius 20× cable diameter; outer jacket thickness ≥1.8 mm HDPE; cable diameter 8–18 mm; span length support up to 80 m pole spacing; UV resistance rated for 25+ years outdoor service life.

Get a Competitive Quote for Aerial Outdoor Optical Fiber

Whether you are sourcing aerial outdoor optical fiber cable for a national FTTH rollout, rural broadband project, or urban 5G backhaul deployment, our factory offers competitive wholesale pricing, flexible MOQ policies, and full documentation support including ITU-T compliance certificates and third-party test reports. Global logistics with DDP and FOB shipping options ensure reliable on-time delivery to any destination.

24/7 expert optical communication engineer support
Full ITU-T, ISO, RoHS compliance guarantee for all batches
Exclusive wholesale discounts for bulk telecom, FTTH and data center orders
Complete technical data sheets and on-site deployment guidance included

Contact us today to get your free quote and full specification sheet within 24 hours!

Aerial Outdoor Optical Fiber wholesale

Ratings & Reviews

4.5

Based on 8 reviews

5 5

4 2

3 1

2 0

1 0

Tariq A.

UAE

2025-02-01

Initial shipment had documentation gap — resolved promptly

Ordered 40,000 meters of 96-core G.652D aerial cable for a smart city backbone project in Dubai. The cable itself performed well — attenuation at 1550 nm was ≤0.20 dB/km and operating temperature tolerance up to +70°C is critical for our climate. However, the initial shipment was missing the required third-party REACH compliance test report, which caused a two-day delay at customs. After contacting the support team, the documentation was emailed within four hours and the issue was fully resolved. Cable quality and technical specs are not in question — documentation process just needs tightening.

Liam F.

Australia

2025-02-22

Solid performance on outback aerial deployment — good price point

Used 60,000 meters of 36-core aerial outdoor cable for a remote area broadband project with extreme UV exposure and wide daily temperature swings. HDPE outer jacket showed no cracking or discoloration after six weeks of outdoor staging. IEC 60794 compliance was verified. Span performance at 75-meter pole spacing was stable. Pricing was about 15% below comparable Australian-sourced product. Delivery took 26 days to Sydney port via FOB, which was acceptable for the project timeline. Would appreciate faster customs pre-clearance documentation next time.

Oliver M.

United Kingdom

2025-03-16

Good value for 48-core aerial cable — minor packaging feedback

Ordered 25,000 meters of 48-core G.652D aerial fiber for a regional ISP expansion project. Attenuation performance at 1310 nm was within spec at ≤0.34 dB/km and UV resistance labeling confirmed 25-year outdoor rating. Price per meter at this volume was notably competitive versus European suppliers. Only minor issue was that two reels had slightly compressed cardboard cores on arrival — not affecting the cable itself, but worth noting for export packaging. Technical datasheet was detailed and compliance certificates were all present. Would order again.

Know your supplier

Anxun optical fiber Co., Ltd.

7 yrs on Sinoali.com

Located in China

Company information More goods

FAQ

Q: What types of outdoor fiber optic cables do you supply?

A:We supply aerial, direct buried, duct, armored, non-armored and ADSS all-dielectric outdoor fiber cables.

Q: What is the difference between armored and non-armored outdoor fiber cable?

Q: Can your outdoor fiber cables be used directly buried underground?

Q: What fiber types are available for outdoor cables?

Q: What is the operating temperature range of outdoor fiber cable?

Q: Do your outdoor fiber cables have waterproof performance?

Product display

Anxun Optical Fiber Co., Ltd. is a technology-driven enterprise specializing in the research, development, and manufacturing of high-quality optical fiber products and communication solutions. With a strong focus on innovation and precision engineering, the company provides a wide range of products, including fiber optic cables, connectivity components, and customized network solutions for telecommunications, data centers, and industrial applications.

Committed to international standards and strict quality control, Anxun ensures reliable performance and long-term durability in all its products. The company continuously invests in advanced production equipment and technical expertise to meet the evolving demands of global communication infrastructure. Guided by a customer-centric approach, Anxun Optical Fiber Co., Ltd. strives to deliver efficient, cost-effective, and sustainable solutions, building long-term partnerships with clients worldwide.
