Aerial Outdoor Optical Fiber Cable for High-Speed Networks

Anxun optical fiber Co., Ltd.

Verified Custom manufacturer · 7 yrs ·

China

Customizable Rock-bottom price

$285 1-49 kilometers Base price

$273 50-99 kilometers 4.2% off

$266 ≥100 kilometers 6.7% off

Price validity: subject to market conditions

Supplier's customization ability

Drawing-based customization
Sample-based customization
Full customization

Quantity

Minimum order quantity: 1 kilometers

Shipping total: To be negotiated

Subtotal of goods US$ 285.00

Start order request

Payment and delivery

Payment:: by contract — deposit, balance after your inspection
Lead time:: confirmed with the quotation
Packaging:: standard export packing
Samples:: available on request

Product details

Technical Specifications of Aerial Outdoor Optical Fiber

Property	Parameter	Description
Optical Fiber Product Name	Aerial Outdoor Optical Fiber	Self-supporting or lashed aerial fiber cable designed for outdoor overhead deployment
Fiber Grade & ITU-T Classification	ITU-T G.652D / G.657A1 / G.657A2	Single-mode fiber compliant with ITU-T standards for aerial long-haul and access network applications
Core & Cladding Diameter Range	Core: 8.2–9.2 μm; Cladding: 125 ± 0.7 μm	Standard single-mode geometry ensuring compatibility with industry splicing and connector equipment
Attenuation Coefficient at 1310nm	≤ 0.34 dB/km	Low attenuation at 1310 nm wavelength window for short to medium distance transmission
Attenuation Coefficient at 1550nm	≤ 0.20 dB/km	Ultra-low attenuation at 1550 nm for long-haul aerial transmission with minimal signal loss
Macrobending Loss Performance	≤ 0.10 dB (R=30 mm, 100 turns, 1550 nm)	Excellent bend resistance suitable for aerial installation with wind-induced sway and vibration
Chromatic Dispersion Coefficient	≤ 18 ps/(nm·km) at 1550 nm	Controlled dispersion ensuring signal integrity over extended aerial fiber spans
Batch Qualification Rate	≥ 99.5%	High-consistency production with rigorous batch testing to ensure uniform optical performance
Manufacturing Environment Standards	ISO 9001:2015; Class 1000 Cleanroom	Produced under controlled cleanroom conditions to prevent contamination and ensure fiber quality
Core Raw Material Source	High-purity SiO₂ preform (OVD/MCVD process)	Optical-grade silica preform manufactured via Outside Vapor Deposition or Modified Chemical Vapor Deposition
Packaging Specification	Wooden drum; 2 km, 4 km, 6 km per reel	Standard wooden reels with moisture-proof wrapping suitable for aerial cable project logistics
Storage Conditions	Temperature: -20°C to +60°C; Humidity: ≤ 85% RH	Store in dry, ventilated warehouse away from direct sunlight and corrosive substances
Valid Shelf Life	≥ 20 years (installed); 2 years (stored on reel)	Long operational lifespan with UV-resistant jacket and anti-corrosion coating for aerial environments
Application Scenarios	FTTH aerial drop, OPGW, ADSS, inter-building links, rural broadband	Widely used in overhead power line corridors, campus networks, and last-mile aerial fiber deployments
Compliance & Certification	ITU-T G.652D, IEC 60794-1, RoHS, CE, TIA-568	Meets international optical fiber cable standards for aerial outdoor installation and environmental compliance
Minimum Order Quantity (MOQ)	10 km (≈ 2–5 reels depending on reel length)	Flexible MOQ available for project-based procurement; custom reel lengths negotiable for large orders
Monthly Supply Capacity	500,000 km/month (fiber); 50,000 km/month (cable)	Large-scale production capacity supporting national and international aerial fiber infrastructure projects

Aerial Outdoor Optical Fiber Cable for High-Speed Networks

Aerial outdoor optical fiber cable stands as one of the most critical infrastructure components in modern telecommunications, enabling high-speed data transmission across vast distances without the need for costly underground trenching. Designed specifically for overhead deployment on utility poles, towers, and self-supporting spans, this category of outdoor fiber optic cable serves a wide range of applications including metropolitan area networks (MAN), rural broadband expansion, FTTH last-mile connectivity, power utility communication, and inter-city backbone links. As global demand for reliable, high-bandwidth connectivity surges, aerial optical fiber solutions have become indispensable for telecom operators, ISPs, and enterprise network builders seeking cost-effective, scalable, and weather-resistant cabling infrastructure. With superior mechanical strength, UV resistance, and long-span capability, aerial outdoor fiber optic cables deliver consistent performance in the most demanding outdoor environments worldwide.

Aerial Outdoor Optical Fiber manufacturer

What is Aerial Outdoor Optical Fiber Cable?

Aerial outdoor optical fiber cable is a ruggedized fiber optic cable engineered for overhead, above-ground installation along poles, towers, or messenger wires. Compliant with ITU-T G.652D, G.657A2, and IEC 60794 international standards, these cables integrate single-mode or multimode optical fibers within protective sheaths featuring UV-stabilized polyethylene jackets, aramid yarn strength members, and optional steel or FRP messenger wire for self-supporting configurations. They are purpose-built to withstand wind loading, ice accumulation, temperature cycling, and prolonged UV exposure.

Aerial Outdoor Optical Fiber supplier

Aerial Outdoor Optical Fiber Cable Manufacturing and Production Process

Production of aerial outdoor optical fiber cable takes place in ISO 9001:2015-certified facilities under strict environmental controls. The manufacturing process begins with precision fiber drawing from high-purity silica preforms, followed by secondary coating, SZ-stranding of fiber bundles, and application of water-blocking gel or tape layers. Central strength members of steel wire or FRP are integrated before extrusion of the UV-stabilized HDPE outer sheath. Each production batch undergoes 100% optical attenuation testing, tensile load verification, and crush resistance evaluation to ensure full IEC, RoHS, and REACH compliance.

Aerial Outdoor Optical Fiber Cable Technical Specifications

Key technical parameters for aerial outdoor fiber optic cable include: fiber count options from 2 to 288 cores; attenuation ≤0.34 dB/km at 1310 nm and ≤0.20 dB/km at 1550 nm (ITU-T G.652D); tensile strength up to 2,700 N (installation) and 670 N (long-term); operating temperature range of -40°C to +70°C; minimum bend radius of 15× cable diameter; span length up to 80 m without messenger wire and up to 150 m with integrated steel messenger; outer diameter ranging from 8 mm to 22 mm depending on fiber count and construction type.

Get a Competitive Quote for Aerial Outdoor Optical Fiber

Ready to source premium aerial outdoor optical fiber cable for your next network deployment? We supply certified aerial fiber optic cables in bulk quantities with flexible MOQ, competitive wholesale pricing, and fast global logistics to over 80 countries. Request your customized quote today and receive full technical documentation within 24 hours.

24/7 expert optical communication engineer support
Full ITU-T, ISO, RoHS compliance guarantee for all batches
Exclusive wholesale discounts for bulk telecom, FTTH and data center orders
Complete technical data sheets and on-site deployment guidance included

Contact us today to get your free quote and full specification sheet within 24 hours!

Aerial Outdoor Optical Fiber wholesale

Ratings & Reviews

4.5

Based on 8 reviews

5 5

4 2

3 1

2 0

1 0

Robert Callahan

United States

2025-01-28

Initial Documentation Gap — Resolved Promptly by Support Team

Ordered 18,000 meters of 48-core aerial cable with integrated steel messenger for a New Jersey utility communication project. The cable itself performed well in the field — tensile strength and attenuation figures checked out against IEC 60794 spec. However, the initial shipment was missing the RoHS and REACH compliance certificates our client required for project sign-off, which caused a two-day hold. After contacting support, the full compliance documentation package was emailed within four hours and a hard copy followed by courier. Issue was resolved satisfactorily. Cable quality itself was not in question — just ensure documentation is requested explicitly at order stage.

Daniel Forsythe

United Kingdom

2025-02-19

Competitive Pricing on Bulk Aerial Fiber — Quality Meets Spec

Ordered 25,000 meters of 12-core and 36-core aerial ADSS cables for a Scottish Highlands broadband project. Pricing per meter was around 15% below comparable EU-sourced product for equivalent ITU-T G.652D specification, which made a meaningful difference on a tight project budget. Optical performance verified against spec on arrival. The outer diameter of 10 mm on the 12-core variant was slightly larger than the datasheet indicated, which required minor clamp adjustments — not a major issue but worth flagging. Technical team responded helpfully. Delivery in 20 days was acceptable. Would use again for cost-sensitive projects.

Ahmed Al-Rashidi

UAE

2025-03-13

Good Value for MAN Deployment — Minor Lead Time Delay Noted

Purchased 50,000 meters of 24-core and 48-core G.652D aerial cables for a metropolitan area network project in Dubai. Cable quality is solid — UV-stabilized HDPE jacket performance in 45°C ambient temperatures has been reliable so far, and attenuation figures match the spec sheet. Pricing was noticeably more competitive than regional alternatives for equivalent IEC 60794-compliant product. Only minor issue was a 4-day delay on the second shipment tranche, though the logistics team communicated proactively and adjusted documentation quickly. Overall good value; would order again for Phase 2 expansion.

Know your supplier

Anxun optical fiber Co., Ltd.

7 yrs on Sinoali.com

Located in China

Company information More goods

FAQ

Q: What types of outdoor fiber optic cables do you supply?

A:We supply aerial, direct buried, duct, armored, non-armored and ADSS all-dielectric outdoor fiber cables.

Q: What is the difference between armored and non-armored outdoor fiber cable?

Q: Can your outdoor fiber cables be used directly buried underground?

Q: What fiber types are available for outdoor cables?

Q: What is the operating temperature range of outdoor fiber cable?

Q: Do your outdoor fiber cables have waterproof performance?

Product display

Anxun Optical Fiber Co., Ltd. is a technology-driven enterprise specializing in the research, development, and manufacturing of high-quality optical fiber products and communication solutions. With a strong focus on innovation and precision engineering, the company provides a wide range of products, including fiber optic cables, connectivity components, and customized network solutions for telecommunications, data centers, and industrial applications.

Committed to international standards and strict quality control, Anxun ensures reliable performance and long-term durability in all its products. The company continuously invests in advanced production equipment and technical expertise to meet the evolving demands of global communication infrastructure. Guided by a customer-centric approach, Anxun Optical Fiber Co., Ltd. strives to deliver efficient, cost-effective, and sustainable solutions, building long-term partnerships with clients worldwide.
