| Property | Parameter | Description |
|---|---|---|
| Product Name | Low Loss Pre Terminated Fiber Cable | Factory-terminated fiber optic cable assembly with ultra-low insertion loss connectors |
| Fiber Type | Single-mode (OS2) / Multimode (OM3, OM4, OM5) | ITU-T G.652D for SM; IEC 60793-2-10 for MM; grade selected per application bandwidth |
| Standard Compliance | IEC 61754-20, TIA-568.3-D, IEC 61300-3-4 | Connector interface, cabling performance, and insertion loss test method standards |
| Insertion Loss (Typical) | ≤ 0.10 dB (SM) / ≤ 0.15 dB (MM) | Per mated connector pair; measured per IEC 61300-3-4 using mandrel wrap method |
| Return Loss | ≥ 55 dB (UPC) / ≥ 65 dB (APC) | Measured per IEC 61300-3-6; APC recommended for single-mode long-haul links |
| Cable Attenuation | ≤ 0.20 dB/km @ 1550 nm (SM) / ≤ 0.35 dB/km @ 850 nm (MM) | Fiber attenuation per IEC 60793-1-40; contributes to total link loss budget |
| Connector Type | LC/UPC, LC/APC, SC/UPC, SC/APC, MPO/MTP | Polish grade and ferrule type matched to network architecture; MPO for high-density use |
| Ferrule Material | Zirconia Ceramic (ZrO₂) | High hardness, low thermal expansion; ensures consistent end-face geometry and low loss |
| Cable Construction | Simplex, Duplex, Ribbon, Breakout, Trunk | Jacket options: LSZH, PVC, Plenum (OFNP); armored versions available for harsh environments |
| Cable Diameter | 2.0 mm / 3.0 mm (simplex/duplex); 4.5–25 mm (trunk) | Outer diameter varies by fiber count (1F–144F) and jacket type |
| Operating Temperature | -20°C to +70°C (storage: -40°C to +85°C) | Per IEC 60794-1-2 Method F1; suitable for indoor data center and outdoor conduit routing |
| Tensile Load Rating | ≤ 150 N (short-term) / ≤ 50 N (long-term) | Per IEC 60794-1-2 Method E1; Kevlar aramid yarn reinforcement standard |
| Cable Length | 1 m – 300 m (custom lengths available) | Factory pre-cut and terminated; length tolerance ±1%; longer runs on request |
| Surface Finish / End-Face | PC / UPC / APC polished | End-face geometry per IEC 61300-3-35; 100% tested with interferometer before shipment |
| Application | Data centers, MTP/MPO trunk systems, telecom PON, FTTH, enterprise LAN, 5G fronthaul | Optimized for high-density patching, structured cabling, and low-latency optical networks |
| Certification | RoHS, REACH, UL Listed (OFNR/OFNP), CE, ISO 9001 | Compliance documentation and test reports provided with each shipment |
| Packaging | Individual polybag with dust caps; bulk in ESD-safe reel or coiled box | Connector end-faces protected with dust caps; labeled with part number, length, and fiber type |
| MOQ | 10 pcs per SKU | Custom assemblies available from 1 pc; volume pricing for orders ≥ 500 pcs |
Initial batch had two faulty connectors — replacement handled promptly
Ordered 60 units of MPO 12-fiber OM4 trunk cables for a data center pilot in Dallas. Two connectors in the batch showed insertion loss of 0.35 dB — well above the ≤0.10 dB spec — flagged during our incoming inspection using OTDR. I raised the issue with support and received replacement units within 4 business days, no questions asked. The replacement cables tested perfectly. The QC miss was disappointing given the 100% end-face inspection claim, but the resolution was fast and professional. Will give them another chance on the next order.
