| Property | Parameter | Description |
|---|---|---|
| Product Name | Prefabricated Color Steel Sheet | Pre-painted galvanized/galvalume steel sheet for prefabricated structures |
| Material Grade | DX51D, DX52D, S280GD, S350GD | Equivalent to ASTM A653 CS/SS, JIS G3302 SGCC/SGCD |
| Standard Compliance | GB/T 12754, EN 10346, ASTM A755 | Meets international standards for prepainted metallic coated steel |
| Chemical Composition (C) | ≤ 0.12% | Low carbon content ensures formability and weldability |
| Chemical Composition (Mn) | ≤ 0.60% | Manganese for strength and hardness balance |
| Chemical Composition (P/S) | P ≤ 0.045%, S ≤ 0.045% | Controlled impurities for improved ductility |
| Tensile Strength | 270–560 MPa | Per GB/T 12754 and EN 10346; grade-dependent |
| Yield Strength | 220–420 MPa | Suitable for load-bearing prefabricated building panels |
| Elongation | ≥ 16–22% | Ensures flexibility during roll-forming and installation |
| Base Metal Coating | Z60–Z275 (Galvanized), AZ50–AZ150 (Galvalume) | Hot-dip zinc or zinc-aluminum alloy coating for corrosion resistance |
| Paint Coating | Top coat: 15–25 µm; Primer: 5–7 µm | Polyester (PE), PVDF, SMP; UV and weather resistant |
| Thickness Range | 0.3 mm – 1.5 mm | Standard base metal thickness excluding coating |
| Width Range | 600 mm – 1250 mm | Custom slit widths available upon request |
| Length / Coil Weight | Coil: 3–8 tons; Sheet: 1000–6000 mm | Supplied as coils or cut-to-length sheets |
| Surface Finish | Smooth, embossed, matte, high-gloss | RAL color system available; consistent color uniformity |
| Application | Roofing, wall cladding, sandwich panels, warehouses, prefab buildings | Widely used in industrial, commercial, and residential construction |
| Certification | ISO 9001, CE, SGS, BV | Quality management and third-party inspection certified |
| Packaging | Eye-to-sky or eye-to-wall coils; waterproof paper + steel strip | Seaworthy export packaging to prevent transit damage |
| MOQ | 25 tons per order | Mixed specifications accepted; OEM color and size available |
Color variance on first shipment — resolved promptly by supplier
Ordered 40 tonnes of 0.6 mm PE-coated color steel sheet in RAL 1013 for a commercial development in Dubai. The first shipment showed a visible color variance between two coil batches — noticeable when panels were installed side-by-side. We raised the issue with the sales team, who investigated within 24 hours, confirmed a batch mixing error, and arranged replacement panels at no additional cost within 15 days. Replacement batch was perfectly consistent. Zinc coating (Z275) and tensile specs (≥550 MPa) were correct throughout. Issue has been resolved satisfactorily and we're cautiously placing a second order.
