Heavy Rail Steel Supplier - AREMA Standard Rail 115RE 136RE for Railway Track
China
Supplier's customization ability
- Drawing-based customization
- Sample-based customization
- Full customization
Minimum order quantity: 1 ton
Shipping total: To be negotiated
- Lead time:
- confirmed with the quotation
- Packaging:
- standard export packing
- Samples:
- available on request
Product details
Technical Specifications of Heavy Rail
| Property | Parameter | Description |
|---|---|---|
| Product Name | Heavy Rail | Hot-rolled steel rail for railway track construction, also known as heavy steel rail or railroad rail |
| Material Grade | U71Mn / 900A / R260 | Equivalent grades: GB U71Mn, EN 13674 R260, AREMA 136RE, UIC 60 |
| Standard Compliance | GB 2585 / EN 13674 / AREMA / TB/T 2344 | Compliant with Chinese, European, and American railway rail standards |
| Carbon (C) | 0.65% - 0.82% | Primary strengthening element for rail hardness and wear resistance |
| Manganese (Mn) | 0.70% - 1.30% | Enhances tensile strength and hardenability of rail steel |
| Silicon (Si) | 0.15% - 0.58% | Improves strength and deoxidation during steelmaking |
| Phosphorus (P) | ≤ 0.030% | Controlled to minimize cold brittleness |
| Sulfur (S) | ≤ 0.030% | Controlled to prevent hot shortness and improve rail integrity |
| Tensile Strength | ≥ 880 MPa | Per GB 2585 / EN 13674 for R260 grade; ensures load-bearing capacity under heavy axle loads |
| Yield Strength | ≥ 460 MPa | Minimum yield point ensuring resistance to permanent deformation |
| Elongation | ≥ 10% | Measured on gauge length of 50 mm per applicable standard |
| Rail Profiles | 43 kg/m, 50 kg/m, 60 kg/m, 75 kg/m | Common profiles include 50N, UIC60, 136RE; weight per meter ≥ 38 kg/m classified as heavy rail |
| Rail Length | 12.5 m / 25 m / 50 m / 100 m | Standard and long-welded rail lengths available; custom lengths upon request |
| Surface Finish | Hot-rolled / Head-hardened | Optional online or offline head hardening for enhanced wear and rolling contact fatigue resistance |
| Application | Mainline railway, high-speed rail, heavy haul freight, metro transit, crane rail | Suitable for axle loads from 25 t to 40 t in passenger and freight operations |
| Certification | ISO 9001 / CE / IRIS / CRCC | Third-party inspection available: SGS, BV, Lloyd's |
| Packaging | Bundled in stacks, secured with steel straps | Rust-preventive oil coating optional; marked with grade, length, and heat number |
| MOQ | 30 Metric Tons | Smaller quantities negotiable based on profile and grade availability |
Heavy Rail Steel Supplier - AREMA Standard Rail 115RE 136RE for Railway Track
Heavy rail steel serves as the backbone of modern railway infrastructure, bearing the immense loads of freight trains and high-speed passenger services across thousands of miles of track. As a professional heavy rail supplier with over a decade of experience in steel product export, we provide AREMA-standard rail sections including 115RE, 136RE, and other profiles engineered for demanding mainline railway applications. Whether you are constructing new rail corridors, upgrading existing track, or sourcing replacement rail for maintenance programs, our mill-direct supply chain ensures premium-grade heavy rail delivered to your project site with full material certification and competitive pricing.
What is Heavy Rail?
Heavy rail refers to steel rail sections with a linear mass of 30 kg/m (approximately 60 lb/yd) or greater, specifically designed for mainline railway operations carrying heavy axle loads. In North American standards, heavy rail profiles such as 115RE (57.0 kg/m) and 136RE (67.5 kg/m) are manufactured to AREMA (American Railway Engineering and Maintenance-of-Way Association) specifications. These rails feature a robust head-web-base geometry optimized for fatigue resistance, wear durability, and safe wheel-rail contact under repeated loading cycles exceeding 35-ton axle loads.
Heavy Rail Technical Specifications
Our heavy rail products are manufactured from high-carbon steel with precise chemical and mechanical properties to meet rigorous railway performance standards. Below are the key specifications for our most requested profiles:
| Specification | 115RE Rail | 136RE Rail |
|---|---|---|
| Linear Mass | 57.0 kg/m (115 lb/yd) | 67.5 kg/m (136 lb/yd) |
| Rail Height | 168.3 mm (6.625 in) | 185.7 mm (7.3125 in) |
| Head Width | 69.1 mm (2.719 in) | 74.6 mm (2.938 in) |
| Base Width | 139.7 mm (5.5 in) | 152.4 mm (6.0 in) |
| Carbon Content | 0.72%–0.82% | 0.72%–0.82% |
| Minimum Tensile Strength | 880 MPa (128 ksi) | 880 MPa (128 ksi) |
| Minimum Hardness (Head) | 300 HB | 300 HB |
| Standard Length | 24.38 m (80 ft) / 25 m | 24.38 m (80 ft) / 25 m |
| Standard | AREMA | AREMA |
Additional rail grades are available, including head-hardened (HH) variants with surface hardness reaching 340–390 HB for curves and high-wear zones. All rails undergo ultrasonic testing and straightness inspection per AREMA Chapter 4 requirements before shipment.
Applications of Heavy Rail Steel in Railway Construction
Heavy rail finds extensive application across diverse railway environments where load-bearing capacity and long service life are critical. The 136RE profile is the standard choice for Class I freight railroads in North America, supporting gross rail loads exceeding 315,000 lbs per car. The 115RE section serves branch lines, industrial sidings, and transit systems where moderate traffic density allows a lighter rail profile without compromising safety. Beyond conventional railways, heavy rail sections are also specified for port rail infrastructure, mining haul roads, and heavy-duty crane runways where repeated high-impact loading demands superior fatigue performance.
Get a Competitive Quote for Heavy Rail
Partner with a trusted heavy rail supplier offering mill-direct rates, full AREMA-compliant material test reports, and flexible logistics solutions for domestic and international projects. We support orders from single-track maintenance quantities to large-scale new construction volumes.
- 24/7 customer support available
- Free samples for quality evaluation
- Competitive pricing for bulk orders
- Professional technical consultation
Contact us today to get your free quote within 24 hours!
