S235JR H Beam - EN Certified Steel Supplier | Factory Price
China
Supplier's customization ability
- Drawing-based customization
- Sample-based customization
- Full customization
Minimum order quantity: 1 ton
Shipping total: To be negotiated
- Lead time:
- confirmed with the quotation
- Packaging:
- standard export packing
- Samples:
- available on request
Product details
Technical Specifications of S235JR H Beam
| Property | Parameter | Description |
|---|---|---|
| Product Name | S235JR H Beam | Hot rolled structural H-shaped steel beam |
| Material Grade | S235JR | Equivalent to ASTM A36, Q235B (GB), SS400 (JIS) |
| Standard Compliance | EN 10025-2 | European standard for hot rolled structural steel |
| Carbon (C) | ≤ 0.17% | Maximum carbon content per EN 10025-2 |
| Manganese (Mn) | ≤ 1.40% | Ensures strength and toughness |
| Silicon (Si) | ≤ 0.035% | Deoxidizer element |
| Phosphorus (P) | ≤ 0.035% | Controlled for improved weldability |
| Sulfur (S) | ≤ 0.035% | Controlled to prevent hot shortness |
| Tensile Strength | 360 - 510 MPa | Per EN 10025-2 for nominal thickness ≤ 16 mm |
| Yield Strength | ≥ 235 MPa | Minimum yield strength for thickness ≤ 16 mm |
| Elongation | ≥ 26% | Measured on standard test specimen (Lo = 5.65√So) |
| Size Range | 100×100 - 900×300 mm | Flange width: 100 - 300 mm; Length: 6 - 12 m or customized |
| Web Thickness | 5 - 16 mm | Varies by section size per EN 10365 |
| Flange Thickness | 8 - 28 mm | Varies by section size per EN 10365 |
| Surface Finish | Hot Rolled / Black / Primed | Optional anti-rust primer or galvanized coating available |
| Application | Construction, Bridges, Industrial Plants | Widely used in building frames, platforms, and infrastructure projects |
| Certification | EN 10204 3.1, CE, ISO 9001 | Mill test certificate provided with each shipment |
| Packaging | Bundled with steel strips | Waterproof paper or plastic caps on ends upon request |
| MOQ | 5 Metric Tons | Smaller quantities available upon negotiation |
S235JR H Beam - EN Certified Steel Supplier | Factory Price
S235JR H beam is one of the most widely specified structural steel profiles in construction and engineering projects across Europe, the Middle East, and beyond. Manufactured in accordance with EN 10025-2, this hot-rolled H-shaped section delivers a reliable combination of strength, weldability, and cost efficiency that makes it ideal for load-bearing frameworks. As a mill-direct supplier with EN certification, we provide S235JR H beams in a comprehensive range of sizes — from HEA 100 to HEB 1000 — with consistent quality control and factory-direct pricing. Whether you are sourcing material for commercial building frames, industrial warehouses, bridge supports, or infrastructure projects, our S235JR H beam stock is ready for prompt shipment with full mill test certificates (MTC EN 10204 3.1) included with every order.
What Is S235JR H Beam?
An S235JR H beam is a hot-rolled structural steel section with an H-shaped cross-section, produced to the European standard EN 10025-2. The designation "S235" indicates a minimum yield strength of 235 MPa for thicknesses ≤ 16 mm, while "JR" signifies a Charpy V-notch impact toughness of 27 Joules at room temperature (20°C). This profile features two parallel flanges connected by a vertical web, creating a geometry that efficiently resists bending and shear forces. S235JR H beams are available in HEA (light), HEB (standard), and HEM (heavy) series, conforming to dimensional tolerances specified in EN 10365.
S235JR H Beam Technical Specifications
The following table outlines the key chemical composition and mechanical properties of S235JR steel per EN 10025-2:
| Property | Value |
|---|---|
| Standard | EN 10025-2:2019 |
| Carbon (C) max | 0.17% (≤ 16 mm) |
| Manganese (Mn) max | 1.40% |
| Silicon (Si) max | — |
| Phosphorus (P) max | 0.035% |
| Sulfur (S) max | 0.035% |
| Yield Strength (≤ 16 mm) | ≥ 235 MPa |
| Tensile Strength | 360–510 MPa |
| Elongation (min) | 26% (for nominal thickness ≤ 40 mm) |
| Impact Toughness (JR) | 27 J at 20°C |
| Density | 7.85 g/cm³ |
Common S235JR H beam dimensions range from HEA 100 (96 mm height, 100 mm flange width, 16.7 kg/m) to HEB 600 (600 mm height, 300 mm flange width, 212 kg/m). Standard lengths are 6 m, 9 m, and 12 m, with custom cutting available upon request.
Key Applications of S235JR H Beams
S235JR H beam sections serve critical roles in a wide range of structural applications due to their superior load-distribution characteristics and excellent weldability. Primary applications include:
- Commercial and residential building frames — columns, beams, and portal frames
- Industrial facilities — warehouse structures, factory buildings, and mezzanine platforms
- Infrastructure projects — bridge girders, highway overpasses, and railway supports
- Heavy equipment foundations — crane runways and machine bases
- Temporary structures — shoring systems and construction staging
The JR impact grade ensures reliable performance under standard ambient conditions, making this grade suitable for most temperate-climate construction environments.
Get a Competitive Quote for S235JR H Beam
As a certified structural steel supplier with direct mill partnerships, we deliver premium-grade S235JR H beams at cost-effective, mill-direct rates. Every shipment includes full EN 10204 3.1 documentation for complete traceability.
- 24/7 customer support available
- Free samples for quality evaluation
- Competitive pricing for bulk orders
- Professional technical consultation
Contact us today to get your free quote within 24 hours!
