High-Strength C-Shaped Steel - ASTM Certified Manufacturer
China
Supplier's customization ability
- Drawing-based customization
- Sample-based customization
- Full customization
Minimum order quantity: 1 ton
Shipping total: To be negotiated
- Lead time:
- confirmed with the quotation
- Packaging:
- standard export packing
- Samples:
- available on request
Product details
Technical Specifications of High-Strength C-Shaped Steel
| Property | Parameter | Description |
|---|---|---|
| Product Name | High-Strength C-Shaped Steel | Cold-formed high-strength C-channel structural steel section |
| Material Grade | Q345B / S355JR / ASTM A572 Gr.50 | High-strength low-alloy structural steel with international equivalent grades |
| Standard Compliance | GB/T 6725, EN 10162, ASTM A1011 | Compliant with Chinese, European, and American cold-formed steel standards |
| Carbon (C) | ≤ 0.20% | Controlled carbon content for optimal weldability and strength |
| Manganese (Mn) | ≤ 1.60% | Enhances tensile strength and hardenability |
| Silicon (Si) | ≤ 0.55% | Improves strength and deoxidation during steelmaking |
| Phosphorus (P) | ≤ 0.025% | Strictly controlled to prevent cold brittleness |
| Sulfur (S) | ≤ 0.025% | Minimized to ensure ductility and toughness |
| Tensile Strength | 470 - 630 MPa | Per GB/T 1591 / EN 10025-2 standard requirements |
| Yield Strength | ≥ 345 MPa | Minimum yield point ensuring structural load-bearing capacity |
| Elongation | ≥ 20% | Measured on standard gauge length A5, indicating good ductility |
| Dimensions | Height: 80 - 300 mm; Width: 40 - 100 mm; Thickness: 1.5 - 6.0 mm; Length: 6 - 12 m | Customizable C-channel profiles per project specifications |
| Surface Finish | Hot-dip galvanized / Painted / Black (mill finish) | Galvanized coating thickness 60 - 275 g/m² available for corrosion resistance |
| Application | Steel structure framing, purlins, wall girts, solar mounting systems, industrial buildings | Widely used in prefabricated construction and light steel structures |
| Certification | ISO 9001, CE, SGS, BV | Third-party quality certification ensuring international trade compliance |
| Packaging | Bundled with steel strips, waterproof paper wrapped, tagged | Seaworthy packaging suitable for container or bulk vessel shipment |
| MOQ | 5 Metric Tons | Smaller trial orders negotiable for new customers |
High-Strength C-Shaped Steel - ASTM Certified Manufacturer
High-strength C-shaped steel is a precision-engineered cold-formed structural profile that serves critical roles in modern construction, industrial framing, and infrastructure development. Manufactured through advanced roll-forming processes using premium-grade steel coils, this versatile section delivers exceptional load-bearing capacity while maintaining a lightweight profile. As an ASTM-certified manufacturer with over a decade of production expertise, we supply high-strength C-channel steel to contractors, fabricators, and distributors across more than 30 countries. Our mill-direct supply chain ensures consistent quality, reliable delivery schedules, and cost-effective pricing for projects of every scale — from commercial building frameworks to solar panel mounting systems and warehouse purlin installations.
What Is High-Strength C-Shaped Steel?
High-strength C-shaped steel, also referred to as C-channel or C-purlin, is a cold-formed structural member with a cross-section resembling the letter "C." It features two parallel flanges connected by a single web, creating an open-profile geometry that provides superior structural rigidity relative to its weight. Produced from high-strength low-alloy (HSLA) steel or structural-grade carbon steel, this profile finds extensive application in steel-framed buildings, mezzanine floors, curtain wall supports, and equipment mounting brackets. The cold-forming process enhances the steel's yield strength through strain hardening, resulting in a finished product that outperforms traditional hot-rolled sections of equivalent thickness.
High-Strength C-Shaped Steel Technical Specifications
Our C-shaped steel profiles are manufactured to meet or exceed ASTM A572 Grade 50 and ASTM A36 standards, ensuring reliable performance across demanding structural applications. Below are the key technical parameters:
| Parameter | Specification |
|---|---|
| Steel Grade | Q235B, Q345B, ASTM A36, ASTM A572 Gr.50, S235JR, S355JR |
| Yield Strength | 235–450 MPa (depending on grade) |
| Tensile Strength | 370–630 MPa minimum per applicable standard |
| Web Height | 80 mm – 300 mm |
| Flange Width | 40 mm – 100 mm |
| Thickness | 1.5 mm – 6.0 mm |
| Length | 1,000 mm – 12,000 mm (custom lengths available) |
| Surface Treatment | Hot-dip galvanized (Z120–Z275), painted, or bare finish |
| Lip Height | 15 mm – 25 mm (lipped C-channel option) |
| Tolerance | Per GB/T 6725, EN 10162, or AISI S200 |
Hot-dip galvanized options provide outstanding anti-corrosion properties with zinc coating weights ranging from 120 g/m² to 275 g/m², extending service life to 25+ years in standard atmospheric environments. All profiles undergo rigorous dimensional inspection, tensile testing, and coating thickness verification before shipment.
Key Advantages of Our High-Strength C-Channel Steel
Our C-shaped steel profiles offer distinct advantages that set them apart in the marketplace. The superior yield-to-weight ratio — with Q345B grade delivering a minimum yield strength of 345 MPa at thicknesses as low as 2.0 mm — enables engineers to design lighter structures without compromising load capacity. Precision roll-forming technology maintains dimensional tolerances within ±0.5 mm on web height and ±0.3 mm on thickness, ensuring seamless fit during on-site assembly. Pre-punched holes, custom perforations, and back-to-back pairing for I-beam configurations are available upon request, reducing fabrication time and labor costs at the project site.
Get a Competitive Quote for High-Strength C-Shaped Steel
Partner with a trusted ASTM-certified manufacturer for your next structural steel project. Whether you need standard purlins or custom-dimensioned C-channels, our team delivers mill-direct rates with flexible MOQ options tailored to your requirements.
- 24/7 customer support available
- Free samples for quality evaluation
- Competitive pricing for bulk orders
- Professional technical consultation
Contact us today to get your free quote within 24 hours!
