Roof And Wall Enclosure Steel For Industrial Buildings

Zhonghe Building Materials Co., Ltd.

Verified Custom manufacturer · 3 yrs ·

China

Customizable Rock-bottom price

$20 10-499 meter Base price

$18 500-999 meter 10% off

$15 ≥1000 meter 25% off

Price validity: subject to market conditions

Supplier's customization ability

Drawing-based customization
Sample-based customization
Full customization

Quantity

Minimum order quantity: 1 meter

Shipping total: To be negotiated

Subtotal of goods US$ 20.00

Start order request

Payment and delivery

Payment:: by contract — deposit, balance after your inspection
Lead time:: confirmed with the quotation
Packaging:: standard export packing
Samples:: available on request

Product details

Technical Specifications of Roof and Wall Enclosure Steel

Property	Parameter	Description
Product Name	Roof and Wall Enclosure Steel	Structural steel panels and profiles for roof and wall cladding systems
Material Grade	Q235B / Q345B / S280GD / S350GD	High-strength galvanized or color-coated steel for enclosure applications
Thickness Range	0.3 mm – 1.5 mm	Single-layer or composite panel thickness depending on application
Width Range	600 mm – 1250 mm	Effective coverage width after installation overlap
Length Range	2000 mm – 12000 mm	Custom lengths available per project requirement
Zinc Coating Weight	60 – 275 g/m²	Hot-dip galvanized coating for corrosion resistance (Z60–Z275)
Paint Coating Thickness	15 – 25 μm (top) / 5 – 10 μm (back)	Polyester (PE) or PVDF coating for color-coated enclosure panels
Tensile Strength	280 – 550 MPa	Meets structural load-bearing requirements for roofing and walling
Yield Strength	250 – 420 MPa	Ensures panel rigidity under wind and snow loads
Thermal Insulation (U-value)	0.25 – 0.45 W/(m²·K)	Applicable for sandwich panel configurations with insulation core
Fire Resistance Rating	Class A / Class B1	Non-combustible or flame-retardant options available
Surface Treatment	Galvanized / Aluzinc / Color-coated	Multiple surface finishes for aesthetic and protective purposes
Profile Type	Corrugated / Trapezoidal / Standing Seam	Various rib profiles to suit different structural and design needs
Applicable Temperature	-40°C – +120°C	Suitable for extreme climate environments
Application	Industrial plants, warehouses, commercial buildings, cold storage	Widely used in roof and wall enclosure systems across construction sectors
Certification	ISO 9001 / CE / GB/T 12754 / ASTM A792	Quality and safety certifications for international markets
MOQ	5 tons	Minimum order quantity per specification or color
Supply Capacity	5000 tons/month	Stable production capacity to meet large-scale project demands

Roof And Wall Enclosure Steel For Industrial Buildings

Roof and wall enclosure steel is the backbone of modern industrial building envelopes, delivering structural integrity, weather resistance, and long-term durability across warehouses, manufacturing plants, logistics hubs, and commercial facilities. As industrial construction demands continue to rise globally, high-performance enclosure steel has become the material of choice for architects, contractors, and project developers seeking reliable, cost-effective cladding solutions. Our roof and wall enclosure steel products are manufactured to meet the most stringent international standards, including EN 10346, ASTM A653, and GB/T 12754, ensuring consistent quality across every project. Whether you are constructing a single-span warehouse or a multi-bay industrial complex, the right enclosure steel system significantly reduces construction timelines, lowers lifecycle maintenance costs, and enhances overall building energy efficiency. With a growing portfolio of hot-dip galvanized, pre-painted, and high-strength coated steel panels, we serve clients across Asia, Europe, the Middle East, and North America with reliable supply chains and competitive pricing.

Roof and wall enclosure steel supplier

What is Roof and Wall Enclosure Steel?

Roof and wall enclosure steel refers to cold-formed or roll-formed steel sheets, panels, and profiled sections specifically engineered to form the exterior skin of industrial and commercial buildings. Typically produced from hot-dip galvanized steel substrate (Z275 or AZ150 coating class) with optional PVDF, polyester, or HDP color coatings, these products include corrugated sheets, trapezoidal profiles, standing seam panels, and insulated sandwich panels. They function simultaneously as structural cladding, weatherproofing membranes, and thermal barriers, making them indispensable in modern prefabricated and steel-frame construction systems.

Roof and Wall Enclosure Steel Manufacturing and Processing

Our enclosure steel is produced through a continuous roll-forming and coil-coating process using prime-grade base coils sourced from certified steel mills. Base material thickness ranges from 0.3 mm to 1.5 mm, with tensile strength grades of S280GD to S550GD available. Zinc coating weight is precisely controlled at 275 g/m² (double-sided) to guarantee corrosion resistance exceeding 25 years in C3 environments. Color coatings are applied via a two-coat, two-bake (2C2B) process, achieving a dry film thickness of 25–35 μm on the top surface and 10–15 μm on the reverse side. Each production batch undergoes salt spray testing (minimum 500 hours per ISO 9227), adhesion testing (cross-cut method, Grade 0), and T-bend flexibility testing before shipment authorization.

Roof and wall enclosure steel manufacturer

Roof and Wall Enclosure Steel Technical Specifications

Our standard roof and wall enclosure steel profiles are available in effective coverage widths of 750 mm, 900 mm, and 1,000 mm, with panel lengths customizable from 1,500 mm to 12,000 mm per order requirement. Profile rib heights range from 18 mm (shallow corrugated) to 76 mm (deep trapezoidal), providing moment of inertia values between 8.5 cm⁴/m and 74.2 cm⁴/m depending on profile geometry and base thickness. Thermal transmittance (U-value) for insulated sandwich panel systems achieves as low as 0.23 W/(m²·K) with 100 mm mineral wool or PIR core. Wind uplift resistance is certified at up to 3.0 kPa under AS/NZS 1562.1 and EN 14782 test protocols. All products carry CE marking, ISO 9001:2015 certification, and LEED-compatible environmental declarations.

Roof and wall enclosure steel factory

Get a Competitive Quote for Roof and Wall Enclosure Steel

Ready to source high-performance roof and wall enclosure steel for your next industrial building project? We offer flexible MOQ policies, factory-direct pricing, and global logistics support to ensure your materials arrive on schedule and within budget. Our technical team provides full project consultation, including profile selection, load calculation support, and fixing system recommendations.

Dedicated steel industry technical support available 24/7
On-time delivery guarantee with real-time shipment tracking
Wholesale and bulk project discounts for contractors and distributors
Full material certificates, test reports, and technical datasheets included with every order

Contact us today to get your free quote and project availability list within 24 hours!

Ratings & Reviews

4.5

Based on 8 reviews

5 5

4 2

3 1

2 0

1 0

Thomas B.

United Kingdom

2025-02-02

Initial colour inconsistency resolved promptly – now satisfied

Ordered 8,000 m² of 0.5 mm pre-painted corrugated sheets (polyester, RAL 7035) for a warehouse extension in Manchester. On delivery, approximately 600 m² from one coil batch showed a visible colour variance against the rest of the order – noticeable under direct daylight. Raised the issue with the account team immediately. They acknowledged the batch deviation, arranged a replacement shipment within 12 working days, and covered the return freight cost. Replacement panels matched perfectly. The after-sales resolution was handled professionally. Willing to order again given how the problem was managed.

Aisha K.

UAE

2025-02-24

Good corrosion performance in C4 marine environment – competitive pricing

We specified 16,500 m² of AZ150-coated trapezoidal sheets (1.0 mm, S350GD) for an industrial facility near the Dubai coastline. The AZ150 Galvalume coating was critical for our C4 marine environment requirement, and the supplier's corrosion resistance data supported our 25-year durability design. Pricing was competitive against three other international quotes. Documentation – including CE marks, ISO 9001 certs, and third-party test reports – was thorough. Slight packaging damage on two pallets was noted at port; supplier arranged replacement panels within 10 days. Overall satisfied.

Sarah M.

United States

2025-03-18

Strong value on wall cladding panels – minor lead time variance

Procured 11,200 m² of 0.6 mm polyester-coated wall enclosure panels (S320GD, 900 mm coverage width) for a commercial storage facility in Ohio. Factory-direct pricing came in 12% below our previous domestic supplier for equivalent ASTM A653 G90 spec material. Quality was solid – T-bend flexibility tests passed and coating adhesion was Grade 0. Only reason for 4 stars: lead time extended by 5 days versus original confirmation. Account team communicated the delay proactively, which helped us reschedule the cladding crew. Would order again.

Know your supplier

Zhonghe Building Materials Co., Ltd.

3 yrs on Sinoali.com

Located in China

Company information More goods

FAQ

Q: What products do you supply for building enclosure systems?

A:We supply corrugated steel sheets, wall panels, roof panels, color coated steel, galvanized steel, and accessories for building envelope and cladding.

Q: What materials are your building enclosure steel products made of?

Q: Are your steel panels suitable for exterior wall cladding?

Q: Do you provide insulated or sandwich panels for building enclosure?

Q: What thickness range do you offer for building enclosure steel?

Q: What is the service life of your building enclosure steel materials?

Product display

Zhonghe Building Materials Co., Ltd. is a professional industrial manufacturer and supplier focusing on high-quality building materials. We specialize in a full range of steel building materials, covering reinforcing steel bars, galvanized steel products, corrugated steel sheets, structural steel pipes and other related metal construction materials.

Equipped with advanced production lines and precision testing equipment, the company implements strict full-process quality control and holds authoritative industry qualification certificates. We maintain sufficient spot inventory, adopt standardized export packaging, and ensure stable delivery cycles to meet global customer demands.

Our products are widely applied in construction engineering, machinery manufacturing, shipbuilding, energy and infrastructure projects. Adhering to the principle of quality first and customer-oriented service, we are committed to providing reliable building material solutions and long-term stable cooperation for global clients.
