| Property | Parameter | Description |
|---|---|---|
| Product Name | Weather Resistant Enclosure Steel | High-strength weathering steel for outdoor enclosure structures |
| Material Grade | Corten A / Corten B / S355J2W | Atmospheric corrosion-resistant structural steel grades |
| Size Range | Thickness: 1.5–50 mm; Width: 600–2500 mm | Custom dimensions available upon request |
| Tensile Strength | 470–630 MPa | Minimum tensile strength per standard specification |
| Yield Strength | ≥355 MPa | Minimum yield point at room temperature |
| Elongation | ≥19% | Minimum elongation at fracture (A80) |
| Copper Content | 0.25–0.55% | Key alloying element enhancing weather resistance |
| Chromium Content | 0.40–0.65% | Improves oxidation and corrosion resistance |
| Phosphorus Content | ≤0.035% | Controlled to ensure weldability and toughness |
| Corrosion Resistance | Corrosion Index ≤6.0 (ASTM G101) | Forms stable patina layer; no painting required |
| Surface Finish | Hot-rolled / Pickled / Sandblasted | Multiple finishes for different enclosure applications |
| Moisture Resistance | Humidity ≤95% RH (non-condensing) | Suitable for high-humidity outdoor environments |
| Operating Temperature | -40°C to +150°C | Maintains structural integrity across temperature range |
| Packaging | Steel strip bundled / Wooden pallet / Seaworthy packing | Export-standard packaging to prevent transit damage |
| Storage Conditions | Dry, ventilated warehouse; avoid direct contact with ground | Prevents premature surface oxidation before installation |
| Application | Outdoor enclosures, electrical cabinets, facades, bridges | Widely used in industrial and architectural weathering applications |
| Certification | ISO 9001, CE, SGS, Mill Test Certificate (EN 10204 3.1) | Third-party quality verification available |
| MOQ | 5,000 kg | Minimum order quantity per grade and size |
| Supply Capacity | 5,000 MT/month | Stable supply from certified steel mills |
Initial surface finish inconsistency — resolved after supplier intervention
We received 6 tonnes of 4mm ASTM A588 for IP65 switchgear enclosure panels. About 12% of plates in the first shipment showed uneven shot blasting — some areas below Sa 2.5 cleanliness standard, which risked adhesion failure on our powder coat line. We raised the issue with documentation and photos within 24 hours. The supplier acknowledged the problem, arranged a replacement lot within 10 days, and issued a corrective action report. Second shipment was fully compliant. Material spec itself — yield strength 355 MPa, copper 0.38% — was correct throughout. Situation was handled professionally, but the initial QC miss cost us production time.
